TRENDnet TE100-S5Pplus Bedienungsanleitung

TRENDnet's TE100-S5P, 5-port, palm-sized 10/100Mbps

NWay Ethernet Switch, presents the perfect choice for small

workgroups for any desktop space. It allows users to simply

plug any port to either a 10Mbps or 100Mbps network to

multiply bandwidth, boost response time and satisfy heavy

load demands. The NWay ports automatically negotiate

between 10Base-T and 100Base-TX network speeds, half-

and full-duplex modes, and MDI-II and MDI-X media types.

TE100-S5P is truly a Plug-N-Play device, which provides

cost-effective and high-performance solutions.

TE100-S5P

5-port 10/100Mbps NWay Auto-MDI Fast Ethernet Mini Switch

Compliant with IEEE 802.3 and IEEE 802.3µ

standards

5-port NWay 10/100Mbps connection speed auto-

detection

Half- or Full-Duplex operation for each port

Auto-MDI-II / MDI-X media type detection

Operates at maximum packet filtering and

forwarding rate

Store-and-forward switching method

128KB buffer memory

Address table up to 4K MAC address

Compact design with external power adapter

Comprehensive LED indicators for port status

Wall-Mountable with two magnets on the bottom for

mounting on ferrous surface

5-year Warranty

FEATURES BENEFITS

Easy Installation:

Flexibility:

Expandability:

Easy Migration:

Dependability:

Designed to link 10Mbps and

100Mbps with 5 ports for an easy

connection.

NWay ports auto-negotiate between

10Base-T and 100Base-TX, as well as

between half- and full-duplex modes.

Auto-MDI for each port; connects to

regular RJ45 port or Uplink port with

either regular "straight through" or

crossover RJ45 cable.

All ports support 200Mbps (in full-

duplex mode), expanding from any

port and for any number of Switches.

Easy upgrade to Fast Ethernet without

reconfiguration.

Parallel store-and-forward architecture

allows direct transfer.

TE100-S5P (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

SPECIFICATIONS

Standards:

• IEEE 802.3 for 10Base-T Ethernet

• IEEE 802.3µ for 100Base-TX Fast Ethernet

• ANSI/IEEE 802.3µ N-way auto-negotiation

Data Transfer Rate:

• 10/100Mbps (20/200Mbps in full-duplex mode)

Protocol:

• CSMA/CD

Connectors:

• 5 UTP/STP RJ-45 Auto-MDI

Network Media:

• UTP CAT 3, 4, 5 (100m) for 10Base-T

• EIA/TIA-568 100-ohm STP (100m) for

10Base-T/100Base-TX

• UTP CAT 5 (100m) for 100Base-TX

Packet Forwarding Rate:

• 10Base-T: 14,880 ppp per port (half-duplex)

• 100Base-TX/100Base-FX: 148,800 pps per

port (half-duplex)

Topology:

• Star

Diagnostic LEDs:

• Power, 100Mbps, Link/Activity, Collision/Full-duplex

Power:

• External power supply, 7.5V, 1A, max. 7.5 Watts

Dimensions:

• 116 x 70 x 25 mm (4.57 x 2.8 x 0.98 inches)

Weight:

• 199 g (7 oz.)

Temperature:

• Operating: 0° to 50° C (32° F to 122° F)

• Storage: -10° to 70° C (14° F to 158° F)

Humidity:

• Operating: 10 % to 90 % RH

• Storage: 5 % to 90 % RH

Certifications:

• FCC, UL, CE, CSA, C-tick, VCCI

TE100-S5P

5-port 10/100Mbps NWay Auto-MDI Fast Ethernet Mini Switch

TE100-S5P

5-port 10/100Mbps NWay Auto-MDI Fast Ethernet Mini Switch

PRODUCT INFORMATION

TE100-S5P

5-port 10/100Mbps NWay Auto-MDI Fast

Ethernet Mini Switch

TE100-S8P

8-port 10/100Mbps NWay Fast Ethernet Mini

Switch

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION
