TPG MOBILE BROADBAND

QUICK SETUP GUIDE

TPG USB E1762 Modem

TPG MOBILE BROADBAND QUICK SETUP GUIDE

Thank you for choosing TPG Mobile Broadband and USB E1762 modem.

This User Guide provides step by step instructions that will take you through the setup

process to get started.

Content:

1. Getting to know your USB E1762 modem

2. Installing USB E1762 modem

3. Installing TPG Mobile Broadband Connection software (For Windows XP)

4. Installing TPG Mobile Broadband Connection software (For Mac OSX)

5. Your rst connection to TPG Mobile Broadband

6. Using the Software and USB E1762 modem

7. Checking your data usage online

TPG MOBILE BROADBAND QUICK SETUP GUIDE

SIMPLE STEPS TO GET CONNECTED

TPG MOBILE BROADBAND QUICK SETUP GUIDE 1

1. Getting to Know Your USB Modem

1. USB Interface – It connects the E1762 Modem to the USB Port of your PC.

2. SIM/Micro SIM Card Holder – Insert your TPG Mobile Broadband SIM or

Micro SIM here.

3. Micro SDCard Slot – This holds the Micro SD card (optional, not pro-

vided by TPG).

4. External Antenna Connection - Connect an external antenna

(optional, not provided by TPG) to boost your reception.

5. Indicator Light - Indicates the status of the USB modem.

Indicator Light Staus

Colour Status Meaning

Green Blinking twice every 3 seconds. The USB modem is on

Green Blinking once every 3 seconds. 2G network (GPRS network

- Weak coverage strength/slow speeds).

Blue Blinking once every 3 seconds. 3G network (UMTS network

- Good coverage strength/fast speeds).

Green On 2G network (GPRS network

- Weak coverage strength/slow speeds).

Blue On 3G network (WCDMA network

- Good coverage strength/fast speeds.

Cyan On 3G+ network (HSDPA network

- Strong coverage strength/super fast speeds.

No colour O The USB modem is removed.

TPG MOBILE BROADBAND QUICK SETUP GUIDE

SIMPLE STEPS TO GET CONNECTED 1

TPG MOBILE BROADBAND QUICK SETUP GUIDE 2

TPG MOBILE BROADBAND QUICK SETUP GUIDE

SIMPLE STEPS TO GET CONNECTED

2. Installing USB Modem

NOTE: YOU MUST ACTIVATE THE SIM CARD BEFORE PROCEEDING TO THE NEXT STEP.

SIM ACTIVATION STEPS:

Step 1: Go to www.tpg.com.au/account

Step 2: Login with your Mobile Number or Customer ID and Password (Mobile Number and Customer

ID can be found in the Welcome Letter with SIM card attached. Password is what you nominated

during registration.)

Step 3: Choose “Mobile Broadband Service”

Step 4: Click on the ‘SIM Activation’ button

Step 5: Click on ‘Activate SIM now’

After you’ve completed the activation steps above, please allow up to 24 hours for your activation

request to be processed.

2.1. Insert the TPG SIM/Micro SIM card into the card holder. Make sure the SIM is properly inserted.

2.2. Power on your PC before connecting the USB modem with the PC. Otherwise the normal installation may

be aected.

Method 1: Plug the E1762 Modem into the USB interface of the PC. OR

TPG MOBILE BROADBAND QUICK SETUP GUIDE 3

Method 2: Connect the E1762 to a PC using the USB extension cable (included in the USB Modem pack).

TPG MOBILE BROADBAND QUICK SETUP GUIDE

SIMPLE STEPS TO GET CONNECTED

2. Installing USB Modem

2.3. Follow the relevant steps below to install the TPG Mobile Broadband Software.

Optional Step: Insert the Micro SD card into the USB modem, as shown in the following gure.

Do not remove the Micro SD and the SIM/Micro SIM card when they are being used. Removing cards during

an operation may damage the cards as well as the device, and data stored on the cards may be corrupted.

Note: Micro SD card is an optional accessory

and is not provided by TPG in the package.

TPG MOBILE BROADBAND QUICK SETUP GUIDE 4

TPG MOBILE BROADBAND QUICK SETUP GUIDE

SIMPLE STEPS TO GET CONNECTED

3. Installing TPG Mobile Broadband connection software

(Windows XP)

Note: The steps for installing the TPG Mobile Broadband software depends on the operating system (OS)

installed on your PC. The following sections primarily take Windows XP as an example.

Once you plug in your USB modem to your computer, the OS automatically detects and recognises new

hardware and starts the installation wizard. The Auto Play window will follow up and please click on Run

AutoRun. exe.

If the software does not respond automatically, go to “My Computer”. Click on the disk drive labeled “Wireless

BB”, and then double-click on “AutoRun.exe”, to start the installation program.

TPG MOBILE BROADBAND QUICK SETUP GUIDE 5

TPG MOBILE BROADBAND QUICK SETUP GUIDE

SIMPLE STEPS TO GET CONNECTED

3. Installing TPG Mobile Broadband connection software

(Windows XP)

For Windows Vista and Windows 7 from this point another window named User Account Control might

appear asking to Allow the Data Card Setup and please click on Ye s and then the Setup Software will run.

3.1. Choose Next and then click continue to proceed

3.2. Please read software Licence Agreement, and click I Agree to proceed.

TPG MOBILE BROADBAND QUICK SETUP GUIDE

SIMPLE STEPS TO GET CONNECTED

3.3 Click Next to continue.

3.4 Click the Install button to start the installation process.

TPG MOBILE BROADBAND QUICK SETUP GUIDE

SIMPLE STEPS TO GET CONNECTED

3.5 Please wait until the status bar is completed.

3.6. Once the software and drivers have installed, click Finish.

TPG MOBILE BROADBAND QUICK SETUP GUIDE 8

TPG MOBILE BROADBAND QUICK SETUP GUIDE

SIMPLE STEPS TO GET CONNECTED 3

3.7. Your computer will use the software installed to congure your USB modem. Please wait until the software

tells you it is nished. An information balloon will pop up from your System Tray area to conrm “Found New

Hardware”. Your new hardware is installed and ready to use”. This process may take several minutes.

If you are a Windows user then go to Section 5 and ignore Section 4 (Apple OSX).
