Quick-Start-Guide STKaRZG2x
Arm® architecture
CONNECT HOST PC AND STKaRZG2x
Use the supplied USB cable (USB2.0 ST-A / Micro-B) to connect
Debug-USB (X9) of the STKaRZG2x to a USB port of your host PC.
RUN TERMINAL EMULATOR AND
CONFIGURE SERIAL PORT
Run your favourite terminal emulator on the host PC (we
Recommend Tera Term Pro) and configure the serial port as
Follows:
Baudrate
115200
Data bits
8
Parity
none
Stop bits
1
Handshake
XON / XOFF
!
For latest documentation, BSPs, etc. please visit:
tq-group.com/en/products/tq-embedded/arm-architecture/ STKaRZG2x
Support.tq-group.com/TQMaRZG2x
SUPPLY THE STKaRZG2x WITH POWER
Double-check the mains voltage required for the included
Power supply, then connect it to connector X5 on the
STKaRZG2x.
Caution when using a different power supply! The Starterkit
can be operated using a regulated supply voltage of 16…26V
(nom. 24V)!
ESTABLISH SERIAL CONNECTION
The boot messages of boot loader and operating system are
displayed by the terminal emulator.
B
A
B
A
© TQ-Systems GmbH 2021 | All data is for information purposes only | Subject to change without notice | EMB_QSG_STKaRZG2x_Rev002
Quick-Start-Guide STKaRZG2x
Arm® architecture
S2
DIP
1
2
3
4
5
6
7
8
Set
OFF
OFF
ON
ON
ON
OFF
ON
OFF
S2
DIP
1
2
3
4
5
6
7
8
Set
OFF
OFF
ON
OFF
ON
OFF
OFF
OFF
DIP switch settings
Configuration eMMC
Configuration QSPI-NOR
Boot device selection
To select the desired boot device set DIP switch S2 accordingly.
Reset
To reset the Starterkit, press S9.
