TRENDnet TK-208K Bedienungsanleitung

TK-208K

User’s Guide

Table of Contents

English ......................................................................................................

Specifications ............................................................................................

Troubleshooting ........................................................................................

1. Before You Start

2. How to Connect .................................................................................

3. Using the KVM Switch .......................................................................

.................................................................................

Table of Contents

Version 10.31.05

System Requirements

Application

TK-208K

Multi-Language User’s Guide

2 Sets of KVM &Audio Cables

VGAor SVGACompatible Monitor

6-pin Mini-Din PS/2 Keyboard

6-pin Mini-Din PS/2 Mouse

Speakers

Microphone

Package Content

1. Before You Start

English

Microphone

PC 1

Speakers

Keyboard Mouse

PC 2

LCD Monitor

2-Port PS/2 Audio

KVM Switch

(TK-208K)

1. Connect the Monitor to your

Switch's Console Port.

3. Use the provided KVM cables to

connect your PC to your KVM

switch.

2. How to Connect

English

2. Connect the Keyboard, Mouse,

Microphone and Speakers to the

Switch's Console Port.

6. Turn on all connected PC’s.

5. Connect the other end of theAudio

cable to the Switch'sAudio Port.

4. Connect the other end of the cable

to the Switch's PC Port.

Your installation is now complete.

English

To alternate between computers, you use hot-key commands.

Hot-Key Commands

Akeyboard hot-key command consists of three keystrokes:

Hot-Key command = ScrLk + ScrLk + Command key(s)

After pressing the ScrLk key, you have 2 seconds to press the ScrLk key again.

You then have another 2 seconds to press a command key. If you do not press

a key within 2 seconds, the switch will exit hot-key mode.

NOTE

1. Hotkey command works on top row numbers keys only.

2. When the binding of PC &Audio/Mic port switching is enabled by the hotkey

sequence,any PC andAudio/Mic switching are bound together.

3. For non-PnP OS(Linux, Windows NT4.0), please use the following

commands to reset the mouse setting:

4. Mac User must note: Standard PC Keyboard mapping to MAC

Keyboard:

Hot-Key convention: The hotkey notation ,denotes that you should hit the

individual key consecutively one at a time, not simultaneously.

3. Using the KVM Switch

English

Command Hot-Keys Description

Quick Reference Sheet for TK-208K

Select PC

Select Audio/Mic

Channel

Next higher PC

channel

Bind PC & Audio/Mic

Switching

Console Mouse/

Keyboard Reset

UnBind PC & Audio/

Mic Switching

Autoscan

Next lower PC

channel

Stop Autoscan

ScrLk ScrLk X

+ +

x = 1 ~ 2 for PC channel number

ScrLk ScrLk

+ +

(Arrow up)

ScrLk ScrLk

+ +

(Arrow down)

ScrLk ScrLk

+ + W

ScrLk ScrLk

+ + End

ScrLk ScrLk

+ + S

Press any key on keyboard

Select the active PC channel.

Select the active Audio/Mic channel

Select the next lower available computer

Enable the binding of PC port and Audio/Mic port

switching.

Reset mouse/keyboard on the console side. (works on

non-PnP OS only)

Disable the binding of PC port and Audio/Mic port

switching.

Autoscan through every connected channel for

quick screen browsing of each channel (scan delay

= 10 seconds).

Select the next higher available computer

Terminate Autoscan activity.

(Fx is a function key) x = 1 ~ 2 for Audio mic

channel number

ScrLk ScrLk

+ +

ScrLk ScrLk

+ +

English

Computer Connections: 2

Cable Connectors:

Console Port Connectors:

Keyboard: PS/2 Keyboard 6-pin Mini Din (Female)

Mouse: PS/2 Keyboard 6-pin Mini Din (Female)

Monitor: VGAHDB 15-pin (Female)

Speaker: 3.5mm audio in/out jack

Microphone: 3.5mm microphone in/out jack

Specifications

To PC: • 1 x 3.5mm audio in/out jack

• 1 x 3.5mm microphone in/out jack

To Console: 1 x 15-pin HDB type VGA(Male)

KVM

To PC: • 1 x PS/2 Keyboard 6-pin Mini Din (Male)

• 1 x PS/2 Mouse 6-pin Mini Din (Male)

• 1 X VGAHDB 15-pin (Male)

Audio

To Console: 2 x USB (Type Mini B)

Port Selection: Push Button and Hot-Key Commands

Auto-Scan Intervals: 10 seconds

Keyboard State: Saved and Restored

Power Type: PS/2 Interface Power

Dimensions: 95 x 65 x 30 mm (3.7 x 2.6 x 1.2 in.)

Weight: 99 g (3.5 oz)

0º ~ 40ºC (32º ~104º F)Operating Temperature:

-20º ~ 60ºC (-4º ~ 140º F)Storage Temperature:

0%~90%, Non-Condensing

Humidity:

FCC and CECertifications:

KVM Cable: 2 Sets of 1.2M (4ft) KVM &Audio Cables

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Q5:

A5:

Where is the power supply? I did not find one in the box.

The TK-208K does not require a power supply. It draws power from

your computer's PS/2 connections.As long as your KVM switch is connected to

the PS/2 port, it will receive the necessary power to function.

I have the KVM switch connected properly, but my keyboard and mouse don't

work. Please make sure your PS/2 port is working properly by testing it with your

other PS/2 devices. Once you confirm that the PS/2 port is functional, please

reboot your computers, and try to use the KVM switch again.

Can I connect and disconnect the PS/2 cables while the computers are turned

on? Yes, you can connect or disconnect the PS/2 cables while the computers are

turned on because the PS/2 interface is Plug-and-Play and Hot-Pluggable.

Will the KVM switch remember the keyboard settings between computers?

Yes, the KVM switch will remember the keyboard settings when switching

between your computers. (i.e.: Cap lock, Num key, etc.)

How do I switch from one computer to another with the KVM switch?

You may switch between PCs by pressing the Push button on the KVM switch

or by using the Hot-Key commands.

If you have further questions, please contact TRENDnet’s Technical Support

Department.

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received.

Including interference that may cause undesired operation.

NOTE: THE MANUFACTURER IS NOTRESPONSIBLE FORANY RADIO ORTV

INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TOTHIS

EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’SAUTHORITYTO

OPERATE THE EQUIPMENT.

Troubleshooting

Limited Warranty

TRENDnet warrants its products against defects in material and

workmanship, under normal use and service, for the following lengths of

time from the date of purchase.

TK-208K - 2 Years Warranty

If a product does not operate as warranted above during the applicable

warranty period, TRENDnet shall, at its option and expense, repair the

defective product or part, deliver to customer an equivalent product or

part to replace the defective item, or refund to customer the purchase

price paid for the defective product. All products that are replaced will

become the property of TRENDnet. Replacement products may be new

or reconditioned.

TRENDnet shall not be responsible for any software, firmware,

information, or memory data of customer contained in, stored on, or

integrated with any products returned to TRENDnet pursuant to any

warranty.

There are no user serviceable parts inside the product. Do not remove

or attempt to service the product by any unauthorized service center.

This warranty is voided if (i) the product has been modified or repaired

by any unauthorized service center, (ii) the product was subject to

accident, abuse, or improper use (iii) the product was subject to

conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet office within

the applicable warranty period for a Return Material Authorization (RMA)

number, accompanied by a copy of the dated proof of the purchase.

Products returned to TRENDnet must be pre-authorized by TRENDnet

with RMA number marked on the outside of the package, and sent

prepaid, insured and packaged appropriately for safe shipment.
