Using ToteVision LCD-567T Television
Since TV signals vary in different areas, you need to select the appropriate signal.
LCD-567T provides AIR, STD, HRC and IRC cable band.
Only one of these TV systems will be selected from the menu.
To ensure that you can select and watch all active channels
please refer to the section “Channel Auto Scanning”.
Accessing the TV Controls
To access the various TV controls
open up the menu displays by pressing MENU key on the remote control.
The MENU can be accessed only with remote control.
The Remote control
The following figure shows a clear layout of the remote control.
Calling up a Menu display
Press the MENU button on the remote control to call up the various menu displays.
Then, use the Channel Up/Down buttons to select which item you want to access or adjust.
Display color will be changed for the selected item.
Press Volume -/+ to adjust values or activate command.
The Menu is in two pages as below. Access next page by pressing MENU button a second time.
.
MENUpage#1
MENUpage#2
CONTRAST
BRIGHTNESS
COLOR
TINT
DEFAULT
Select CH-/CH+ Adjust VOL-/VOL+
CH AUTO SCAN
CH DELETE
CH MANUAL SELECT
TV MODE STD
Select CH-/CH+ Adjust VOL-/VOL+
