TRENDnet TK-IP101 Bedienungsanleitung

kvm

The 1-Port KVM Switch over IP (TK-IP101) provides cost effective

remote server management for multiple users, regardless of server

status. Eliminate the need to physically be in the server room to

troubleshoot, reboot and edit pre-boot functions. Save resources and

manage server and PC resources from around corner or around the

world. Provides highly secure access to both Windows and Java-based

clients. With up to 16 active user accounts the TK-IP101 supports 4

concurrent logins. An intuitive Web user interface provides controls from

BIOS level functions to Windows based applications. Use the TK-IP101

with the TRENDnet's 8-Outlet Remote Power Controller (TK-RP08) to

facilitate remote power cycling and rebooting.

TK-IP101 (V1.0R)

1-Port KVM Switch over IP

TK-IP101(V1.0R)

rev:07.15.2008

•

Manage KVM switches and servers remotely over the Internet

Centralize management of multiple servers when connected to a conventional KVM switch

Save time and resources by managing resources remotely

Multiple user access control

Management of remote servers from BIOS level up to GUI level applications

Ultra secure access with full 1024-bit PKI authentication and 256-bit SSL encryption

Enjoy crisp 1600x1200 resolution

Intuitive Web user interface permits upgrades and backups

Supports user friendly Telnet sessions and FTP access

Use with TRENDnet's TK-RP08 to control on/off power cycling of multiple devices remotely

Works with LDAP, RADIUS and Active Directory Servers

Ethernet RJ-45 and Serial PPP connections supported

PPP connection over serial RS-232 interface with data rates up to 1 Mbps

Works with Windows® and Java-based clients for cross-platform compatibility

Low bandwidth Internet connections supported with JPEG compression

2-year warranty

FEATURES

Digital Connector

Server or KVM Port

Connectors

Remote Connections

Viewer Session

Serial Console Port (Front)

Video Resolution

Mouse Emulation

Keyboard Emulation

Remote Power On/Off

• 1

• RJ-45

• Multiple Connections [Shared/Private/View Only Session]

• 10/100 Base-T Connection With Auto-Sensing

• PS/2 And USB

• Yes*

• 1 x HDB 15-Pin Male + Special Cable Assembly Providing VGA, PS/2 Mouse And PS2 Keyboard Connectors.

• 1 x USB Type B

• RJ-12 Connector / 115200 Bps Max - Used Only For Console Management

• 1 × VGA HDB 15-Pin Female

• Shared/View Only – Multiple Users / Private – 1 User

• 1 x HDB15 (Integrated With PS/2 Keyboard And PS/2 Mouse

• PS/2 and USB

• 1600 × 1200 Max.

• 1 × PS/2 Keyboard 6-Pin Mini Din Female

Local Console Connectors

PC Port Connectors

Number of Server Ports

Hardware

• 1 × PS/2 Mouse 6 Pin Mini Din Female

• 1 x USB Type B (For USB Keyboard And USB Mouse)

Ethernet Interface

Serial Control Port (Back) • RJ-12 / 1Mpbs High-Speed Serial For Connect To External Modem/ Power Control Device

Server Control Remote Interface • Win32 Viewer / JAVA Viewer

Management • With Any Browser Connected To The Embedded Web Server Via HTTPS Secure Connection

Security • SSL, Encryption With 256-Bit Ephemeral Keys User Authentication Based On Password And PKI Certificates

Power Input • Dc 12V 2A

Operation Temperature • 0 ~ 50°C

Storage Temperature • - 20 ~ 60°C

Humidity • 0~90% RH, Non-Condensing

Housing • Metal / 0U

Dimension (L x W x H) • 16 x 11.5 x 2.5 Cm

Safety / EMI Certification • FCC, CE

TK-IP101(V1.0R)

rev:07.15.2008

TK-IP101 (V1.0R)

1-Port KVM Switch over IP

SPECIFICATIONS

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

PACKAGE CONTENTS

• TK-IP101

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

• 1 x Ethernet cable 1m – (3.3ft)

• CD-ROM (user's guide)

8-Outlet Remote Power Controller

8-Port USB/PS/2 Rack Mount KVM Switch w/ OSD

16-Port USB/PS/2 Rack Mount KVM Switch w/ OSD

• Multi-Language Quick Installation Guide

TK-RP08

TK-804R

TK-1604R

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

RELATED PRODUCTS

• 1 x RS-232 cable 1m – (3.3ft)

• Power adapter (9V DC 2mA)

TK-IP101 (V1.0R)

1-Port KVM Switch over IP

KVM 10/100Mbps

PS/2 Keyboard Mouse

PS/2

USB KVM Switch

(TK-803R)

8-Port Rack Mount

Workstations

16-Port 10/100Mbps

Fast Ethernet Switch

(TE100-S16)

Cable/DSL 4-Port

Broadband Router

(TW100-S4W1CA)

in France

Workstation

in Taiwan

Workstation

in USA

1-Port KVM

over IP Switch

(TK-IP101)

Internet

Monitor
