Tripp Lite Products Ensure 100% Availability—and

Profitability—Through Blackouts and More . . .

Kiosk operators rated blackouts as the #1 threat to kiosk availability in a 2002

Kiosk Business study. Tripp Lite UPS Systems eliminate this threat to your profitability

by supporting and protecting components through blackouts and all power problems.

Backed by an 80-year history of trusted reliability, Tripp Lite offers a convenient,

single-source solution for protecting, managing and connecting all kiosk and P.O.S.

components. All Tripp Lite products offer premium quality at value pricing, allowing

you to upgrade installations without compromising your budget. In addition, with

Tripp Lite products protecting and supporting key components throughout your

installation, you save money by reducing costly service calls or "truck rolls."

200211103 95-2326

Trust the Kiosk Industry Experts Who Trust Tripp Lite!

Return-on-Investment (ROI)

Power outages and service lockups are common and costly. Tripp Lite UPS Systems with WatchDog Service

Monitoring/Rebooting Software pay for themselves by supporting your kiosks through just one power outage

or eliminating just one service call.

Save with Tripp Lite by Eliminating Revenue Loss Due to Downtime

Save tens of thousands of dollars per year in potential revenue loss by eliminating downtime with a Tripp Lite UPS System.

Example: sales kiosks in a retail environment Example Your Data

A. Power outages per year: 24 outages/year

B. Downtime per power outage: x 2 hours/outage

C. Downtime per year: = 48 hours/year

D. Revenue loss per hour of downtime: x $50/hour

E. Total yearly revenue loss per kiosk: = $2,400/kiosk

F. Installation size: x 10 kiosks

G. Total yearly revenue loss per installation: = $24,000/installation

Save with Tripp Lite by Eliminating Service Costs

Save thousands of dollars per year in potential service costs by eliminating the threat of kiosk lockups with a Tripp Lite UPS System

and WatchDog Software.*

Example: remote informational kiosks Example Your Data

A. Service lockups per year: 5 - 10 lockups/year

B. Cost of service call: x $150/call

C. Total yearly service costs per kiosk: = $750 - $1,500/kiosk

D. Installation size: x 10 kiosks

E. Total yearly service costs per installation: = $7,500 - $15,000/installation

* Comparable solutions require the installation of a separate UPS system and rebooting device. The only hardware required for installation in Tripp Lite's solution is the UPS system—saving valuable

space and costing hundreds of dollars less.

The policy of Tripp Lite is one of continuous improvement. Specifications are subject to change without notice. Actual product may differ slightly from photos.

All trademarks are the property of their respective owners.

200211103--Kiosk Applications brochure--9.qxd 6/19/2003 12:25 PM Page 1

4 Port Serial-to-USB Adapter

(U209-004) upgrades older serial

components

Short-length, right-angle cable

(U005-10I) minimizes space and

maximizes ease-of-use

Tripp Lite offers hundreds of cables and

adapters for every component interface

(USB, FireWire®, PC/Mac, Cat6/5e, Fiber

Optic, SCSI and more) which deliver

premium quality at competitive pricing,

allowing you to upgrade installations

without compromising your budget.

TRIPP LITE HAS A RELIABLE, COST-EFFECTIVE SOLUTION . . . . . . FOR ALL COMPONENTS

TRIPP LITE HAS A RELIABLE, COST-EFFECTIVE SOLUTION FOR AL

Surge Suppressors &

Multiple Outlet Strips

Surge Suppressors

protect against surge

damage and line

noise distortion

Multiple Outlet Strips offer

convenient sources for power

Tripp Lite Surge Suppressors protect

components against damaging surges and

disruptive line noise, backed by up to

$250,000 Ultimate Lifetime Insurance and

Data Recovery Warranty on select models.

Select models also feature tel/modem surge

protection. Mount models anywhere inside

or outside kiosk enclosures or P.O.S. areas.

DCables & Adapters

NEW! INDUSTRY EXCLUSIVE!

SmartPro®550 USB WatchDog UPS System (Model: SMART550USBWD)

The Only Single-Purchase Solution For 100% Availability

• Completely safeguards equipment against two common causes of costly downtime—

blackouts and computer service lockups

• Saves money—provides two availability products for less than the price of a single solution

Includes a UPS System . . .

Eliminates downtime

due to blackouts

Protects against surge

damage and line noise

distortion

Saves space with

small footprint cabinet

Provides 550VA

capacity to support

all components

Reliable battery backup supports critical components

through blackouts. Built-in surge suppression and line noise

filtering (on both the AC and tel/DSL lines) safeguard all

components against damage and audio/video distortion.

Automatic Voltage Regulation supports components through

low voltage (brownouts) indefinitely. $50,000 Ultimate

Lifetime Insurance protects connected equipment against

surge damage, for life! PowerAlert Software, included,

provides remote power rebooting, automatic system

shutdown thresholds and power quality monitoring.

PowerAlert offers web/wireless management and supports

every operating system, including major Linux®

distributions.

. . . & WatchDog Service

Monitoring/Rebooting Software

Eliminates downtime due to

computer service lockups

Saves space—utilizes UPS

for system reboot,

eliminating the need for a

separate hardware device!*

Automatically reboot

locked-up or poorly

performing system service

applications. Set CPU-

and memory-usage

thresholds and monitor

service performance in

one application. Together with the UPS System, WatchDog

Software eliminates the #1 reason for costly service

calls—the need to reboot locked systems.** If a locked

system service cannot be rebooted, WatchDog Software

will automatically direct PowerAlert Software (included

with the UPS System) to reboot the computer and

connected equipment by powering down and restarting

the UPS System.†

* Comparable solutions require the installation of a separate UPS system and rebooting

device. The only hardware required for installation in Tripp Lite's solution is the UPS

system—saving valuable space and costing hundreds of dollars less. ** Server Technology

study. †WatchDog Software supports Windows®NT, 2000 and XP systems.

MMMM

Benchmarking

Interface

Configuration

Interface

Model:

TLP808

Model:

TLP604TEL

Model: PS2408

Complete Line of Low-Profile UPS Systems Also Sold Separately

Tripp Lite also offers a full line of UPS Systems fully compatible with WatchDog Software (with

capacities from 300 to 10,000VA) to protect PCs, workstations and servers inside or outside of kiosk

and P.O.S. environments. Open-frame UPS solutions are also available to volume customers. An open,

modular UPS architecture (without a case) can be configured to your specific space and runtime

requirements. Contact Tripp Lite for details.

Model:

INTERNETOFFICE500

Model: SMART450RT

Tripp Lite Products Installed in a

Typical Kiosk Application

WatchDog Software Also Sold Separately

Purchase WatchDog Software separately for use with most Tripp Lite UPS Systems to build a complete protection and

availability solution, or use WatchDog Software as a stand-alone application. Contact Tripp Lite for details.

Model: WATCHDOGSW

Model: U209-004

Model: N001-005-BL Model: U005-10I

Model: SMART550USBWD

200211103--Kiosk Applications brochure--9.qxd 6/19/2003 12:46 PM Page 3

4 Port Serial-to-USB Adapter

(U209-004) upgrades older serial

components

Short-length, right-angle cable

(U005-10I) minimizes space and

maximizes ease-of-use

Tripp Lite offers hundreds of cables and

adapters for every component interface

(USB, FireWire®, PC/Mac, Cat6/5e, Fiber

Optic, SCSI and more) which deliver

premium quality at competitive pricing,

allowing you to upgrade installations

without compromising your budget.

TRIPP LITE HAS A RELIABLE, COST-EFFECTIVE SOLUTION . . . . . . FOR ALL COMPONENTS

TRIPP LITE HAS A RELIABLE, COST-EFFECTIVE SOLUTION FOR AL

Surge Suppressors &

Multiple Outlet Strips

Surge Suppressors

protect against surge

damage and line

noise distortion

Multiple Outlet Strips offer

convenient sources for power

Tripp Lite Surge Suppressors protect

components against damaging surges and

disruptive line noise, backed by up to

$250,000 Ultimate Lifetime Insurance and

Data Recovery Warranty on select models.

Select models also feature tel/modem surge

protection. Mount models anywhere inside

or outside kiosk enclosures or P.O.S. areas.

DCables & Adapters

NEW! INDUSTRY EXCLUSIVE!

SmartPro®550 USB WatchDog UPS System (Model: SMART550USBWD)

The Only Single-Purchase Solution For 100% Availability

• Completely safeguards equipment against two common causes of costly downtime—

blackouts and computer service lockups

• Saves money—provides two availability products for less than the price of a single solution

Includes a UPS System . . .

Eliminates downtime

due to blackouts

Protects against surge

damage and line noise

distortion

Saves space with

small footprint cabinet

Provides 550VA

capacity to support

all components

Reliable battery backup supports critical components

through blackouts. Built-in surge suppression and line noise

filtering (on both the AC and tel/DSL lines) safeguard all

components against damage and audio/video distortion.

Automatic Voltage Regulation supports components through

low voltage (brownouts) indefinitely. $50,000 Ultimate

Lifetime Insurance protects connected equipment against

surge damage, for life! PowerAlert Software, included,

provides remote power rebooting, automatic system

shutdown thresholds and power quality monitoring.

PowerAlert offers web/wireless management and supports

every operating system, including major Linux®

distributions.

. . . & WatchDog Service

Monitoring/Rebooting Software

Eliminates downtime due to

computer service lockups

Saves space—utilizes UPS

for system reboot,

eliminating the need for a

separate hardware device!*

Automatically reboot

locked-up or poorly

performing system service

applications. Set CPU-

and memory-usage

thresholds and monitor

service performance in

one application. Together with the UPS System, WatchDog

Software eliminates the #1 reason for costly service

calls—the need to reboot locked systems.** If a locked

system service cannot be rebooted, WatchDog Software

will automatically direct PowerAlert Software (included

with the UPS System) to reboot the computer and

connected equipment by powering down and restarting

the UPS System.†

* Comparable solutions require the installation of a separate UPS system and rebooting

device. The only hardware required for installation in Tripp Lite's solution is the UPS

system—saving valuable space and costing hundreds of dollars less. ** Server Technology

study. †WatchDog Software supports Windows®NT, 2000 and XP systems.

MMMM

Benchmarking

Interface

Configuration

Interface

Model:

TLP808

Model:

TLP604TEL

Model: PS2408

Complete Line of Low-Profile UPS Systems Also Sold Separately

Tripp Lite also offers a full line of UPS Systems fully compatible with WatchDog Software (with

capacities from 300 to 10,000VA) to protect PCs, workstations and servers inside or outside of kiosk

and P.O.S. environments. Open-frame UPS solutions are also available to volume customers. An open,

modular UPS architecture (without a case) can be configured to your specific space and runtime

requirements. Contact Tripp Lite for details.

Model:

INTERNETOFFICE500

Model: SMART450RT

Tripp Lite Products Installed in a

Typical Kiosk Application

WatchDog Software Also Sold Separately

Purchase WatchDog Software separately for use with most Tripp Lite UPS Systems to build a complete protection and

availability solution, or use WatchDog Software as a stand-alone application. Contact Tripp Lite for details.

Model: WATCHDOGSW

Model: U209-004

Model: N001-005-BL Model: U005-10I

Model: SMART550USBWD

200211103--Kiosk Applications brochure--9.qxd 6/19/2003 12:46 PM Page 3
