InstallingtheFuse
Insetthefuse(25A)intothefuseblockatthesecond
fuseslotfromtheleft(Figure11).
Note:Thefusemaynotneedtobeinstalledifafuse
hasalreadybeeninstalledfromanotherT orokit.
g244641
Figure11
1.Fuse(25A)2.Fuseslot—secondfrom
left(switchpanelfuse
block)
6
ConnectingtheBattery
NoPartsRequired
Procedure
Connectthebattery;refertotheelectricalsystem
maintenancesectionofyourOperator’sManual.
7
AdjustingtheCoolingFan
Position
NoPartsRequired
Procedure
1.Seattheoperatorofthemachineinthe
operator’sseat.
2.Rotatethefanswitchtomedium-fanspeed.
3.Determineiftheoperatorwantstheairstreamof
thecoolingfanmovedforwardorrearward:
•Iftheairstreampositioniscorrect,shutoff
thecoolingfan.
•Iftheoperatorwantstheairstreamofthe
coolingfanmoved,performthefollowing
steps:
A.Shutoffthecoolingfan.
B.Removethe4carriagebolts(1/4x5/8
inch)and4angelocknuts(1/4inch)
thatsecuretheswitchpaneltotheleft
andrightside-framechannels(Figure
12).
g244667
Figure12
1.Flangelocknut(1/4inch)3.Carriagebolt(1/4x5/8
inch)
2.Switchpanel4.Side-framechannel
C.Movetheswitchpanelforwardor
rearward(Figure13)toalignthecooling
fanthepositionthatyoudeterminedin
step3.
Note:Youcansetthecoolingfanto1
of5positions.
