RENTAL EQUIPMENT SETUP GUIDE

Setup Video Guide:

Scan this QR code

with your phone

camera for video.

Contact our Support Team:

www.choose2rent.com/help

+1 (800) 622-6484 Ext. 3 (USA)

+49 40 226 360 - 590 (Europe)

TP-Link MR200 Router

Shipment Content:

1 x Protective Case

1 x 4G LTE Router

1 x Power Adapter

2 x Antennas

Quick Setup:

1. Install the antennas and position them

upwards.

2. Plug in and turn On the router. Allow 3-5

minutes for the router to light

up when ready.

3. Connect your Wired devices. (e.g. Ethernet

enabled Printer) Connect the ethernet cable

to a yellow port on the back of the router. Plug

the other end of the cable into the printer. The

LAN LED on the router lights up when

connected.

Troubleshooting:

What if…

4. Connect your Wireless devices (e.g.

Tablet / PC) Open the camera app on your

device and scan the QR-Code on the

bottom of the router. Alternatively use the

default SSID (Wireless Network Name) on

the bottom of the router along with the

password in your Important Documents

Folder to connect wirelessly.

5. Via WPS (e.g. WPS enabled Printer) Press

(do not hold) the WPS button on the back

of the router until the WiFi LED starts

flashing. Then proceed to set the printer on

WPS mode as per its setup guide. Allow 1-

2 minutes to establish a connection. Once the

WiFi LED changes from flashing to solid a

connection has been established.

Please DO NOT press the Reset button

on the back of the router.

… the router does not power up?

Please check if the power plugs are plugged in

tightly. Switch On and Off again. Wait 3 mins.

… the WiFi symbol does not light up /the

devices can’t find WiFi to connect to?

Make sure, the WiFi function is switched On.

Use the button on the back of the router.

…the Internet symbol does not light up?

Make sure to reach a signal strength of 3

to 4 bars. Relocate the router closer to a

window for better reception. Wait 3 mins.

…I want to change to a hardline connection?

Please ask for a DHCP activated hardline cable

and plug it into the WAN/LAN port.

… I have to login to change the router setup?

Please turn around for more info.

RENTAL EQUIPMENT SETUP GUIDE

Setup Video Guide:

Scan this QR code

with your phone

camera for video.

Contact our Support Team:

www.choose2rent.com/help

+1 (800) 622-6484 Ext. 3 (USA)

+49 40 226 360 - 590 (Europe)

TP-Link MR200 Router

How to login to the router?

1. Connect your tablet to the router WiFi.

If your router has been reset use default

SSID and password from the bottom of

the router.

2. Then open the Safari browser and type

‘tplinkmodem.net' or the IP

192.168.0.1.

3. Type in ‘admin’ as password.

How to enter a static IP address when

using a static hardline from the venue?

1. Go to ‘Advanced’ over the top

navigation.

2. Then open Network/Internet and

change the connection type to ‘Static IP’.

3. Enter the static IP information here e.g.

IP address, then press ‘Save’.

How to setup a SIM card profile?

Important: Only 4G/LTE SIM cards will work with

this router.

1. Activate and register your new SIM card

on your providers website. If you need

to see an SMS, this can be read under

SMS in Advanced Mode.

2. Go to Network/Internet in Advanced

Mode and enter the dial up settings

from your SIM card provider.

For most providers you can google this

information e.g. ‘dial-up Vodafone UK’ or ‘O2 apn

setting UK’.

How do I confirm a working internet

connectivity?

1. The Internet LED on your router is

lighted up.

2. The Network Map in Basic Mode shows

a tick and the status is ‘connected’.

3. Your tablet opens web pages.
