TRETTITRE TreSound mini Bedienungsanleitung
TreSound mini
©TRETTITRE. All Rights Reserved. Designed and developed by TTT.
If you encounter any issues or have any questions regarding your new product,
feel free to contact our helpful Customer Support Team. Your satisfaction is our goal!
Wenn Sie auf Probleme oder Fragen zu Ihrem neuen Produkt haben,
können Sie sich gerne an unser hilfsbereites Kundendienstteam wenden. Ihre Zufriedenheit ist unser Ziel!
Si vous rencontrez des problèmes ou avez des questions concernantnos nouveaux produits,
n’hésitez pas à contacter notre équipe d’assistance à la clientèle.
Votre satisfaction est notre objectif!
新製品に関して問題が発生したり、質問がある場合は、
お力添えできるカスタマーサポートチームにお気軽にお問い合わせください。あなたの満足が私たちの目標です！
TRETTITRE (SHENZHEN) TECHNOLOGY CO., LTD.
903-905, Bldg A, Zhonghengsheng Hightech Park, No.3, Xinyu Road, Baoan District, Shenzhen, CN
纯粹声学（深圳）科技有限公司
trettitre_officials
Trettitre
trettitre_sound
trettitre_sound
Trettitre
DISCOVER THE BEAUTY OF SOUND
ENGLISCH
• Make sure all items listed in <Box Contents> are included in the package.
• Avoid positioning your item in areas where there is high humidity, high heat, poor ventilation,
excessive dust, or where there will be excessive vibration.
Placement Guidelines:
For best Bluetooth performance, place your mobile device within 33 ft. (10m) of your speaker,
and make sure there is a clear line of sight between you and your speaker.
Moving your device farther away, or not having a clear line of sight may impact sound quality,
and your device may disconnect from your speaker.
• Keep other wireless equipment at least 3 ft. (1m) away from your speaker.
• Place your speaker and your device away from other audio/video components and direct heat
sources.
Box Contents
Lift the speaker carefully out of the packing.
When setting up your speaker, please consider the following precautions:
• The Speaker • USB-C Cable • User Guide
Bluetooth Pairing
Pairing Your Mobile Device. When you power on your speaker, the speaker
automatically searches for your mobile device.
Power On
Long press for 2 seconds: on / off
1 2
Power Button / Indicator
• Long press for 2 seconds: on / off; Auto off after 10 minutes of standby;
• Short press: switch ambient light effect; Three modes: 1. warm white; 2. gradient color; 3. off.
• Double click: pause / play.
Button
• Short press "+" : volume + ;
• Short press "-" : volume - ;
• Long press "+" for 2 seconds: next song;
• Long press "-" for 2 seconds: prev song.
menu BLUETOOTH
Bluetooth
Not connected
TreSound mini
Tip: In pairing mode: the orange indicator light flashes rapidly;
Pairing successful: the orange indicator light remains on.
1. On your device, turn on the Bluetooth feature.
Tip: The Bluetooth feature is usually found in the Settings menu.
2. Select your [ TreSound mini ] speaker from the device list.
TWS PairingTWS Pairing
Support only 2 devices, support left and right channels stereo;
TWS pairing distance <10m
3 3
Tips: In pairing mode: the orange indicator light flashes slowly;
Pairing successful: the orange indicator light remains on.
Connecting & pairing
1. Connecting Bluetooth to any speaker;
2. Press the pairing buttons of the two speakers respectively. The devices will automatically pair
with each other.
3. After successful pairing, the speakers can be restarted to keep the pairing.
Disconnect pairing
Press the pairing button of any speaker to disconnect the pairing.
Pairing Button
• Short press: TWS pairing on/off.
• Long press for 2 seconds: Bluetooth reset.
• System reset.
Reset
4
Charging Instructions
When the orange ambient light is flashing, the device needs to be charged.
Tips:
Charging after power off: the green ambient light flashes,
and the green ambient light remains on when charging is complete.
Charging while in use: the ambient light is displayed in the corresponding user setting mode.
It is recommended to use the original USB-C power cable of
TRETTITRE for charging. Using other cables may cause the
device to fail to work properly during charging.
Power level≦20%: Orange ambient light flashes slowly.
Power level ≦5%: Orange ambient light flashes rapidly.
The TreSound mini's battery level can be displayed on your phone.
When the battery runs out and turns off automatically, to protect the battery,
please charge it for 10 minutes before turning it on again.
2h
0% 100%
USB-C 5V/3A
Reconnecting a Device
When powered on, your speaker tries to reconnect with the one most recently
connected device.
5
Note: The devices must be within range and powered on.
TreSound mini
Product Diagram
Power Button / Indicator
Tweeter × 1
Woofer × 1
Passive Radiators × 1
Metal Cabinet
Base
Ambient Light
Power Input
Pairing Button
+/-Button
Reset
Specifications
Input
Capacity
Charging Time
Bluetooth
Speaker
Sound Direction
TWS Pairing
Woofer Sensitivity
Max SPL
Frequency Response
THD
RMS
Material
Size
Weight
USB-C 5V/3A
5200mAh
2h
5.3
1*1.0"Tweeter, 1*2.75"Woofer
360° Surround Sound
1+1
83dB
>92dB
50Hz-20KHz
<5%
30W
Metal + ABS
168*168*252mm
1kg
MADE IN CHINA
FAQ / Troubleshooting
PROBLEM SOLUTION
No power
Speaker does not pair
with a mobile device
No sound
Poor sound quality
• Check if the power is connected correctly.
• Check whether the power adapter is damaged.
• Check whether the speaker is fully charged.
• On your mobile device, turn the Bluetooth feature off and then on.
Remove your speaker from the Bluetooth list on your device. Pair
your device again.
• Pair a different device.
• Clear your speaker's pairing list. Pair your device again.
• On your mobile device, turn the Bluetooth feature off and then on.
Remove your speaker from the Bluetooth list on your device. Pair
your device again.
• Increase the volume on your speaker, your device and music source.
• Use a different music source.
• Pair a different device.
• Use a different music source.
• Pair a different device.
• Increase the volume on the device.
• Check device audio settings.
• Clean the surface of the speaker with a soft, damp cloth (water only).
• Do not use any sprays near the speaker.
• Do not use any solvents, chemicals, or cleaning solutions containing
alcohol, ammonia or abrasives.
• Do not allow liquids to spill into any openings.
MAINTENANCE
Warranty
TRETTITRE warrants all products to be of the highest quality in material, craftsmanship and
service, effective from the date of purchase to the end of the warranty period.
This warranty extends only to personal use and does not extend to any product that has been
used for commercial, rental, or any other use in which the product is not intended for. There are
no warranties other than the warranties expressly set forth with each product.
This warranty is non-transferable. TRETTITRE is not responsible in any way for any damages,
losses or inconveniences caused by equipment failure caused by user negligence, abuse, or
noncompliance with the user manual or non-compliance with any additional safety
recommendations or warnings included in the product packaging and manual.
What is not covered by the warranty:
1. The warranty immediately becomes void if the product has been tampered with, repaired or
modified by non-authorized personnel.
2. Damage (accidental or otherwise) to the product that does not impact the product's
operation, including but not limited to rust, change in color, texture or finish, wear and tear,
and gradual deterioration is not covered.
3. Damage caused by accident, abuse, natural disaster, intentional or accidental misuse, fire,
neglect or improper maintenance, and use under abnormal conditions is not covered.
4. Products that have exceeded the warranty service period stipulated by our company are not
covered.
5. The warranty immediately becomes void if the original serial number is removed, obliterated
or altered from the product.
6. Packaging and attached accessories, services and additional configurations other than those
promised by the salesperson are not covered.
7. The warranty immediately becomes void if the instructions in the user manual are not
followed.
中文 本機附件
請小心地從包裝裡取出音箱，避免碰撞。
放置原則：
•
•
設置揚聲器時，請考慮以下注意事項：
•
•
藍牙
藍牙
未連結
藍牙連接
啟動揚聲器時，揚聲器會自動搜尋行動裝置。
開機
長按2秒：開機 / 關機
1 2
電源開關/指示燈 鍵
•
•
•
•
•
•
•
TWS 配對TWS 配對
僅支援2台設備，支援左右聲道立體聲；TWS配對距離<10米。
3 3
配對鍵
復位孔
連接配對
斷開配對
•
•
•
