TP-Link Kasa Smart KP200 Bedienungsanleitung
User Guide
Kasa Smart Wi-Fi Power Outlet
KP200
1910012459 REV1.0.0
Contents
About This Guide ···················································· 1
Introduction ······························································· 2
Appearance ······························································· 3
Set Up Your Smart Power Outlet···················· 4
Main Device Controls··········································· 5
Congure Your Smart Power Outlet ············· 6
Create Scenes·························································· 8
Discover Kasa··························································· 9
Authentication························································10
1
About This Guide
This guide provides a brief introduction to Kasa Smart Wi-Fi Power Outlet and the Kasa app, as well as regulatory information.
Please note that features of Kasa Smart Wi-Fi Power Outlet may vary slightly depending on the model and software version you have, and on your
location, language and internet service provider. All images, parameters and descriptions documented in this guide are used for demonstration only.
Conventions
In this guide, the following convention is used:
Convention Description
Teal Key information appears in teal, including management page text such as menus, items, buttons and so on.
Underline Hyperlinks are in teal and underlined. You can click to redirect to a website.
More Info
• Specications can be found on the product page at https://www.tp-link.com.
• Our Technical Support and troubleshooting information can be found at https://www.tp-link.com/support.
2
Introduction
Replace your traditional in-wall outlet with the Kasa smart power outlet. Set schedules and turn devices on or off with your smartphone or voice
assistant. Ideal for controlling lamps, kitchen appliances, and other devices from anywhere. Download the Kasa app and control your outlets remotely.
The Kasa app provides easy step-by-step installation instructions and convenient remote control from anywhere.
• 2 Smart Outlets - Individually control each outlet and take up less space than smart plugs.
• Easy Install - The Kasa Smart app provides an easy to follow step-by-step wiring guide to help replace your existing in-wall outlets.
• No Hub Required - Connect to your existing Wi-Fi router. No hub or accessories required.
• Scheduling - Set a schedule to automatically turn your smart outlets on and o.
• Voice Control - Use Alexa, Google Assistant, or Microsoft Cortana to control your devices with voice commands.
• Works with IFTTT - Have your smart outlets work together with other devices through support from IFTTT.
3
Appearance
Smart Power Outlet has 2 individual smart outlets, with control buttons to turn on/o devices plugged in. The System LED changes color according to
its status. See the explanation below:
Smart Outlet * 2
Plug in your device and control it from your smartphone.
Each outlet is independent.
Control Button * 2
· Press the button to turn on or o the corresponding outlet.
·Press and hold a button for 5s to reenable setup mode.
·Press and hold a button for 10s to restore KP200 to factory default settings.
Green
Lit up for about 30 seconds when connected to the Wi-Fi network, then turns o.
Blinking Amber
Resetting.
Blinking Green
Searching for Wi-Fi.
Red
No Wi-Fi connection.
Blinking Amber and Green
App-Cong mode initiated.
4
Set Up Your Smart Power Outlet
Follow the steps below to set up your Smart Power Outlet via Kasa Smart app.
1. Download and install Kasa app
Go to Google Play or the Apple App Store
or scan the QR code below to download the
Kasa app on your Android or iOS smartphone
or tablet.
2. Log in or sign up with TP-Link ID
Open the app. Use your TP-Link ID to log in.
If you don’t have a TP-Link ID, tap Create
Account and the Kasa app will guide you
through the rest.
3. Add Device
Tap the + button in the Kasa app, select Smart
Outlet.
5
Set Up Your Smart Power Outlet
Follow the steps below to set up your Smart Power Outlet via Kasa Smart app.
4. Label the Old Wires
Turn off the power, remove the old wallplate
and label the wires before the disconnection.
Label the Wires
100%9:41 AMSketch
Use the provided labels to label the wires.
The black wire is line wire. The white wire
is neutral wire.
Next
5. Connect the New Wires
Disconnect the old wires and connect the new
wires to the connections of Smart Outlet with
the wire labels.
Note: Straighten and align the ends of wires from Smart Outlet and your
outlet box. Fully tighten them and ensure that no conductor is exposed.
Connect the Wires
100%9:41 AMSketch
Use the wire labels to help you match
wires to the connections of Smart Outlet.
Next
6. Double-Check the Wires
Check all of the wires and give them a light tug
while holding the wire nut to make sure they
are secure.
Double-Check the Wires
100%9:41 AMSketch
Check that all of the wires are correct.
Give them a light tug while holding the
wire nut to make sure they are secure.
Next
6
Set Up Your Smart Power Outlet
Follow the steps below to set up your Smart Power Outlet via Kasa Smart app.
7. Install Smart Outlet
Gently fold all of the wires back into the
wallbox. Secure Smart Outlet with the screws
provided.
Install Smart Outlet
100%9:41 AMSketch
Gently fold all of the wires back into the
wallbox. Secure Smart Outlet with the
screws provided.
Next
8. Attach the Wallplate
With your Smart Outlet secured, snap on the
provided wallplate. Follow Kasa instructions to
connect it to your home network.
Attach the Wallplate
100%9:41 AMSketch
With your Smart Outlet secured, snap on
the provided wallplate.
Connect to Wi-Fi
Connect Later
7
Main Device Controls
After you successfully set up your Smart Power Outlet, you will see the home page of the Kasa app. Here you can view the status of all devices that
you've added to Kasa and manage them. There are 2 smart outlets of KP200 and you can tap on a smart outlet to control and manage.
Home Page Device Status
8
Congure Your Smart Power Outlet
On Device Status page, you can set Schedule, preset Away Mode, set Timer, check Usage and change the settings of your smart outlet.
Set Schedule
Tap to set a schedule for your smart
outlet to simplify your daily routine by creating
automatic On/O action.
Preset Away Mode
Ta p to preset the Away Mode and your
smart outlet will be randomly turned on/off
during this time.
