Touch Dynamic CS-200 Bedienungsanleitung

CS-200

Point-of-Sale

HardwareSystem

User Manual

Revision v1.3 December 2009

Manual Version 1.3

Part Number:

The information contained in this document is subject to change without notice.

We make no warranty of any kind with regard to this material, including, but not limited to, the

implied warranties of merchantability and fitness for a particular purpose. We shall not be

liable for errors contained herein or for incidental or consequential damages in connection

with the furnishing, performance, or use of this material.

This document contains proprietary information that is protected by copyright. All rights are

reserved. No part of this document may be photocopied, reproduced or translated to another

language without the prior written consent of the manufacturer.

TRADEMARK

Intel®, Pentium® and MMX are registered trademarks of Intel® Corporation. Microsoft® and

Windows® are registered trademarks of Microsoft Corporation.

Other trademarks mentioned herein are the property of their respective owners.

Safety

IMPORTANT SAFETY INSTRUCTIONS

1. To disconnect the machine from the electrical power supply, turn off the power switch

and remove the power cord plug from the wall socket. The wall socket must be easily

accessible and in close proximity to the machine.

2. Read these instructions carefully. Save these instructions for future reference.

3. Follow all warnings and instructions marked on the product.

4. Do not use this product near water.

5. Do not place this product on an unstable cart, stand, or table. The product may fall,

causing serious damage to the product.

6. Slots and openings in the cabinet and the back or bottom are provided for ventilation to

ensure reliable operation of the product and to protect it from overheating. These

openings must not be blocked or covered. The openings should never be blocked by

placing the product on a bed, sofa, rug, or other similar surface. This product should

never be placed near or over a radiator or heat register or in a built-in installation unless

proper ventilation is provided.

7. This product should be operated from the type of power indicated on the marking label.

If you are not sure of the type of power available, consult your dealer or local power

company.

8. Do not allow anything to rest on the power cord. Do not locate this product where

persons will walk on the cord.

9. Never push objects of any kind into this product through cabinet slots as they may

touch dangerous voltage points or short out parts that could result in a fire or electric

shock. Never spill liquid of any kind on the product.

CE MARK

This device complies with the requirements of the EEC directive

2004/108/EC with regard to “Electromagnetic compatibility” and

2006/95/EC “Low Voltage Directive”.

FCC This device complies with part 15 of the FCC rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including interference that may cause

undesired operation.

CAUTION ON LITHIUM BATTERIES

There is a danger of explosion if the battery is replaced incorrectly. Replace only with the

same or equivalent type recommended by the manufacturer. Discard used batteries

according to the manufacturer’s instructions.

LEGISLATION AND WEEE SYMBOL

2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection,

recycling and disposal of electric and electronic devices and their components.

The crossed dustbin symbol on the device means that it should not be disposed of with other

household wastes at the end of its working life. Instead, the device should be taken to the

waste collection centers for activation of the treatment, collection, recycling and disposal

procedure.

To prevent possible harm to the environment or human health from uncontrolled waste

disposal, please separate this from other types of wastes and recycle it responsibly to

promote the sustainable reuse of material resources.

Household users should contact either the retailer where they purchased this product, or

their local government office, for details of where and how they can take this item for

environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the

purchase contract.

This product should not be mixed with other commercial wastes for disposal.

Revision History

Changes to the original user manual are listed below:

Version Date Description

1.0 2007 December Initial release

1.1 2007 March System disassembly updated

1.2 2007 October

Cover page update

Wall mount bracket installation

Connector Pin Definition update

1.3 2009 December Drivers installation removed from manual

Table of Contents

1. Item Checklist .............................................................................................................................................................7

1.1 Standard Items......................................................................................................... 7

2. System View.................................................................................................................................................................8

2.1 Front View................................................................................................................ 8

2.2 Rear View................................................................................................................. 8

2.3 System Drawing....................................................................................................... 9

4. Peripherals Installation............................................................................................................................................11

4.1 Biometric Magnetic Stripe Reader Installation.........................................................11

4.2 Cash Drawer Installation.........................................................................................11

4.3 Customer Display Installation................................................................................. 13

4.4 Second Display Installation.................................................................................... 14

4.5 Wall Mount Bracket Installation.............................................................................. 15

5. System Disassembly..................................................................................................................................................16

5.1. Removing the Base Cover .................................................................................... 16

5.2. Replacing the HDD ............................................................................................... 17

5.4. Replacing the Power Supply................................................................................. 17

5.5. Replacing the RAM............................................................................................... 18

Appendix A: Specification............................................................................................................................................19

Appendix B: Jumper Settings......................................................................................................................................21

Appendix C: BIOS Setting...........................................................................................................................................27

Appendix D: Drivers Installation................................................................................................................................30

1. Item Checklist

Take the system unit out of the carton. Remove the unit from the carton by holding it by

the foam inserts. The following contents should be found in the carton:

1.1 Standard Items

a. Driver CD

b. Power Cable

Note: The power cord type various according to different country and region.

2. System View

2.1 Front View

2.2 Rear View

Note: The maximum current that can be drawn from each COM port is 500 mA.

CD-ROM

(option) USB 1 & 2 Power Button

VGA

COM3

KB/Mouse LAN

Cash Drawer

Power USB 24V

Power USB 12V

COM2

COM1

LPT COM4 Line-In Line-Out

2.3 System Drawing

Item Description

1 Front Bezel

2 Touch Panel

3 LCD Panel

4 LCD Chassis

5 Main Board

6 Inverter

7 MSR Function Board

8 Touch Bridge Board

9 Thermal Module

10 LCD Cover Assembly

11 MSR Dummy Door

12 CPU / RAM Door

Item Description

13 CD-ROM

14 Base Front Cover

15 Front I/O Board

16 CD-ROM Guide Bracket

17 Side Cover

18 Power Supply

19 Rear I/O Board

20 Base Cover Bracket

21 Base Cover
