Traxon E:cue Genius AM38213003I Technisches Datenblatt

AM38213003I, AM38214003I

e:cue Genius (4CH and 8CH)

Information for Use

Edition:

09.03.23 [EN_ecue_Genius_Node_combined_Setup_v1p1]

Published by:

Traxon Technologies Europe GmbH

Karl-Schurz-Strasse 38

33100 Paderborn, Germany

Read the Information for Use and the Safety Instructions

carefully. Subject to modication without prior notice.

Typographical and other errors do not justify any claim for

damages. Modication of the product is prohibited.

This document is designed for electricians, system

administrators and product users..

All product names and trademarks mentioned in this manual are

trademarks of their respective owners.

Except for internal use, relinquishment of the instructions to a

third party, duplication in any type or form - also extracts - as

well as exploitation and / or communication of the contents is not

permitted.

Traxon Technologies Europe GmbH

Sales Operations

Karl-Schurz-Str. 38

33100 Paderborn, Germany

+49 5251 54648-0

[email protected]

Downloads and more information at:

www.ecue.com

Table of Contents

Genius (4CH and 8CH) — Information for Use | Table of Contents

Table of Contents

1 Safety instructions 03

1.1 Symbols 03

1.2 General safety instructions 03

2 General device description 04

2.1 Delivery content 05

2.2 Genius 4CH 05

2.3 Genius 8CH 07

2.4 User interface: LEDs 08

2.5 Manual switches 08

3 General remarks 09

3.1 Transport 09

3.2 Unpacking 09

3.3 Warranty regulations 09

3.4 Maintenance and Repair 09

3.5 Disposal 10

3.6 Support 10

4 Installation 10

4.1 Installation conditions 11

4.2 Mounting process 12

4.3 Modbus connection 12

4.4 Relay connection 12

4.5 Relay connection diagram 13

4.6 Input power 15

4.7 System diagrams 15

5 Modbus Settings 16

5.1 Conguration of the Genius Modbus settings 16

6 Integration in SYMPHOLIGHT 18

7 Modbus Registers 19

7.1 Single Hold Registers 19

7.2 Single Coil Register 19

8 Port Status 20

9 Firmware Update 20

10 Dismounting 21

11 Certications 21

12 Dimensions 22

12.1 Genius 4CH 22

12.2 Genius 8CH 22

13 Modbus register list 23

14 Example: Reading register 25

1 Safety instructions

Please read the safety instructions carefully. Make sure that the environmental, mounting, and installation

prerequisites are met. This manual should be kept at a safe place and in reach of the device.

1.1 Symbols

This icon warns about possible damage of the device

itself, to connected devices, and to the user.



This icon warns about electrical voltage.

This icon warns about hot surfaces.

This icon states mandatory actions.

This icon gives general hints and informs about

handling and procedures for use of the device.

1.2 General safety instructions

The product must only be installed, put into operation

and dismounted by a qualied electrician. The

applicable safety regulations and accident prevention

regulations must be observed.

Otherwise the unit may be damaged or injuries may

happen.

The product may only be operated in the operating

modes and environments described in the manual.

Read and adhere the manual instructions.



Danger of death

Electrical shocks or re

— Do not use the device if power supply, power

cables, or power wearing lines are damaged.

— Tighten the screw terminals adequately (0.5 Nm).

— The altitude for which the operation of the Genius

is rated is 0 ... 2000 m above sea level.

Take care: Exposure to possible risk of electrical

shock.

Conguration of this product must be performed by

qualied individuals who are knowledgeable about the

procedures, precautions, and hazards associated

with the product.

Caution

Risk of burns

Device components can reach high temperatures.

Let unit cool down after operation before mounting

or removing unit.

Genius (4CH and 8CH) — Information for Use | Safety instructions



content

— Only work on the product when it is de-energized

to prevent electrical shocks. Connect cables and

data only when the device is powered down.

Exception: USB connection.

— Output Ratings / Channel (CH):

Load Type CH1-CH4, CH1-CH8

General Use 20 A, 230 V AC

Incandescent Lamp 4600 W, 230 V AC

Electronic Ballast 16 A, 230 V AC

Inrush Current 500 A peak / 2 ms

Valid for Genius 4CH and Genius 8CH.

Notice

— No user serviceable parts inside. Opening the

device voids the warranty. Do not open or try to

repair the device. Repairs must only be carried

out by authorized Traxon e:cue specialists. Return

it to your Traxon e:cue distributor for

replacement or repair.

— Keep away from re and water.

2 General device description

e:cue Nodes are a system of interfaces and provide various connection types like DMX/RDM, DALI, digital

inputs and outputs etc.

The Genius is a relay controller and energy meter that combines measuring and switching load in a single

device. Communication with any third party system is made via the Modbus RTU / ASCII protocol at an RS-

485 interface. The Genius provides bistable relay interfaces in single-pole, single-throw conguration,

accompanied by manual switches for service overrides. It is a modular basic solution for controlling lighting

installations. The Genius is easily mounted on standard 35 mm DIN rails, or with a key hole in the housing base

on walls or on any stable vertical surface. The Node is AC line powered.

Measured data: Voltage

Current

Power (active, apparent, reactive)

Power factor

Energy (active)

Phase

Line frequency

Status.

For the detailed list see “13 Modbus register list” (page 23).

Genius (4CH and 8CH) — Information for Use | General device description



content

Notice

— The e:cue Genius is not for use as an tari

counter. All measured values are for indication

purposes only.

— The e:cue Genius is not for use in potentially

explosive atmospheres and not for safety-related

technical equipment.

2.1 Delivery content

Delivery content of the e:cue Genius - Product number AM38213003I, AM38214003I:

yGenius

ySafety instructions

yInformation for Use (English / German)

yUSB A to USB Mini-B adapter cable

2.2 Genius 4CH

2.2.1 Productspecications

Product number AM38213003I

Dimensions (W x H x D) 106.3 x 90.5 x 62 mm/

4.2 x 3.6 x 2.4 in

(excl. fastening clip)

Weight 320 g / 0.71 lb

Input power 200-240V ±10% 50/60Hz AC

Power consumption < 3 W

Operating temperature 0 ... 50 °C / 32 ... 122 °F

for > 40 °C, only use max. 2

channels up to 20 A load

Storage temperature -10 ... 70 °C / 14 ... 158 °F

Operating / storage humidity 0 … 80% RH, non-condensing

Overvoltage category II

Installation conditions IP20, not designed for outdoor use

Intra-building connections only

Pollution degree II

IEC protection class Class II

Housing Self extinguishing blend PC/ABS, UL

document E140692

Mounting On 35 mm DIN rail (EN 60715) or

with key hole on any stable vertical

surface

Certi cates CE, RoHS, UKCA

Interfacespecications

Relay outputs 4 x SPST feed-through latching relays with manual

override, rising cage clamp for solid and

stranded wire,

wire gauge: 0.05 ... 5.26 mm²

torque: 0.5 Nm

Nominal voltage per channel: 115 ... 230 V AC

Contact rating Cycles

20 A, 230 V AC resistive load 1 x 105

4600 W, 230 V AC incandescent

lamp

3 x 104

16 A, 230 V AC electronic ballast 6 x 10³

Inrush current: 500 A peak / 2 ms

Max operate frequency per channel: 10 ops. / min

Measured data Voltage, current, power (active, apparent,

reactive), power factor, energy (active), phase,

line frequency, status

Measurement

tolerance

± 3 %

Serial port Modbus RTU / ASCII (RS-485), 3-pin pluggable

connector

USB port 1 x Mini-USB, Type B

User interface Combined LED for data activity and device status

Genius (4CH and 8CH) — Information for Use | General device description



content

Product number AM38213003I

Dimensions (W x H x D) 106.3 x 90.5 x 62 mm/

4.2 x 3.6 x 2.4 in

(excl. fastening clip)

Weight 320 g / 0.71 lb

Input power 200-240V ±10% 50/60Hz AC

Power consumption < 3 W

Operating temperature 0 ... 50 °C / 32 ... 122 °F

for > 40 °C, only use max. 2

channels up to 20 A load

Storage temperature -10 ... 70 °C / 14 ... 158 °F

Operating / storage humidity 0 … 80% RH, non-condensing

Overvoltage category II

Installation conditions IP20, not designed for outdoor use

Intra-building connections only

Pollution degree II

IEC protection class Class II

Housing Self extinguishing blend PC/ABS, UL

document E140692

Mounting On 35 mm DIN rail (EN 60715) or

with key hole on any stable vertical

surface

Certi cates CE, RoHS, UKCA

Interfacespecications

Relay outputs 4 x SPST feed-through latching relays with manual

override, rising cage clamp for solid and

stranded wire,

wire gauge: 0.05 ... 5.26 mm²

torque: 0.5 Nm

Nominal voltage per channel: 115 ... 230 V AC

Contact rating Cycles

20 A, 230 V AC resistive load 1 x 105

4600 W, 230 V AC incandescent

lamp

3 x 104

16 A, 230 V AC electronic ballast 6 x 10³

Inrush current: 500 A peak / 2 ms

Max operate frequency per channel: 10 ops. / min

Measured data Voltage, current, power (active, apparent,

reactive), power factor, energy (active), phase,

line frequency, status

Measurement

tolerance

± 3 %

Serial port Modbus RTU / ASCII (RS-485), 3-pin pluggable

connector

USB port 1 x Mini-USB, Type B

User interface Combined LED for data activity and device status

For all details of the measured data see “13 Modbus register list” (page 23).

2.2.2 Connectors and Interfaces

View from top:

1Relay interfaces CH 1...4 (left to right)

(IN, OUT left to right)

2N for relay interfaces and power supply

3L for power supply

4Manual relay switches CH 1 ... 4 (left to right)

5Status LED (Device status, activity)

6Modbus interface (RS-485: +, –, GND left to right)

7Mini-USB interface (serial conguration interface)

8DIN rail handle

1 2 3

6 7

Genius (4CH and 8CH) — Information for Use | General device description



content

2.3 Genius 8CH

2.3.1 Productspecications

Product number AM38214003I

Dimensions (W x H x D) 213 x 90.5 x 62 mm/

8.4 x 3.6 x 2.4 in

(excl. fastening clip)

Weight 600 g / 1.32 lb

Input power 200-240V ±10% 50/60Hz AC

Power consumption < 4 W

Operating temperature 0 ... 50 °C / 32 ... 122 °F

for > 40 °C, only use max. 4

channels up to 20 A load

Storage temperature -10 ... 70 °C / 14 ... 158 °F

Operating / storage humidity 0 … 80% RH, non-condensing

Overvoltage category II

Installation conditions IP20, not designed for outdoor use

Intra-building connections only

Pollution degree II

IEC protection class Class II

Housing Self extinguishing blend PC/ABS, UL

document E140692

Mounting On 35 mm DIN rail (EN 60715) or

with key hole on any stable vertical

surface

Certi cates CE, RoHS, UKCA

Interfacespecications

Relay outputs 8 x SPST feed-through latching relays with manual

override, rising cage clamp for solid and stranded

wire,

wire gauge: 0.05 ... 5.26 mm²

torque: 0.5 Nm

Nominal voltage per channel: 115 ... 230 V AC

Contact rating Cycles

20 A, 230 V AC resistive load 1 x 105

4600 W, 230 V AC incandescent

lamp

3 x 104

16 A, 230 V AC electronic ballast 6 x 10³

Inrush current: 500 A peak / 2 ms

Max operate frequency per channel: 10 ops./min

Measured data Voltage, current, power (active, apparent,

reactive), power factor, energy (active), phase, line

frequency, status

Measurement

tolerance

± 3 %

Serial port Modbus RTU / ASCII (RS-485), 3-pin pluggable

connector

USB port 1 x Mini-USB, Type B

User interface Combined LED for data activity and device status

Genius (4CH and 8CH) — Information for Use | General device description



content

Product number AM38214003I

Dimensions (W x H x D) 213 x 90.5 x 62 mm/

8.4 x 3.6 x 2.4 in

(excl. fastening clip)

Weight 600 g / 1.32 lb

Input power 200-240V ±10% 50/60Hz AC

Power consumption < 4 W

Operating temperature 0 ... 50 °C / 32 ... 122 °F

for > 40 °C, only use max. 4

channels up to 20 A load

Storage temperature -10 ... 70 °C / 14 ... 158 °F

Operating / storage humidity 0 … 80% RH, non-condensing

Overvoltage category II

Installation conditions IP20, not designed for outdoor use

Intra-building connections only

Pollution degree II

IEC protection class Class II

Housing Self extinguishing blend PC/ABS, UL

document E140692

Mounting On 35 mm DIN rail (EN 60715) or

with key hole on any stable vertical

surface

Certi cates CE, RoHS, UKCA

Interfacespecications

Relay outputs 8 x SPST feed-through latching relays with manual

override, rising cage clamp for solid and stranded

wire,

wire gauge: 0.05 ... 5.26 mm²

torque: 0.5 Nm

Nominal voltage per channel: 115 ... 230 V AC

Contact rating Cycles

20 A, 230 V AC resistive load 1 x 105

4600 W, 230 V AC incandescent

lamp

3 x 104

16 A, 230 V AC electronic ballast 6 x 10³

Inrush current: 500 A peak / 2 ms

Max operate frequency per channel: 10 ops./min

Measured data Voltage, current, power (active, apparent,

reactive), power factor, energy (active), phase, line

frequency, status

Measurement

tolerance

± 3 %

Serial port Modbus RTU / ASCII (RS-485), 3-pin pluggable

connector

USB port 1 x Mini-USB, Type B

User interface Combined LED for data activity and device status

For all details of the measured data see “13 Modbus register list” (page 23).

2.3.2 Connectors and Interfaces

View from top:

1Relay interfaces CH 1...4 (left to right)

(IN, OUT left to right)

2N for relay interfaces CH 1 ... 4

3L for power supply

4Relay interfaces CH 5...8 (left to right)

(IN, OUT left to right)

5N for relay interfaces CH 5 ... 8 and power supply

6Manual relay switches CH 1 ... 8 (left to right)

7Status LED (Device status, activity)

8Modbus interface (RS-485: +, -, GND left to right)

9Mini-USB interface (serial conguration interface)

10 DIN rail handle

2.4 User interface: LEDs

The Genius has one LED on the front panel. The LED shows the basic states of the Genius.

LED states

green, constant The device is powered / on.

LED is o: No power supply.

green, fast

ashing

Bootloader mode.

orange, blinking Activity: Modbus trac (reception and

sending).

red, constant Self-protection shutdown active.

2.5 Manual switches

You can manually switch the relays using Manual switches on the Genius.

1 2 4 5 3

8 9 10

Genius (4CH and 8CH) — Information for Use | General device description



content

OFF

Use a standard screw driver. Do not use small

conductive items.

3 General remarks

3.1 Transport

Only transport the device in its original packaging. This protects the device from damage.

3.2 Unpacking

Only unpack the device at its installation location. To protect the device against condensation water, unpack it

and wait until all moisture remaining in the device has evaporated. Condensation can occur when the device is

moved from a cold to a warm location. Keep the packaging for use in case of further transport. Inspect all

parts for completeness regarding chapter “2.1 Delivery content” (page 05). If there is apparent damage to

the device or parts are missing from the delivery scope, please contact the Traxon e:cue support service.

3.3 Warranty regulations

Depending on the product, warranty regulations are of dierent duration. The warranty time is usually noted

in the quote and in the order conrmation. See www.traxon-ecue.com/terms-and-conditions for details. Legal

warranty regulations apply in any case.

3.4 Maintenance and Repair

This device requires no maintenance.

The device has a self-protection shutdown for safety reasons. To reset a shutdown, turn the device o and

on again.

Caution

Risk of burns

Device components can reach high temperatures.

Let unit cool down after operation before mounting

or removing unit.

Genius (4CH and 8CH) — Information for Use | General remarks



content

Attention: Failure

— Before dismounting, appropriate measures must

be taken to protect the respective components

against damage caused by electrostatic

discharge (ESD protection).

— No user serviceable parts inside. Opening the

device voids the warranty. Do not open or try to

repair the device. Repairs must only be carried

out by authorized Traxon e:cue specialists. Return

it to your Traxon e:cue distributor for

replacement or repair.

3.5 Disposal

The proper disposal of packing materials and of the device is the responsibility of the respective user and for

his account; in all other matters, the retrieval obligation for packing materials and the device is subject to the

statutory regulations.

Batteries and technical appliances must not be

disposed of with domestic waste, but should be

handed in at the appropriate collection and disposal

points.

3.6 Support

In case of technical problems or questions regarding installation and repair please contact:

Traxon Technologies Europe GmbH

Customer Service

Karl-Schurz-Str. 38

33100 Paderborn, Deutschland

+49 (5251) 54648-0

[email protected]

4 Installation

The installation of the Genius consists of mounting the device, connections to the Modbus device, to the

loads, and to input power. For conguration a Mini-USB connection is required additionally.

The sequence of cabling is not dened. Supply the device with power after all cabling is completed; it starts

booting.



Danger of death

Electrical shocks or re

Connect cables and data only when the device is

powered down.

Caution

Risk of burns

Device components can reach high temperatures.

Let unit cool down after operation before mounting

or removing unit.

Genius (4CH and 8CH) — Information for Use | Installation



content

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Traxon Beleuchtungsausrüstung Handbücher

Traxon

Traxon Allegro Dot S Direct View Bedienungsanleitung

Traxon

Traxon Allegro Media Tube Lite Bedienungsanleitung

Traxon

Traxon Cove Light AC DIM Installationsanleitung

Traxon

Traxon Osram Media Tube Go Bedienungsanleitung

Traxon

Traxon ARCHISHAPE Tube Ultra Slim Bedienungsanleitung

Traxon

Traxon ProPoint Vista Series Bedienungsanleitung

Traxon

Traxon Allegro Dot M/L Direct View Bedienungsanleitung

Traxon

Traxon Mesh Installationsanleitung

Traxon

Traxon Media Tube HO Bedienungsanleitung

Traxon

Traxon Allegro Media Tube Lite Installationsanleitung

Traxon

Traxon RGB 50 144PXL Bedienungsanleitung

Traxon

Traxon Media Tube HO Installationsanleitung

Traxon

Traxon Allegro Dot M Installationsanleitung

Traxon

Traxon ProPoint Vista 100W Bedienungsanleitung

Traxon

Traxon e:cue SYMPL pro Node Bedienungsanleitung

Traxon

Traxon Allegro Dot S Direct View Bedienungsanleitung

Traxon

Traxon Pro Washer Pro Nano Bedienungsanleitung

Traxon

Traxon e cue Osram ProPoint KR.MA.01.10001 Installationsanleitung

Traxon

Traxon ARCHISHAPE Dot 2.0 S CE Bedienungsanleitung

Traxon

Traxon Washer Quattro AC XB Installationsanleitung

Beliebte Beleuchtungsausrüstung Handbücher anderer Marken

Brizo

Brizo 8SP-MU-4 Bedienungsanleitung

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Bedienungsanleitung

IKEA

IKEA BJÖRKSPIREA Bedienungsanleitung

Laserworld

Laserworld Evolution Series ES-400RGB Bedienungsanleitung

Alien

Alien RG STAR Bedienungsanleitung

EuroLite

EuroLite LED B-40 Bedienungsanleitung

Qazqa

Qazqa Suplux SL 3 Black 103062 Bedienungsanleitung

Commercial Electric

Commercial Electric 54568141 Bedienungsanleitung

CREE LIGHTING

CREE LIGHTING 304 Series Bedienungsanleitung

Goobay

Goobay 49867 Bedienungsanleitung

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Bedienungsanleitung

Alkalite

Alkalite Krypton KT-81 Bedienungsanleitung

Clas Ohlson

Clas Ohlson GU10 Bedienungsanleitung

DTS

DTS DELTA 10 F Bedienungsanleitung

ring

ring Solar Steplight Bedienungsanleitung

One Stop Gardens

One Stop Gardens 57696 Montageanleitung

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Bedienungsanleitung

SIREM

SIREM Swimeo A2 Bedienungsanleitung

Traxon e:cue Genius AM38213003I Technisches Datenblatt

Beliebte Beleuchtungsausrüstung Handbücher anderer Marken
