CMS505
1. Product Introduction
1-1. Overview
The card management system can save labor costs, and reduce auditing
stress. All top-ups and cash settlements are completed at the cash
register to avoid unnecessary cash handling. This solves the problem of
miscalculation and difference between the cash and computer accounts of
other branches, and decrease the time cost of checking and reconciling.
Easy to install and use, no need for network cable connection between
devices. Information is using and transferring by the memory of the CPU.
Without the computer management, each host can work independently.
After using the system management, the accounts are clearer, the handover
is simple, it is easy to check and manage at any time, and improve the work
efficiency of the playground.
All game cards can be transferred between players, and the venue does not
need to be recovered, but can be stored, refunded and deposited.
Applicable to all: game machine, machines with the functions of opening
points, returning coins, and issuing lottery tickets.
1-2. Features
• Card Information High security
• Compatible with various game consoles
• Multiple devices can be connected in real time
★ Avaliable type for contact card(ISO 7816) & non-contact card(RFID)
2
Card Reader
2. Product Specifications
2-1. General Specifications
Communication
Interface RS232/PULSE
Card type Contact card(ISO 7816)、non-contact card
(Mifare1 S70)
Installation site Indoors
2-2. Electronic Specifications
Input power +12V DC
Power Consumption
Standby:1.5~1.6W
Working:2.3W
Max.:2.5W
Temperature Range (° C)
Ambient: 0~60
Storage:-10~80
Humidity:20~70%RH(no condensation)
2-3. Machine Specifications
Weight 229 ±12g
Dimension 133 x 92 x 75 mm
Screen Size 1.8 Inch Screen
3. Product content
Main CMS 505( non-contact card )
Accessories
Manual*1
Wires (Check page…)
Screw set
CMS100H Adapter board(Optional)
Metal Frame Sticker (Purchase)
Metal Frame (Purchase)
3
CMS505
4. Product Dimension
133.1 5.24
92.2 3.63
51 2.008
51 2.008
117.3 4.618
115.9 4.563
84.1 3.311
84.1 3.311
75.1 2.957
36.5 1.437
4 .157
4
Card Reader
5. Installation Instructions
5-1. Board description
1. Dig holes according to the recommended shape and size.
2. Put the CMS505 into the iron frame according to the direction shown in
the figure, and lock the nut.
Nuts
CMS505
Metal Frame
105.6 4.157
136 5.354
110 4.331
105.6 4.157
136.6 5.378
136.6 5.378
6 .236
孔*4
20 .787
20 .787
20 .787
20 .787
94 3.701
94 3.701
5
CMS505
3. Put the CMS505 into the board according to the direction shown in the
figure and lock the nut.
5-2. iron plate description
1. Put the CMS505 into the stud on the iron plate according to the direction
shown in the figure, and lock the nut to complete.
Nuts
CMS505
CMS505
Iron Plate
Nuts
board
6
Card Reader
6. Application
7
CMS505
7. Wiring
Connector Interface Voltage Use Wire Pag.
J2 Power +12V DC Power Cable WEL-R7U02 8
WEL-
R7U02 Power +12V DC Power
Extension CU-R961-1 9
CN4 RS232/
UART Data Transfer WEL-R7U06
(Purchase) 10
CN4 USB/UART Data Transfer 2WIR-CP2102N-00
(Purchase) 11
J4 PULSE/
HOPPER Data Transfer 2WIR-CMS3000C-00
(Purchase) 12
CMS100H Power +12V DC CMS100H
Power cord
2WIR-CMS100G1-0B
(Purchase) 13
CMS100H UART/
UART
CMS100H
Data transfer
2WIR-CMS100H1-0A
(Purchase) 14
Setting Button
Dip Switch
( J2 )
WEL-R7U02 ( J4 )
2WIR-CMS300C-00
( CN4 )
WEL-R7U06
2WIR-CP2102N--00
For Software update
