TP-Link TL-MR3220 Bedienungsanleitung

CONTENTS

English.................................................................................1

български..........................................................................13

Bosanski............................................................................25

Čeština ..............................................................................37

Eesti...................................................................................49

Hrvatski..............................................................................60

Latviešu .............................................................................71

Lietuvių ..............................................................................82

Magyar...............................................................................93

Македонски ....................................................................105

Polski............................................................................... 116

Русский язык ..................................................................126

Română...........................................................................137

Shqip ...............................................................................148

Slovenčina.......................................................................159

Slovenski .........................................................................171

Srpski jezik ......................................................................182

English

Quick Installation Guide

Package Contents

System Requirement

The following operating systems are supported:

· Windows XP · Windows Vista · Windows 7

· Windows 98 · Windows 2000 · Windows 2003

· Windows Me · Mac · Linux

The following browsers are supported:

· Microsoft Internet Explorer · FireFox

· Safari · Chrome

The product model shown in this QIG is TL-MR3220, as an1. example.

Information for technical support can be found in the last2. page.

Note

English

Front Panel●

Rear Panel●

WAN Port

Power WPS/RESET Button

4 LAN Ports

ON/OFF Button

Side Panel●

Physical Description

USB PortWi-Fi Button

English

Item Description

(Power) On•. The electrical power is on.

Off•. There is no electrical power.

(System)

On•. The Router is initializing.

Flashing•. The Router is working properly.

Off•. The Router has a system error.

(WLAN) Flashing•. The wireless function is enabled.

Off•. The wireless function is disabled.

(WAN)

(

LAN 1~4

)

On•. A device is linked to the corresponding

port.

Flashing•. There is data beening received or

sent on the corresponding port.

Off•. There is no device linked to the

corresponding port.

(USB)

On•. The USB 3G/4G modem is connected

but no data being transferred.

Flashing•. Data is being received/sent

through the 3G/4G modem.

Off•. The U SB 3G/4G mo de m is n ot

connected.

(WPS)

Slow Flash•. A wireless device is connecting

to the network. This process will last in the

rst 2 minutes.

On•. A wireless device has been successfully

added to the network.

Quick Flash•. A wireless device failed to be

added to the network.

Off•. WPS function is disabled.

English

The router supports both 3G/4G and WAN connection. If both the 3G/4G

USB Modem and WAN port are connected, TL-MR3220 will choose

one of them to access the Internet according to your configuration.

For detailed information, please refer to Step 4 in Part 3 Router

Con guration.

Connect TL-MR3220 to 3G/4G network●

3G/4G

Network

SOCKET

TL-MR3220

Notebook

Connect the notebook/PC to the LAN port of TL-MR3220 with an1)

Ethernet cable.

Plug the power adapter into the power jack of TL-MR3220.2)

Insert 3G/4G USB modem into the USB port (Ensure the SIM card is3)

in the modem).

Press the ON/OFF button to power on TL-MR3220.4)

2Hardware Connection

English

Connect TL-MR3220 to WAN network●

Power off the ADSL/Cable Modem.1)

Connect the notebook/PC to the LAN port of TL-MR3220 with an2)

Ethernet cable. Connect the ADSL/Cable Modem to the WAN port of

TL-MR3220 with an Ethernet cable.

Plug the power adapter into the power jack of TL-MR3220.3)

Power on the modem and wait until all LEDs ﬂ ash properly. Press 4)

the ON/OFF button to power on TL-MR3220.

We recommend you to use only the Power Adapter1.

provided with the device.

Place the device on the level and stable surface.2.

Unplug the Power Adapter in the thunder storm to avoid3.

damage.

Place the device in a well ventilated place far from any4.

heater or heating vent.

Keep the router far from the water to avoid damage.5.

Warning

English

Open web browser, type in1) 192.168.0.1, press Enter, then enter the

User name and Password (admin /admin) and click OK.

The2) Status web page will display after a successful login. Please

check if your 3G/4G USB modem can be recognized or not.

If your 3G/4G USB modem can’t be identied (shown as “Unknown

Modem”), please refer to T4~T6 in Troubleshooting for the solution.

3Router Conguration

Note

English

Click3) Quick Setup menu, then click Next to continue.

Select one Internet access mode, and then click4) Next. As follows we

take 3G/4G Only mode as an example.

Select your location and mobile ISP, then click5) Next.

English

If you can't nd your location in the pull-down list, please tick Set

the Dial Number, APN, Username and Password manually to

manually set them according to the information your 3G/4G ISP

provided.

Set your Wireless Parameter, TP-LINK strongly recommends you to6)

edit the following two items, then click Next.

Create a unique and easy-to-remember•Wireless Network Name

(SSID). You can also keep the default settings.

Select the Wireless Security•WPA-Personal/WPA2-Personal, and

enter a Security Key using 8~64 characters (numbers or letters) in

the Password eld.

Click7) Reboot to complete the Quick Setup. Please note that if there

is nothing changed on Wireless page, the Reboot button will be

replaced by Finish.

Congratulations! You can enjoy the 3G/4G surng now.

Note
