TrackSense LyoPro Bedienungsanleitung

TrackSense®LyoPro Version 3.3 Page 1 of 53

User Manual User Manual TrackSense LyoPro – MAN 7

TrackSense®LyoPro

User Manual

TrackSense®LyoPro Version 3.3 Page 2 of 53

User Manual User Manual TrackSense LyoPro – MAN 7

CONTENTS

1. Safety Information ............................................................................................................4

1.1. Warnings......................................................................................................................4

1.2. General.........................................................................................................................4

1.3. Electrical Hazards......................................................................................................5

1.4. Directives ....................................................................................................................6

1.4.1. EMC…. ...................................................................................................................6

1.4.2. Low Voltage (Safety).........................................................................................6

1.4.3. Waste Electrical and Electronic Equipment ................................................6

1.4.4. Important Notice Regarding Ellab LyoPro Equipment..............................7

1.4.5. ARIB…....................................................................................................................8

1.5. Ellab Service ...............................................................................................................8

2. New Order Contents .........................................................................................................9

2.1. TrackSense®LyoPro Orders ....................................................................................9

3. TrackSense®LyoPro 10-Slot Reader Station ..............................................................9

3.1. Proper Use of Reader Stations ...............................................................................9

3.1.1. LyoPro Reader Station................................................................................... 10

3.2. Communication Setup – Hardware Settings.................................................... 10

3.2.1. USB connection............................................................................................... 10

3.2.2. LAN connection............................................................................................... 11

3.3. LIVE Data Option – Access Point ......................................................................... 12

3.3.1. Specifications.................................................................................................. 12

3.3.2. Access Point: Sensitivity to ESD.................................................................. 13

3.3.3. Communication Setup – LIVE Hardware Settings ................................... 14

3.4. ValSuite®Software Installation Requirements............................................... 17

4. Activating ValSuite®...................................................................................................... 17

4.1. Online Activation -The PC is Connected to the Internet............................. 18

4.1.1. Manual Activation – The PC is Not Connected to the Internet ............ 18

4.1.2. Releasing the License.................................................................................... 19

5. How to Start Logging Data with TrackSense LyoPro.............................................. 19

6. TrackSense®LyoPro Loggers ....................................................................................... 23

6.1. TrackSense®LyoPro............................................................................................... 23

6.1.1. Data Logger Specifications .......................................................................... 23

6.1.2. Proper Use........................................................................................................ 24

6.1.3. Data Logger Serial Numbers ........................................................................ 24

6.1.4. Disassembling / Assembling Data Loggers.............................................. 25

6.1.5. Procedure for Cleaning TrackSense®LyoPro Data Loggers ................. 26

6.1.6. Procedure for Changing the Data Logger O-Ring ................................... 26

6.1.7. Extended Warranty ........................................................................................ 26

6.1.8. Thermocouple Sensor ................................................................................... 26

7. Battery............................................................................................................................... 27

7.1. TrackSense®LyoPro Battery ................................................................................ 27

TrackSense®LyoPro Version 3.3 Page 3 of 53

User Manual User Manual TrackSense LyoPro – MAN 7

7.1.1. Proper Use of TrackSense®LyoPro Batteries........................................... 28

7.1.2. Activating and Testing TrackSense®LyoPro Battery.............................. 29

8. Calibration........................................................................................................................ 30

8.1. Ellab Factory Calibration ...................................................................................... 30

8.1.1. Calibration Types – TrackSense®LyoPro .................................................. 30

8.2. In-House Calibration Solutions........................................................................... 30

8.2.1. Ellab Temperature Standard (ETS).............................................................. 31

8.2.2. Installation for Windows 7, 8 and Windows 10 ...................................... 33

8.2.3. Ellab Dry Blocks .............................................................................................. 33

8.3. ValSuite®Calibration Options............................................................................. 34

8.3.1. Manual Calibration......................................................................................... 34

9. Accessories ...................................................................................................................... 34

9.1. StopperClip .............................................................................................................. 35

9.2. LyoStopper............................................................................................................... 35

9.2.1. Standard Versions & Reference Numbers................................................ 35

9.3. LoggerNest............................................................................................................... 36

9.3.1. Standard Versions & Reference Numbers................................................ 36

9.3.2. Standard Versions & Reference Numbers – StopperClips.................... 37

9.4. LoggerClip................................................................................................................ 37

9.4.1. Standard Versions & Reference Numbers – LoggerClips...................... 38

9.5. BufferClip ................................................................................................................. 38

9.5.1. Standard Versions & Reference Numbers – BufferClips....................... 39

10. Examples on how to Configure LyoPro Using LyoStopper or Various

LoggerClips ................................................................................................................................ 39

11. Firmware Update............................................................................................................ 41

11.1. Reader Station and LyoPro Loggers................................................................... 41

11.1.1. Procedure for Updating the LyoPro Logger and Reader Station

Firmware…………................................................................................................................ 43

11.1.2. Procedure for Updating the LyoPro Reader Station firmware.......... 46

12. Ellab Service Contract ................................................................................................... 48

12.1. TrackSense®LyoPro Equipment Warranty ....................................................... 48

12.2. Extended Warranty ................................................................................................ 49

13. Technical Specifications............................................................................................... 50

14. FAQ..................................................................................................................................... 51

15. Changelog ........................................................................................................................ 53

TrackSense®LyoPro Version 3.3 Page 4 of 53

User Manual User Manual TrackSense LyoPro – MAN 7

1. Safety Information

Use this equipment only as specified in this manual. Otherwise, the protection

provided by the equipment may be impaired.

•“Warning” identifies conditions and actions that may pose hazards to the user

•“Caution” identifies conditions and actions that may damage the equipment

being used

1.1. Warnings

Disclaimer: Ellab manufactures equipment intended for use in thermal

validation, monitoring and stability studies. Equipment used for applications

other than these studies is used at the discretion and sole responsibility of the

customer. Ellab cannot accept any responsibility for the use of equipment for

any application other than thermal validation, monitoring and stability studies.

The customer needs to verify the temperature range of the equipment being

used before placing it into an application.

1.2. General

DO NOT use the equipment for any application other than its intended use, e.g.

thermal validation, monitoring and stability studies. Any other use of the

equipment may cause unknown hazards to the user.

DO NOT use the equipment in environments other than those listed in this

user’s guide and follow all safety guidelines. Only trained personnel should use

the equipment. Inspect the equipment for damage before each use.

DO NOT use the equipment if it appears damaged or operates abnormally.

Before initial use, after transport, or after storage in humid or semi-humid

environments, the equipment needs to be dried for a period of at least 2 hours.

If the equipment is wet or has been in a wet environment, take necessary

measures to remove moisture prior to applying power. The equipment is

intended for indoor use only.

TrackSense®LyoPro Version 3.3 Page 5 of 53

User Manual User Manual TrackSense LyoPro – MAN 7

1.3. Electrical Hazards

These guidelines must be followed to ensure that the safety mechanisms in the

equipment will operate properly. Equipment, when applicable, must be

plugged into a 115 VAC (± 10%) or 230 VAC (± 10%) 50/60 Hz electric outlet

as indicated on the label. The power is supplied by an 5V AC/DC adaptor which

can be plugged directly into a receptable. The receptacle must be installed in

accordance with local codes and ordinances.

Cautions:

Always operate TrackSense LyoPro Reader Stations at room temperature

between 5 °C and 50 °C (41 °F and 122 °F).

DO NOT operate this equipment in an excessively wet, oily, dusty, or dirty

environment. The equipment is a precision instrument. Although it has been

designed for optimum durability and trouble-free operation, it must be handled

with care. The equipment including any probes or loggers are sensitive

instruments that can easily be damaged. Always handle these devices with

care. Do not allow them to be dropped, struck, stressed or overheated.

TrackSense Clock (Internal)

When using TrackSense LyoPro loggers, ValSuite will start an internal clock in

the logger. Beware that the max time deviation at 23 °C will be +/- 5 seconds

over 24 hours.

TrackSense®LyoPro Version 3.3 Page 6 of 53

User Manual User Manual TrackSense LyoPro – MAN 7

1.4. Directives

1.4.1. EMC

Ellab equipment has been tested to meet the European Electromagnetic

Compatibility Directive (EMC Directive, 2014/30/EU).The Declaration of

Conformity for your instrument lists the specific standards at which the unit

was tested.

1.4.2. Low Voltage (Safety)

In order to comply with the European Low Voltage Directive (LVD)

2014/35/EU), Ellab equipment has been designed to meet the EN 61010-1

standard.

1.4.3. Waste Electrical and Electronic Equipment

All products supplied after February 1st, 2003 meet the requirements

of the Directive 2012/19/EU on the Waste from Electrical and

Electronic Equipment (WEEE).

This means that all Ellab products, which must be recycled or handled

separately, are marked with the WEEE label in accordance with Directive

2012/19/EU Waste from Electrical and Electronic Equipment.

In addition, Ellab A/S accept scrapped equipment from customers and sort it

for waste disposal. Used equipment returned to Ellab A/S for service may also

be scrapped in accordance with the Directive. However, it is not legal to ship

waste products across country borders for disposal.

Ellab distributors are obliged to register waste in accordance with their

national legislation, which may also require them to accept scrapped

equipment from end users and dispose of it according to their national laws.

This Declaration of Conformity is issued under the sole responsibility of the

manufacturer, pursuant to ISO/IEC 17050. It does not affect the warranty

obligations of the supplier.

We reserve the right to exceed the standards as part of our product

development program.

TrackSense®LyoPro Version 3.3 Page 7 of 53

User Manual User Manual TrackSense LyoPro – MAN 7

1.4.4. Important Notice Regarding Ellab LyoPro Equipment

FCC ID: XUS-LYODL1, FCC ID: XUS-LYORS1 and FCC ID: XUS-LYOAP1.

Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference

that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

ISED CANADA

IC: 8758A-LYODL1, IC: 8758A-LYORS1 and IC: 8758A-LYOAP1.

CAN ICES-3 (B) / NMB-3(B)

This device contains licence-exempt transmitter(s)/receiver(s) that comply

with Innovation, Science and Economic Development Canada’s licence-exempt

RSS(s).

Operation is subject to the following two conditions:

1. This device may not cause interference.

2. This device must accept any interference, including interference that

may cause undesired operation of the device.

TrackSense®LyoPro Version 3.3 Page 8 of 53

User Manual User Manual TrackSense LyoPro – MAN 7

L’émetteur/récepteur exempt de licence contenu dans le présent appareil est

conforme aux CNR d’Innovation, Sciences et Développement économique

Canada applicables aux appareils radio exempts de licence. L’exploitation est

autorisée aux deux conditions suivantes :

1. L’appareil ne doit pas produire de brouillage ;

2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le

brouillage est susceptible d’en compromettre le fonctionnement.

1.4.4.1. FCC and ISED Applicable to TrackSense LyoPro Access Point

FCC: To comply with FCC RF exposure requirements this device with its

antennas must be installed and operated with a min separation distance of

20 cm to any human body.

ISED: To comply with ISED RF exposure requirements this device with its

antennas must be installed and operated with a min separation distance of

20 cm to any human body.

This radio transmitter [IC: 8758A-LYOAP1] has been approved by Innovation,

Science and Economic Development Canada to operate with the antenna

types listed below, with the maximum permissible gain indicated.

Antenna types not included in this list that have a gain greater than the

maximum gain indicated for any type listed are strictly prohibited for use

with this device. Monopole Antenna / 2144150011 Molex / 5.3 dBi.

1.4.5. ARIB

Ellab LyoPro equipment has been tested to comply with the

requirements in the Japanese standard ARIB STD-T66 (Low-Power Data

Communication System/Wireless LAN System).

1.5. Ellab Service

Please contact your local Ellab sales representative for the proper service

center location. Contact information can be found at www.ellab.com.

When contacting Ellab for support, please have the following information

available:

•Model Number

•Serial Number

•Voltage

•Complete description of the problem

•ValSuite Software Version

TrackSense®LyoPro Version 3.3 Page 9 of 53

User Manual User Manual TrackSense LyoPro – MAN 7

2. New Order Contents

When a new system is ordered, the equipment is shipped in a custom Ellab

suitcase. The suitcase contains the following products:

2.1. TrackSense®LyoPro Orders

•Suitcase

•Reader Station

•Power supply

•Accessories Box

•Screwdriver

•Pen for battery

•O-Ring Sealant

•USB Cable

•Quick Guide

•USB key with Software and other

documents

•Access Point for live data (optional)

3. TrackSense®LyoPro 10-Slot Reader Station

3.1. Proper Use of Reader Stations

•The Ellab reader station is intended to be used at room temperature. The

station should not be exposed to temperatures below 5 °C or above 50 °C

•Do not immerse the reader station in water under any circumstances

•Although the TrackSense LyoPro 10-slot reader station is quite robust, it

should be handled with care. Dropping or exposing it to heavy mechanical

shock may loosen or damage the electronic connections

•Only use cables (USB) and power supplies provided by Ellab

Operating Temperature

5 to 50 °C

Environmental:

0 – 90% RH, non-condensing

Operating Voltage

External Adapter 100-240V AC, 50-60 Hz or USB

Weight:

1,100 Grams

Dimensions (H x W x D) :

35 x 177 x 148 mm

Material:

Aluminum

Reader/Logger Communication:

Radio Frequency (RF)

TrackSense®LyoPro Version 3.3 Page 10 of 53

User Manual User Manual TrackSense LyoPro – MAN 7

3.1.1. LyoPro Reader Station

•Contains 10 logger positions

•Connected to PC via USB or LAN (ethernet)

•Only 1 LyoPro reader station can be used at a time

3.2. Communication Setup – Hardware Settings

All TrackSense LyoPro 10-slot Reader Stations can be connected to PC via USB or

LAN (ethernet).

3.2.1. USB connection

•Connect the USB cable to the reader station and PC (USB 3.0 is

required)

•Connect the 5V DC power supply to the reader station (option)

•When connecting the 10-slot reader station, the generic driver is

automatically detected and installed.

Inhaltsverzeichnis

Beliebte Datenlogger Handbücher anderer Marken

TESTO

TESTO 176 Bedienungsanleitung

HT Italia

HT Italia XL421 Bedienungsanleitung

HBM

HBM SOMAT XR CX22B-R Bedienungsanleitung

Agtrix

Agtrix 380i Bedienungsanleitung

Hobo

Hobo H8 Pro Bedienungsanleitung

Beijing ART Tech

Beijing ART Tech PCI2320 Bedienungsanleitung

Athena

Athena GET SL1 Bedienungsanleitung

Motec Systems

Motec Systems C185 Bedienungsanleitung

Beijing ART Tech

Beijing ART Tech USB2832 Bedienungsanleitung

Rotronic

Rotronic HygroLog HL20 Bedienungsanleitung

MRC

MRC DW-6092 Bedienungsanleitung

Racelogic

Racelogic VBOX LapTimer Bedienungsanleitung

Edu-Logger

Edu-Logger 900-240 Bedienungsanleitung

Elma

Elma DT173 Bedienungsanleitung

MadgeTech

MadgeTech PRTemp140 Technisches Datenblatt

Comet

Comet U0121M Bedienungsanleitung

pico Technology

pico Technology PT-104 Bedienungsanleitung

Soil Instruments

Soil Instruments GTecLink Bedienungsanleitung
