Trilogy Touch Technology T3-HB15A1 Bedienungsanleitung

Trilogy Touch Technology

15” Chassis Touch Screen Monitor

T3-HB15A1

Table of Contents

GETTING STARTED 1

Introduction

Features

Unpacking and Checking of the Package Contents

Accessories Included

System Requirements

Mounting

Using Input

INSTALLING THE MONITOR 3

Connecting the Monitor

OPERATING THE MONITOR 4

Adjusting the Viewing Angle

Operating Procedure

Additional information about the On-Screen-Display

Menu Table

FOR YOUR SAFETY 8

SPECIAL NOTES ON LCD MONITORS 9

Cleaning

Power Management

Supported Timing

Troubleshooting Procedures

CONFORMITY AND COMPLIANCE 12

PRODUCT SERVICE AND SUPPORT 13

Contact Information

Warranty

The information contained in the document is subject to change without

notice. Nor does the contained information constitute a warranty, either

expressed or implied or as an obligation by Trilogy Touch Technology.

Trilogy Touch Technology shall not be liable for the accuracy of the

information, fitness for purpose or direct or indirect consequential damages.

Patents, patents under application, trademarks, copyrights and other

intellectual property rights may cover the information in this document.

Manufacturers or products mentioned in this document have their own

respective trademarks.

Page 1

GETTING STARTED

WARNING: Do not operate the LCD Monitor with an unknown utility power voltage source. Usage of incorrect

voltage may cause malfunctions and could cause fire or electric shock.

INTRODUCTION

Thank your for your selection of this Trilogy Touch Technology product. Bright and sharp images of text and graphics

are what you will find with your LCD Monitor. This product provides multiple resolutions with a flicker-free, sharp, and

vibrant color display, without the radiated emission and hazards of CRT monitors.

FEATURES

•Panel control functions

•Support for XGA resolution of 1024x768 pixels

•Wide viewing angle

•Wide tilting angle

•VESA DPMS power saving feature: powers off the monitor after a defined period of inactivity.

•Digital Character Smoothing

•Automatic Set-Up

•Windows 95/98/2000/XP Plug & Play Compliant

•Versatile, functional & User friendly OSD

•Plug & Play: Conforms to the VESA standards and support DDC1/2B specification

•Meets Energy Star guidelines for power management

•UNPACKING AND CHECKING OF THE PACKING CONTENTS

•Before unpacking your LCD Monitor, prepare a stable, level, and clean surface near a wall outlet. Set the LCD

Monitor box in an upright position and open from the top of the box before removing the right/left cushions.

It is highly recommended that all packaging materials be retained in the event that service is required.

ACCESSORIES INCLUDED

1 pc 1 pc 1 pc 1 pc 1pcs

VGA

Cable Driver

CD Power

Cord User’s

Manual

USB or

RS232

cable

Page 2

SYSTEM REQUIREMENTS

The following are basic requirements for using the Monitor. Please check the specifications and Supported Video

Timing section of this Users Guide for specifics.

•This monitor requires connection to a personal computer. Both industry standard architecture and Macintosh

hardware is supported.

•Various Operating System versions are supported for input operation. Please check the product features and

specifications to insure that the OS you intend to use is supported. The included software installation disc

contains the proper drivers for supported Operating Systems and devices.

•An analog, VESA standard video card for the PC is required. This monitor complies with DPMS and Plug &

Play (DDC) standards.

•The personal computer will require either a standard 9 pin serial COM port or USB port, depending on the

product version of the monitor. If the serial COM port is a 25 pin, D-connector, then an adaptor to 9-pin male

is required. In addition, consideration should be given to system IRQ assignments for serial operation, as the

controller cannot share an IRQ.

•There should be enough electrical outlets to support the system installation. This would include the

calculation of total current requirements. Although not a strict requirement, a surge protected power source

is recommended.

USING TOUCH INPUT

The surface of this LCD Monitor is a sensor. Some degree of caution is required to insure the effectiveness and long

life as an input device. Avoid using sharp objects such as pens, pencils, scissors or screwdrivers as a pointing stylus.

After installation of the driver software, a calibration should be performed. This action insures that the graphic

coordinates match the coordinates, sometimes called mapping.

Different software applications may require specific “mouse click” parameters. The control panel will allow selection

of multiple types of mouse button actions.

Page 3

INSTALLING THE MONITOR

•DO NOT install the monitor in areas where sudden temperature changes may occur, or in humid, dusty, or

smoky environments as it may cause fire, electric shock or damage.

•DO NOT expose this product to rain, water, moisture, or sunlight

•MAINTAIN good ventilation; covering of ventilation slots or holes may cause a fire

•PLACE the monitor at least 4” (or 10 cm) way from the walls

•SAFE storage temperature of the LCD Monitor is in a range of -20 to +65

•Install the software drivers via the supplied CD following standard operating system procedures

NOTE

Remember that the connection of USB devices is done after the software drivers are loaded. Further

instructions are provided during software installation and through the Help files on the driver CD.

CONNECTING THE MONITOR

1. Turn off the PC and the LCD Monitor before making any connections.

2. Use the supplied VGA cable to connect the VGA connector of the LCD Monitor to the VGA port of the PC

system.

3. Connect the male end of the power cord into a wall socket and the female end to the Monitor.

4. If your Monitor has a USB interface, use the supplied USB cable to connect the USB connector of LCD

Monitor to the USB port of the PC system. Remember to follow proper software driver installation.

5. If your Monitor has a RS232 serial interface, unplug the PC keyboard and reconnect it to the supplied serial

cable power adaptor. Connect the other end of the adaptor to the keyboard connector on the PC. Connect

the serial D-connector to and standard PC serial comport. Connect the other end or the serial interface cable

to the Monitor.

6. Turn on your computer, and then turn on your LCD Monitor.

NOTE

For added protection, it is recommended to use a Surge Protection device plugged between the AC Adapter

and the electrical wall outlet to prevent the effects of sudden current variations from reaching the LCD

Monitor. Sudden peaks of electricity may cause damage to the Monitor.

uuPower Plug the power cord in.

vvInput 1 Connect with detachable VGA cable.

wwInput 2

(Touch Function)

Connect to USB/RS232 cable

Page 4

OPERATING THE MONITOR

Users can adjust the picture to the desired brightness and sharpness by following these instructions. The adjustment

buttons utilize a security feature that required the use of a paper clip or pin to activate each selection. This is

accomplished through pinholes in each button except the power on/off.

1Power Switch Power On/Off

2Auto Automatically optimize positions, phase &

clock when OSD is not shown

3Exit / Exit the OSD menu when OSD is shown

4 / Selection or adjustment when OSD is

shown/Quick brightness adjustment

5 / Adjustment when OSD is shown/Quick

contrast adjustment

6Menu Enter OSD/Access sub-menu & selection

Page 5

HOW TO USE THE OSD (ON SCREEN DISPLAY)

The OSD function allows the user to easily adjust the display to the desired requirements. The OSD menu includes a

main menu and sub-menus.

OPERATING PROCEDURE

Use the buttons on the right side control panel to adjust the OSD (see Operating the Monitor).

TO MAKE OSD ADJUSTMENTS:

1. Power on the LCD Monitor.

2. Press “MENU” button to pop up the OSD menu.

3. Press “+” or “-” button to select menu item.

4. Press “MENU” button to select sub-menu.

5. Press “+” or “-” button to select sub-menu item.

6. Press “EXIT” button when finished adjusting and accept the user setting.

7. Press “Auto” button to process auto tune function.

ADDITIONAL INFORMATION ABOUT THE ON SCREEN-DISPLAY

•The OSD disappears (times-out) several seconds after you stop pressing the buttons while performing an

adjustment. This function can be adjusted up to 60 seconds allowing the user more time. This adjustment is

Input Source Selection (optional)

Source Resolution & Frequency

Status

Language

Settings

Image Adjustment

Volume Adjustment

Color Temp. Selection

Color Temp. Status

Input Source Status

Current Audio Status

Page 6

Brightness Press the Brightness Button (3) when the Menu

is not displayed.

Contrast: Press the Contrast Button (2) when the Menu is

not displayed.

Auto

Setting:Press the Auto Button (5) when the Menu is not

displayed.

made in the “Settings” submenu.

•Any changes made are automatically saved in the Monitor memory when the OSD disappears. Turning off the

power should be avoided while using the OSD, as this may not allow changes to be saved.

•Adjustments for clock, phase and positions are saved for each signal timing or screen resolution. Except for

these adjustments, all other adjustments have only one setting that applies to all signal timing.

•The submenu color will change from white to pink when the function is selected.

•You can skip the OSD menu and display commonly used adjustment scales directly by using the following

button operations (refer to previous diagram for button locations):

The Auto Adjust process may take as much as 10 consecutive seconds. The display image will make noticeable

changes as the Auto Adjust function completes.

SELF-TEST CHECK:

This product provides a self-test ability, through which you can check whether the LCD monitor functions are working

properly. If your LCD monitor is properly connected, but there is no image showing and the power indicator light on the

Monitor displays orange, please follow the steps below:

1. Turn off both the computer and LCD monitor.

2. Unplug the video signal connector from the back of the computer.

3. Turn the LCD monitor on.

The monitor should display “No Signal Input” on the screen and the power LED indicator should be orange. If no

display is observed, there may be a problem with the Monitor.

Turn off the LCD monitor and reconnect the signal cable, then turn the computer and LCD monitor on. As the

computer boots, there should be a video display and the power LED should now be green. If the LED of the monitor is

an orange color after completing the steps above, please check your VGA card and computer system.

Page 7

MENU TABLE

Primary
