Tripp Lite SRCOOL12K Bedienungsanleitung

120V Portable Air Conditioning Unit for IT

Equipment in Small Server Rooms and Network

Closets

MODEL NUMBER: SRCOOL12K

Description

With 12,000BTU of cooling power, the 120V, 60 Hz SRCOOL12K is ideal for use in data centers, server and

wiring closets, IT environments, home and small business offices, conference rooms, warehouses,

entertainment centers or other venues with heat-sensitive equipment, particularly in areas that facility air

conditioning can't reach. The SRCOOL12K not only adjusts ambient room temperatures, but can also dehumidify

and filter the air, providing better air quality for enhanced equipment performance with minimal noise and power

consumption.

The SRCOOL12K has a built-in evaporator that expels the condensed water through the exhaust duct, so there

is no need for a drain tube, drain pan or water collection tank. Both a standard louvered vent (for general room

cooling) and a directional ducted cooling vent (to direct cold air where most needed) are provided. A directional

exhaust duct safely removes hot air from the room. SRCOOL12K comes equipped with an auto-restart feature

that retains all system settings and returns the unit back to its last operational state after AC power is restored. A

built-in timer enables the unit to be programmed for unattended start-up and shutdown. Controls and displays

are conveniently mounted on the top panel. With the optional added accessory of the SRCOOLNET, this

communication port allows users to monitor temperatures, receive alerts, review logs and control settings from

any location. Designed for quick and simple installation, the SRCOOL12K rolls into place on built-in casters and

plugs into a standard 5-15R outlet with no adapter required. An included window/drop ceiling kit provides multiple

installation options.

The SRCOOL12K uses environmentally friendly R410a refrigerant, which complies with EPA standards for 2010

and beyond, and is accepted worldwide. It contains zero, ozone depleting R22 refrigerant that has been banned

by the EPA for new equipment manufactured after January 1, 2010.

Features

Highlights

Compact, portable, self-contained

design reduces

maintenance—no water

collection tank or drain required

Rolls into place on built-in

casters; does not require an

external condenser, refrigerant

piping or hiring outside

contractors

Offers both hot-spot and general

room cooling with two

exchangeable vent styles

Filters and dehumidifies air to

protect equipment

Auto-restart feature retains all

system settings and returns unit

back to its last operational state

after AC power is restored

Allows users to remotely monitor

and control temperatures, alerts,

logs and settings from any

location with an Internet

connection (requires

SRCOOLNET accessory)

Applications

Supplemental cooling for confined

server rooms where the facility HVAC

is inadequate or unavailable.

Package Includes

SRCOOL12K cooling unit

Louvered front vent

Directional front vent

Cold Air directional delivery tube

Hot exhaust air removal tube

Dropped ceiling or window heat

ventilation kit

Warranty information

Instruction manual

1 / 4

12,000 BTU of cooling power can cool a 500 square foot room

Uses environmentally friendly R410a refrigerant (Contains no ozone depleting R22 refrigerant which has been banned by the U.S. EPA in new

equipment after January 1, 2010)

No water collection tank required. A built-in evaporator expels condensate into the exhaust air stream meaning no drain tube, drain pan or water

collection tank that needs to be emptied every few hours

Cold air output can be precisely directed through a 71" flexible tube to the 'hot spot' for better, faster cooling. (Standard louvered insert is also included

for general room cooling)

Auto-restart feature retains all system settings and returns the unit back to its last operational state after AC power is restored

Communication port allows users to remotely monitor and control temperatures, alerts, logs and settings from any location with an Internet connection

(requires SRCOOLNET accessory)

Compact, portable, self-contained design; ideal for IT, industrial, commercial and similar applications

Quick and easy installation. Plugs into a standard 5-15R outlet; no adapter required

Window/drop ceiling installation kit is included for extracting heat

Offers 3 different cycles (cool, dehumidify and fan)

Cools in confined spaces where facility air conditioning can't reach

Dehumidifies and filters air to promote more efficient equipment performance

Built-in timer for automatic unattended start-up and shutdown

System lock function disables all other buttons to prevent accidental input

Quiet operation with minimal power consumption

Convenient top-mounted controls and displays

120V AC input, 60 Hz frequency compatibility

Specifications

OVERVIEW

Model Type Active Cooling

INPUT

Nominal Input Voltage(s) Supported 120V AC

Electrical Consumption 1250 Watts Max

Input connection type NEMA 5-15P

Input cord length (ft.) 6

Input cord length (m) 1.83

LEDS ALARMS & SWITCHES

Front panel LEDs Touch sensitive control panel with multiple LEDs and numerical temperature readout

PHYSICAL

Shipping Dimensions (HWD/in) 33.46 x 15.16 x 29.13

Shipping Dimensions (HWD/cm) 85 x 38.5 x 74

2 / 4

Shipping weight (lbs) 83

Shipping weight (kg) 37.65

Unit Dimensions (HWD/in) 30.63 x 11.81 x 19.88

Unit Dimensions (HWD/cm) 77.8 x 30 x 50.5

Unit weight (lbs) 73.9

Unit weight (kg) 33.5

Material of construction ABS

Color Black

Form factors supported Tower

ENVIRONMENTAL

Cooling Capacity 12,000 BTU / 3.5 kW

SPECIAL FEATURES

Dehumidifier 2.5lbs / hour

Compressor Type Rotary

Refrigerant R410a (Environmentally friendly, Non ozone depleting)

Refrigerant Amount 22 oz.

Air Flow Evaporator = 329 CFM / Condenser = 311 CFM

Amp Draw Nominal 10.5A

Sound Level (Noise) 57dB

Air Supply Tube Length 71 inches

Air Exhaust Tube Length 118 inches

Air Exhaust Tube Diameter 5.16 inches

CERTIFICATIONS

Certifications Tested to UL484; CSA, RoHS

WARRANTY

Product Warranty Period (Worldwide) 1-year limited warranty

Optional Coverage Extended Warranty options available (WEXT3-SRCOOL12K = 2-year extension, WEXT5-SRCOOL12K = 4-year

extension)

Related Items

Optional Products

Model Number Description Qty.

3 / 4

WEXT3-SRCOOL12K 3-Year Extended Warranty (2-Year Extension) for SRCOOL12K 1

WEXT5-SRCOOL12K 5-Year Extended Warranty (4-Year Extension) for SRCOOL12K 1

SRCOOLNET Power Management Tools - External SNMP/Web Card Module 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at:

http://www.tripplite.com/sku/SRCOOL12K.

Specifications are subject to change without notice. Photos may differ slightly from final products.

4 / 4
