Trans-Tek LS402-B Bedienungsanleitung

version:1.0

GUANGDONG TRANSTEK MEDICAL ELECTRONICS CO., LTD

Zone A, 5/F., Investment Building, No. 12, Huizhan East Rd., Torch Development

District, Zhongshan, Guangdong, 528437, China

TEL:86-760-88282982 www.transtek.cn

User Manual

Bluetooth Pedometer LS402-B

Please do read the user manual carefully and thoroughly so as to ensure

the safe usage of this product, and keep the manual well for further

reference in case you have problems.

Thank you very much for selecting the Transtek Bluetooth Pedometer

LS402-B.

FCC ID: OU9LS402-B01

Table of Contents

Overview

Device Components

Initial Start-Up

General Instructions

How to Turn on the Pedometer for Your First Use

Install the App and Pair-up

Start Measuring

How to Use

Troubleshooting

Specifications

Maintenance

Warranty

11-12

.................................................................................................................

...................................................................................................................

.............................................................................................................................

............................................................................................................................

...............................................................................................................................

......................................................................................................................................

............................................. ...........................................................

............................................................

How to Charge the Power 5

...........................................................................................................

How to Carry the Pedometer 7

. ..........................................................

How to View the Data 9-10

................................................................................................................

............................................

Symbol Meaning

.................................................................................................................

2 3

List

1. Bluetooth Pedometer LS402-B (including Polymer Lithium Battery)

2. User Manual

3. Sling

OverviewSymbol Meaning

General Instructions

Device Components

The warning signs and symbols are essential to ensure your correct and safe use of

this product and protect you and others from injury. Please kindly find the meanings of the

warning signs and symbols, which you may encounter in the label and user manual, as

follows:

Symbol Meaning

Symbol for “THE OPERATION

GUIDE MUST BE READ” Symbol for “MANUFACTURER”

Symbol for “COMPLIES WITH MDD

93/42/ECC REQUIREMENTS”

Symbol for “ENVIRONMENT

PROTECTION – Waste electrical

products should not be disposed of with

household waste. Please recycle where

facilities exist. Check with your local

authority or retailer for recycling advice”

Symbol for “DIRECT CURRENT”

Transtek Bluetooth Pedometer LS402-B is used to measuring the

walking steps, distance and the consumed calories.

This device has bluetooth 4.0 technology, the user can set the time

and unit etc. through the bluetooth, and then download the information

to the pedometer. The data in the pedometer also can be uploaded to

the bluetooth. So the user can check it at anytime.

Main Features:

a. support the bluetooth 4.0 technology

b. OLED display

c. keep a record per every 10 minutes if there has some changes

d. display walking steps, walking distance, the consumed calories

and the current time

e. send the data to the App per every 5 seconds

BUTTON

OLED DISPLAY

USB INTERFACE

Symbol for “MANUFACTURE

DATE”

How to Turn on the Pedometer for Your First Use

When the pedometer is off, press and hold the button for 5

seconds to turn on the pedometer for the first time.

Note: For the first time to use the pedometer,if you press the

button shortly, there is no reaction.

How to Charge the Power

When the OLED displays the following symbol, it reminds you to

charge the power at once.

Connect the USB interface with the computer to finish the

charging.

When the device is charging the power, the OLED will display as

the following picture. The power symbol blinks.

The OLED displays as the following picture, it means the

charging is complete.

Initial Start-Up Initial Start-Up

Install the App and Pair-Up

Initial Start-UpInitial Start-Up

If SUCCEED, symbol will be shown on the

OLED.

If FAIL, symbol “E1” will be shown on the OLED.

Download and install the app in your iPhone.

Turn on Bluetooth and the App. Make sure both are ON when

pair-up is proceeding.

Press and hold the button on the pedometer for 5 seconds to start

pair-up.

Symbol and symbol will be shown on the

OLED alternatively, indicating pair-up is

proceeding.

The measuring data will be transmitted to your phone

automatically if you have paired up with it.

How to Carry the Pedometer

You can choose one of the following methods to carry the

pedometer.

1. Put it in the handbag.

2. Put it in the pocket. Such as the

trousers pocket or the coat pocket.

3. Use the attached sling to hand

around your neck.

Note: It is only available for iPod touch(5th generation), iPhone 4S, iPhone 5,

iPad(3th and 4th generation) and iPad mini to pair up with the device.

Start Measuring

The measuring data will be transmitted to your phone automatically if

you have paired up with it.

How to Use

Follow the hints in the manual to carry the pedometer. Then it can

start the measurement.

How to View the Data

When the OLED is off, press the key on the pedometer, the

OLED will display the steps you have walked.

Then press the key again, the OLED will display the current

time.

When the OLED displays the current time, press the key on the

pedometer, the OLED will display the calories you have

consumed.

Troubleshooting

Solution

Please check below items:

-Bluetooth is ON.

-App Collector is ON.

-Both devices are within the

transmission distance of Bluetooth.

Problem Root Cause

Abnormal

measuring results:

Huge difference

between two recent

measurement.

Incorrect portable fashion

make the device

has irregular shaking

The steps less than 10

Slide or wearing

the slippers to walk

Use the correct portable fashion,

avoid that the pedometer has

irregular shaking

Continue to walk more than

10 steps

Walk in a normal way

10 11

Failure of pairing up your

pedometer with iPhone 4S

Troubleshooting

When the OLED displays the calories, press the key on the

pedometer, the OLED will display the distance you have walked.

If there is no operation for 5 seconds, the OLED will turn off

automatically.

Then press the key again, the OLED will display the battery.

Start Measuring

Problem Root Cause Solution

No display on

OLED when the

device powers on.

The device

powers off

automatically.

Low battery.

Bluetooth is OFF.

Data transmission

failed.

Turn ON the Bluetooth via

“Setting >> General >> Bluetooth”.

The App is OFF. Press the icon to turn ON your

app.

Place your iPhone closer to the

pedometer.

Out of range of Bluetooth

transmission.

Please charge power in time.

12 13

The power is not enough. Charge power in time.

The device didn’t logout

the shipping mode for the first

measurement.

Long press button for

5 seconds, the device will recover

to the normal mode.

Specifications

Product Name

Dimension

Bluetooth Pedometer (LS402-B)

Whole size:55x30x7.2mm

Net Weight Approximately 10 g ( including the dry cells)

Display Blue OLED

V.A.:22.4mm x 5.6mm

Steps 0-120000 steps, division 1 step

Calories

Battery Grade

Working Environment Temperature: 0℃to 40℃Humidity: ≤90% RH

Storage Environment Temperature: -20℃to 60℃

Power Source 3.7V / 50mAh polymer lithium battery

Battery Life ≥7 days when fully charged

and doing sports for 8 hours per day

Exercise Time 0-23 hours and 59 minutes, division 1 minute

Accessories 1. USB cable

2. User Manual

3. Sling

About the Accuracy of This Product

This product passes strict inspection before delivery and therefore its accuracy is guaranteed by the manufacturer.

Please refer to the above table for the descriptions on accuracy.

This product is specially designed for body fat analysis as well as weight measurement. It should NOT be used by

anyone during the process of transaction for verification of goods’ weight.

1-7 grade, division 1 grade

0-12000.0 kcal, division 0.1 kcal

Troubleshooting Specifications

Humidity: ≤90% RH

Pressure: 80 kPa ~ 106 kPa

Pressure: 50 kPa ~ 106 kPa
