TRENDnet TK-408K Bedienungsanleitung

TK-408K

Quick Installation Guide

English ......................................................................................................

Specifications ............................................................................................

Troubleshooting ........................................................................................

1. Before You Start

2. How to Connect .................................................................................

3. Using the KVM Switch .......................................................................

.................................................................................

Table of Contents

Version 05.04.06

System Requirements

Application

VGA or SVGA Compatible Monitor

6-pin Mini-Din PS/2 Keyboard

6-pin Mini-Din PS/2 Mouse

Speakers (optional)

Microphone (optional)

1. Before You Start

English

TK-408

4 x 3-in-1 Combo KVM Cable

4 x Audio/Mic Cable

Quick Installation Guide

Package Content

Microphone

LCD Monitor

4-Port PS/2 Audio

KVM Switch Kit

(TK-408K)

Keyboard Mouse

Speakers

Cables

PC 3 PC 4PC 1 PC 2

Cables Cables Cables

Connect the remaining end of the

3-in-1 Combo KVM Cable to an

available PC channel.

2. How to Connect

English

2. Connect the respective end of the

provided 3-in-1 Combo KVM

Cable and Audio/Mic Cable to

your computer.

Important: Power OFF all computers before making connections to the KVM

Switch.

Note: The included cables and KVM Switch connections are color coded for

your convenience.

1. Connect the shared Monitor,

Keyboard, Mouse, Microphone,

and Speakers to the Console Port

of KVM Switch.

Your installation is now complete.

5. Power ON the connected

computers and wait for the desktop

to appear.

4. Connect the remaining end of the

Audio/Mic Cable to the same

available PC channel.

To alternate between computers, you can use the Push Buttons on the KVM

Switch or the Hot-key commands via keyboard.

Hot-Key Commands

A keyboard hot-key command consists of three keystrokes:

Hot-Key command = ScrLk + ScrLk + Command key(s)

After pressing the ScrLk key, you have 2 seconds to press the ScrLk key again.

You then have another 2 seconds to press a command key. If you do not press

a key within 2 seconds, the switch will exit hot-key mode.

NOTE

1. Hotkey command works on top row numbers keys only.

2. When the binding of PC & Audio/Mic port switching is enabled by the hotkey

sequence,any PC and Audio/Mic switching are bound together.

3. For non-PnP OS(Linux, Windows NT 4.0), please use the following

commands to reset the mouse setting:

Hot-Key convention: The hotkey notation, denotes that you should hit the

individual key consecutively one at a time, not simultaneously.

3. Using the KVM Switch

English

ScrLk +ScrLk +M+1

ScrLk +ScrLk +M+2

ScrLk +ScrLk +M+3

2-key mouse setting:

3-key wheel mouse setting:

5-key wheel mouse setting:

Command Hot-Keys Description

Quick Reference Sheet for TK-408K

Select PC

Select Audio/Mic

Channel

Next higher PC

channel

Bind PC & Audio/Mic

Switching

Console Mouse/

Keyboard Reset

UnBind PC & Audio/

Mic Switching

Autoscan

Next lower PC

channel

Stop Autoscan

ScrLk ScrLk X

+ +

x = 1 ~ 2 for PC channel number

ScrLk ScrLk

+ +

(Arrow up)

ScrLk ScrLk

+ +

(Arrow down)

ScrLk ScrLk

+ + W

ScrLk ScrLk

+ + End

ScrLk ScrLk

+ + S

Press any key on keyboard

Select the active PC channel.

Select the active Audio/Mic channel

Select the next lower available computer

Enable the binding of PC port and Audio/Mic port

switching.

Reset mouse/keyboard on the console side. (works on

non-PnP OS only)

Disable the binding of PC port and Audio/Mic port

switching.

Autoscan through every connected channel for

quick screen browsing of each channel (scan delay

= 10 seconds).

Select the next higher available computer

Terminate Autoscan activity.

(Fx is a function key) FX=F1 ~ F4

ScrLk ScrLk

+ +

ScrLk ScrLk

+ +

English

Computer Connections: 4

KVM Cable Connectors

(all male):

Console Port Connectors

(all female):

Keyboard: PS/2 Keyboard 6-pin Mini Din

Mouse: PS/2 Keyboard 6-pin Mini Din

Monitor: VGA HDB 15-pin

Speaker: 3.5mm audio in/out jack

Microphone: 3.5mm microphone in/out jack

Specifications

To PC:

To KVM: 1 x VGA/SVGA HDB 15-pin

KVM

To PC:

Audio

To KVM:

Port Selection: Push Button and Hot-Key Commands

Auto-Scan Intervals: 5 seconds

Keyboard State: Saved and Restored

Power Type: PS/2 Interface Power

Dimensions: 167 x 80 x 28mm (6.6 x 3.2 x 1.1in.)

Weight: 178g (6.3oz.)

0º ~ 40ºC (32º ~104º F)Operating Temperature:

-20º ~ 60ºC (-4º ~ 140º F)Storage Temperature:

0%~90%, Non-Condensing

Humidity:

FCC and CECertifications:

KVM Cable: 4 sets of 1.8 M (6ft) KVM Cables

• 1 x PS/2 Keyboard 6-pin Mini Din

• 1 x PS/2 Mouse 6-pin Mini Din

• 1 X VGA HDB 15-pin

• 1 x 3.5mm audio in/out jack

• 1 x 3.5mm microphone in/out jack

• 1 x 3.5mm audio in/out jack

• 1 x 3.5mm microphone in/out jack

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Q5:

A5:

Where is the power supply? I did not find one in the box.

I have the KVM switch connected properly, but my keyboard and mouse don't

work.

Please make sure your PS/2 port is working properly by testing it with your

other PS/2 devices. Once you confirm that the PS/2 port is functional, please

reboot your computers, and try to use the KVM switch again.

Can I connect and disconnect the PS/2 cables while the computers are turned

on?

Will the KVM switch remember the keyboard settings between computers?

Yes, the KVM switch will remember the keyboard settings when switching

between your computers. (i.e.: Cap lock, Num key, etc.)

How do I switch from one computer to another with the KVM switch?

The TK-408K does not require a power adapter. It draws power from your

computer's PS/2 connections. As long as your KVM Switch is connected to the

PS/2 port, it will receive the necessary power to function.

Do not try to connect the KVM Switch to the computers while the computers

are in powered-on state, because the computers may have difficulty recognizing

your shared PS/2 keyboard and PS/2 mouse.

You may switch between computers by pressing the Push Buttons on the KVM

switch or by using the Hot-Key commands via keyboard. For a list of Hot-Key

commands, refer to the "Quick Reference Sheet for TK-408K".

If you still encounter problems or have any questions regarding the TK-408K, please

contact TRENDnet's Technical Support Department.

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received.

Including interference that may cause undesired operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV

INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS

EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO

OPERATE THE EQUIPMENT.

Troubleshooting

Limited Warranty

TRENDnet warrants its products against defects in material and

workmanship, under normal use and service, for the following lengths of

time from the date of purchase.

TK-408K - 2 Year Warranty

If a product does not operate as warranted above during the applicable

warranty period, TRENDnet shall, at its option and expense, repair the

defective product or part, deliver to customer an equivalent product or

part to replace the defective item, or refund to customer the purchase

price paid for the defective product. All products that are replaced will

become the property of TRENDnet. Replacement products may be new

or reconditioned.

TRENDnet shall not be responsible for any software, firmware,

information, or memory data of customer contained in, stored on, or

integrated with any products returned to TRENDnet pursuant to any

warranty.

There are no user serviceable parts inside the product. Do not remove

or attempt to service the product by any unauthorized service center.

This warranty is voided if (i) the product has been modified or repaired

by any unauthorized service center, (ii) the product was subject to

accident, abuse, or improper use (iii) the product was subject to

conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet office within

the applicable warranty period for a Return Material Authorization (RMA)

number, accompanied by a copy of the dated proof of the purchase.

Products returned to TRENDnet must be pre-authorized by TRENDnet

with RMA number marked on the outside of the package, and sent

prepaid, insured and packaged appropriately for safe shipment.

WARRANTIES EXCLUSIVE: IF THE TRENDnet PRODUCT DOES NOT

OPERATE AS WARRANTED ABOVE, THE CUSTOMER'S SOLE

REMEDY SHALL BE, AT TRENDnet'S OPTION, REPAIR OR

REPLACEMENT. THE FOREGOING WARRANTIES AND REMEDIES

ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES,

EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF

LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

TRENDnet NEITHER ASSUMES NOR AUTHORIZES ANY OTHER

PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN

CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR

USE OF TRENDnet'S PRODUCTS.

TRENDnet SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS

TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED

DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY

CUSTOMER'S OR ANY THIRD PERSON'S MISUSE, NEGLECT,

IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED

ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE

BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT,

FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW

TRENDnet ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY

LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING

NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT,

SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF

REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF

INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT

OF OR IN CONNECTION WITH THE SALE, INSTALLATION,

MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION

OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY

TO REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE PRICE

PAID, AT TRENDnet’S OPTION. THIS DISCLAIMER OF LIABILITY FOR

DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED

HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.

Governing Law: This Limited Warranty shall be governed by the laws of

the state of California.

AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1 Year

Warranty

Andere Handbücher für TK-408K

Inhaltsverzeichnis

Andere TRENDnet Schalten Handbücher

TRENDnet

TRENDnet TE-SK1 Bedienungsanleitung

TRENDnet

TRENDnet TE100-S5 Bedienungsanleitung

TRENDnet

TRENDnet TK-204UK - DVI USB KVM Switch Bedienungsanleitung

TRENDnet

TRENDnet TK-200K Bedienungsanleitung

TRENDnet

TRENDnet TEG-S240TX - DATA SHEETS Bedienungsanleitung

TRENDnet

TRENDnet TU-700 Bedienungsanleitung

TRENDnet

TRENDnet PoE Web Smart Switch Series Bedienungsanleitung

TRENDnet

TRENDnet TEG-448WS - Switch Bedienungsanleitung

TRENDnet

TRENDnet TEG-S081Fi Bedienungsanleitung

TRENDnet

TRENDnet TE100-S2424 Bedienungsanleitung

TRENDnet

TRENDnet TEG-224WSplus Bedienungsanleitung

TRENDnet

TRENDnet TI-PG541i Bedienungsanleitung

TRENDnet

TRENDnet TEG-S8 - Gigabit Switch Bedienungsanleitung

TRENDnet

TRENDnet TE100-S16plus Bedienungsanleitung

TRENDnet

TRENDnet TK-240DP Bedienungsanleitung

TRENDnet

TRENDnet TE100-S16D Bedienungsanleitung

TRENDnet

TRENDnet TE100-SK4 Bedienungsanleitung

TRENDnet

TRENDnet TEG-S41SX Bedienungsanleitung

TRENDnet

TRENDnet TU2-400E Bedienungsanleitung

TRENDnet

TRENDnet TE-910 Bedienungsanleitung

TRENDnet

TRENDnet TK-200K Bedienungsanleitung

TRENDnet

TRENDnet TE100-H5E Bedienungsanleitung

TRENDnet

TRENDnet TK-403KR Bedienungsanleitung

TRENDnet

TRENDnet TK-423K - USB/PS/2 KVM Switch Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
