Setup for IR Control
Each HXU-1Rx receiver has a built in IR sensor and can be assigned its’ own unique IR remote ID
for independent source switching via infrared remote control. The HXU-1 will also extend IR from
Tx to Rx when in Multicast/Matrix mode. From a control system; affix IR emitter to (or flash) each
HXU-1Tx, plug IR flasher included with HXU-1 into a HXU-1Rx’s “IR TX” 3.5mm mini-jack, face that
flasher at the IR sensor window on that Rx, and repeat for each receiver. For control of connected
displays, add an IR splitter to the HXU-1Rx’s “IR TX” 3.5mm mini-jack to connect multiple IR
emitters/flashers (one for each connected device including the HXU-1Rx itself).
IR MACRO Programming: Control Format:
For installation controlled with IR, it is likely to involve MACRO programming of a universal remote
control. When needed, go to TE web site to download the IR Pronto Codes for keys described in
the command sequence below.
[Start] [Address] [[Address No...]] [Command] [Command No] [Parameter] [[Parameter No...]] [End]
[Start] Star button of remote control
[End] End button of remote control
[Address] Type of address:
[All] All button of remote control, means all receivers
[D#] D# button of remote control, means Device No.
[G#] G# button of remote control, means Group No.
[P#] P# button of remote control, means Party No.
[Address No]
Set Device No. from [0] ~ [9][9][9][9]
Set Group No. from [0] ~ [9][9]
Set Party No. from [0] ~ [9][9]
[Command] Command [Cmd] button of remote control
[Command No] Command numbers:
[0] Start IR Extend ON/OFF Timer Countdown
[1] Set IR Extend ON Timer
[2] Set IR Extend OFF Timer
[3] Channel selection
[4] Screen ON/OFF
[Parameter] Parameter [Para] button of remote control, the continued number is parameter
[Parameter No] Parameter numbers:
Set IR Extend ON/OFF Timer [0] ~ [6][5], based on second
Channel [0] ~ [1][5]
Screen [0] = OFF[1] = ON
e.g.1: All receivers select channel 12
[Start] [All] [Command] [3] [Parameter] [1] [2] [End]
e.g.2: Receiver with Device No. 1234 select channel 5
[Start] [D#] [1] [2] [3] [4] [Command] [3] [Parameter] [5] [End]
e.g.3: Receivers with Party No. 9 select to channel 0
[Start] [P#] [9] [Command] [3] [Parameter] [0] [End]
