Toro 03611 Bedienungsanleitung
FormNo.3425-165RevA
2PostROPSExtensionKit
Groundsmaster®4300andReelmaster®5010SeriesTractionUnit
ModelNo.03611—SerialNo.400000000andUp
InstallationInstructions
Important:WheninstallingthiskitwiththeSafetyandSecurityCageKit,usebothinstallation
instructionstogether.
Safety
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal133-0980
133-0980
1.Headlight—on4.Overheadlight—off
2.Headlight—off5.Wipers—off
3.Overheadlight—on6.Wiperuid—on
decal133-1027
133-1027
1.Fan—max2.Fan—off
©2018—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3425-165*A
Installation
1
PreparingtheMachine
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface,engagetheparkingbrake,lowerthecuttingunits,shutoffthe
engine,andremovethekey.
2.Tipuptheseat,openthehood,andremovethehoodsaddle(Figure1).
g211620
Figure1
1.Hoodsaddle
3.Iftherearelightsontherollbarposts,removethelightsandmountinghardwarefromtherollbarposts
(Figure2).
Note:Retainthelightsandhardwareforinstallingthelightsaftercompletingthisinstallation.
2
g263121
Figure2
1.Rearroofmount11.Largeholeplug21.Thumbscrewknob31.Serialplate
2.Leftupperbracket12.Smallholeplug22.Retainernut32.Poprivet
3.Leftbrace13.Flangenut(5/16inch)23.Sunshade33.Grabhandle
4.Frontmount14.Hex-headangebolt(3/8x
1inch)
24.Hex-angebolt(5/16x1
inch)
34.Mediumholeplug
5.Rightupperbracket15.Flangenut(3/8inch)25.Sealingwasher35.Upperchannelmount
6.Rightbrace16.Rivet26.Hex-headangebolt(1/4x
1inch)
36.Leftrollbarmount
7.Frontroofmount17.Clip27.Upperrightpostcover37.Sidechannelmount
8.Lowerbracketmount18.Rectangleholeplug28.Upperleftpostcover38.Rightrollbarmount
9.Controlpanel19.Speednut29.Lowerleftpostcover39.Wireharness
10.Hex-headangebolt(5/16
x3/4inch)
20.Fusecoverplate30.Lowerrightpostcover40.Screw(1/4x5/8inch)
3
2
AssemblingtheKit
Partsneededforthisprocedure:
1Rearroofmount
1Leftupperbracket
1Leftbrace
1Frontmount
1Rightupperbracket
1Rightbrace
1Frontroofmount
1Lowerbracketmount
1Controlpanel
54Hex-headangebolt(5/16x3/4inch)
2Panelplug
2Plasticplug
58Flangenut(5/16inch)
6Hex-headangebolt(3/8x1inch)
7Flangenut(3/8inch)
26Rivet
4Clip
4Holeplug
2Speednut
1Fusecoverplate
2Thumbscrewknob
2Retainernut
1Sunshade
4Hex-headangebolt(5/16x1inch)
4Sealingwasher
4Hex-headangebolt(1/4x1inch)
1Upperrightpostcover
1Upperleftpostcover
1Lowerleftpostcover
1Lowerrightpostcover
1Grabhandle
8Push-infastener
2Upperchannelmount
1Leftrollbarmount
4Sidechannelmount
1Rightrollbarmount
4
Procedure
Note:RefertoFigure2asyouperformthefollowingsteps.
Important:Whenyouinitiallyinstallcomponents,tightenthefasteners,thenloosenthemahalf
turn;youwilltightentheminstep11.
1.Installthefrontmountontotheoorpanelwithhex-headangebolts(3/8x1inch)andangenuts(3/8
inch)fromthekit(BoxAofFigure3).
g263106
Figure3
5
2.Installtherearroofmountontotheupperpartoftherollbarwithupperchannelmounts,hex-headange
bolts(5/16x3/4inch),andangenuts(5/16inch)(BoxBofFigure3).
Note:Ensurethatthemountiscenteredontherollbar.
3.Installtheleftandrightbracesontotheleftandrightsidesofthefrontmount,respectively,withhex-head
angebolts(5/16x3/4inch)andangenuts(5/16inch)(BoxCofFigure3).
4.Installtheleftandrightupperbracketsontotherearroofmountwithhex-headangebolts(5/16x3/4
inch)andangenuts(5/16inch)(BoxDofFigure3).
5.Attachtheleftandrightupperbracketstothetopoftheleftandrightbraces,respectively,withhex-head
angebolts(5/16x3/4inch)andangenuts(5/16inch)(BoxDofFigure3).
6.Installtheleftandrightrollbarmountstotheleftandrightupperbrackets,respectively,withhex-head
angebolts(5/16x3/4inch)andangenuts(5/16inch)(BoxAofFigure4).
g263109
Figure4
7.Installtheleftandrightrollbarmountstotherollbarwithsidechannelmounts,hex-headangebolts
(5/16x3/4inch),andangenuts(5/16inch)(BoxBofFigure4).
6
8.Installtherectangleandcircularholeplugsinthecontrolpanel(BoxAofFigure5).
g263110
Figure5
9.Installthefrontroofmountontotheleftandrightbraceswithhex-headangebolts(5/16x3/4inch)
andangenuts(5/16inch)(BoxBofFigure5.
10.Alignthemountingholesonthecontrolpanelwiththeholesinthefrontroofmount,andsecurethecontrol
panelontothefrontroofmountbyinsertingtherivetsintotheirrespectiveholesandpushingtheplunger
oneachrivetuntilitissecure(BoxCofFigure5).
11.Tightenallloosefastenerssecurely.
7
12.Installthefusecoverplatewithspeednuts,retainernuts,andthumbscrewknobs(Figure6).
g263104
Figure6
13.Installthelowerbracketmounttotheleftandrightbraceswithhex-headangebolts(5/16x1inch)
andangenuts(5/16inch)(BoxAofFigure7).
g263107
Figure7
14.Installthegrabhandlewithhex-headangebolts(5/16x3/4inch)andangenuts(5/16inch)(BoxBof
Figure7).
8
17.Installthesunshadeontothefrontandrearroofmountswithleftandrightroofmounts,hex-headange
bolts(1/4x1inch),sealingwashers,andclips(BoxAandBofFigure9).
g263108
Figure9
18.Installthemediumholeplugsintotheunusedholesintheleftandrightbraces(BoxCofFigure9).
3
InstallingtheWireHarness
Partsneededforthisprocedure:
1Wireharness
InstallingtheWireHarnessonAll
Machines
1.Disconnectthebattery;refertothetractionunit
Operator’sManual.
2.Installthewireharnessasfollowsandasshown
inFigure10throughFigure20:
Note:Thepowerharnessisrequiredonlyif
yourmachinehasoptionalpoweredaccessories.
A.Connectthepositiveterminaltothepositive
postonthestarter.
B.Connectthenegativeterminaltotheengine
ground.
C.Ensurethattheharnessdoesnotcontact
anyhotormovingparts,andsecureitin
placewithcableties.
3.Installthemagneticcablemountsasshownin
Figure10.
g219339
Figure10
Allmodels
1.Magneticcablemounts
10
