Triz TZ3200C Bedienungsanleitung

TZ3200C
ADSL Bridge/Router Ethernet Modem
User’s Guide

Doc. No. TZ3200C_MN_Ver1.0 Rev 0 2 / 22
TZ3200C ADSL Ethernet Modem User’s Manual
|Copyright |
CopyrightⓒTriz Communications Group All rights Reserved.
No Part of this book shall be reproduced, stored in a retrieval system, or transmitted by any means,
electronic, mechanical, photocopying, recording, or otherwise, without written permission from
the publisher.
The specifications and information regarding the products in this manual are subject to change
without notice.
|Trademark Credit |
Triz is registered trademark of Triz Communications Group.
Windows is registered trademark of Microsoft Corp.
Triz Communications Group.
1F Oh-Bok Bldg, 279-23 Seongsu 2-ga 3-dong,
Seongdong-gu, Seoul, Korea 133-832
Direct TEL:+82-2-2129-9200
Direct FAX:+82-2-2129-9292

Doc. No. TZ3200C_MN_Ver1.0 Rev 0 3 / 22
TZ3200C ADSL Ethernet Modem User’s Manual
Scope
This guide describes the procedure to configure TZ3200C and the usages of the
Web configuration pages.
Organization
This guide is organized as follows:
Chapter 1 Introduction, introduces the TZ3200C ADSL Bridge/Router Ethernet
modem, defines the scope of the document, and provides a brief overview of the
functions of the Windows driver.
Chapter 2 Installation and Setup, describes how to install TZ3200C ADSL
Bridge/Router Ethernet modem.
Chapter 3 Configuring the TZ3200C, provides the descriptions and usages for
the TZ3200C ADSL Bridge/Router Ethernet modem‘s Web configuration pages.
Appendix A Troubleshooting, describes some problems that you might have with
the TZ3200C and how to isolate and possibly solve these problems.
Appendix B Technical Specifications, lists the hardware and software
specifications for the TZ3200C.
Appendix C Factory Default Setting, lists the Factory default setting values of the
TZ3200C.

Doc. No. TZ3200C_MN_Ver1.0 Rev 0 4 / 22
TZ3200C ADSL Ethernet Modem User’s Manual
Table of Contents
Chapter 1 Introduction ……………………………….…… 5 ~ 8
1.1 Overview ……………………………………………………………... 5
1.2 System Requirement ..……………………………………………… 5
1.3 Important Safeguards ………………………………………………. 6
Chapter 2 Installations and Setup .……………………… 9 ~ 16
2.1 Unpacking the Box ……………………………………………….….. 9
2.2 Connectors & LED’s ……………….………………….…………….. 10
2.3 Installing the TZ3200C ……...…………………….………….. … 12
Chapter 3 Configuring the TZ3200C .………………… 13 ~ 19
3.1 Before Configuration ………………………...……………………… 14
3.2 Logging on to the Web Console …………………………………... 15
3.3 Configuring the Router (PPPoA/PPPoE) Mode ………..………… 16
3.4 Configuring the Bridge (RFC 1483) Mode ………………………… 18
Appendix A. Troubleshooting .…………………………………… 20
Appendix B. Technical Specifications ………………………… 21
Appendix C. Factory Default Setting …………………….…… 22

Doc. No. TZ3200C_MN_Ver1.0 Rev 0 5 / 22
TZ3200C ADSL Ethernet Modem User’s Manual
Chapter 1 Introduction
1.1 Overview
The TZ3200C ADSL Bridge/Router Ethernet Modem provides an “always-on”
high speed Asymmetric Digital Subscriber Line (ADSL) connection to the telephone
line. The TZ3200C solution hardware connects to the computer via the Ethernet
interface. The TZ3200C supports T1.413-1998, G.dmt (G.992.1) and G.lite
(G.992.2) ADSL and is designed to operate in LAN and WAN modes.
In addition, the TZ3200C software includes the Web Server to support the feature
of embedded graphics configuration for the TZ3200C products. Through the
Ethernet connection, the end-user can identify the current configuration on
the system.
1.2 System Requirements
☞Windows 95
☞Windows 98
☞Windows 98SE
☞Windows Millennium Edition
☞Windows 2000 Home Edition & Professional
☞Windows XP Home Edition & Professional
☞Macintosh, Linux, UNIX
System Specification (Recommended).
Internet speed depends on your system specification, so the following specifications are
recommended.
⊙OS : Windows 98/98SE or above
⊙CPU :Pentium II 233MHz or higher
⊙System Memory(RAM): 64MB or higher

Doc. No. TZ3200C_MN_Ver1.0 Rev 0 6 / 22
TZ3200C ADSL Ethernet Modem User’s Manual
1.3 Important Safeguards
Read all the instructions carefully. Follow all warnings and instructions marked on
the product.
Environment
yIn-house stationary use, desktop or wall-mounted; the maximum ambient
temperature may not exceed 45°C (113°F).
yIt must not be mounted in a location exposed to direct or excessive sunlight
and/or heat radiation.
yIt must not be exposed to heat trap conditions and must not be subjected to
water or condensation.
yIt must be installed in a Pollution Degree 2 environment.
Qualified Personnel Warning
Only trained and qualified personnel should be allowed to repair this equipment.
Do not Dismantle the Product
Dismantling this product can cause bodily injury and damage to the equipment
because of electric shock, failure, misoperation and static electricity. Do not
dismantle, repair or reassemble it without permission.
Keeping the Installation Area Tidy
The area of installation should be kept clean and tidy. Ensure also that no part of
the device is placed where it could cause an accident.
Cleaning
Unplug this product from your computer before cleaning. Do not use liquid cleaners
or aerosol cleaners. Use a damp cloth for cleaning.
Water and moisture
Do not place this product near water, for example, near a bathtub, wash bowl,
kitchen sink, laundry tub, in a wet basement or near a swimming pool.
Remove Metallic Jewellery
You must remove all your metallic jewellery including rings, necklace, and watch.
Metallic objects are conductors of electricity when the power is on. It can cause
serious burning and damage to the jewellery. Also, please avoid loose clothings
and neckties because they can cause accidents and damage the device.

Doc. No. TZ3200C_MN_Ver1.0 Rev 0 7 / 22
TZ3200C ADSL Ethernet Modem User’s Manual
Ventilation Warning
When you install the product, choose a well ventilated place in order to prevent
product failure or misoperation due to overheating and dust causing data loss,
product failure and human injury.
Electromagnetic Wave Warning
Electromagnetic wave has an adverse effect on the product/cable and causes
abnormal operation by disorganizing the signal system. Therefore do not install or
operate this product in a place where electromagnetic wave is present.
Lightning Warning
Lightning may bring about serious failures like product breakdown. In order to
prevent damage from lightning, ensure that the place of installation and the
connected cables are not susceptible to lightning. Installation of a surge suppressor
system will minimize any danger of a lightning strike.
Lightning Activity Warning
Do not work on, connect or disconnect this product and cables during periods of
lightning activity or when lightning is forecast.
Ground Connected Cable Warning
For all cables connected to the product, use ground connected cable to prevent or
minimize problems from surge. Also do not touch any uninsulated part of cables
disconnected from the product.
Recommended Installation Range Warning
In order to prevent falling off in performance caused by signal reduction, do not
exceed the recommended installation range.
Overheating Warning
Unless you secure enough space around the device when installing it, heat coming
out from other peripheral equipment affects the product and overheating can cause
product failure or misoperation. Therefore always secure enough space around the
place of installation to ensure that this does not happen. In order to prevent
overheating of this unit, do not operate this product in an area where the
temperature is 45℃(113℉) or above.
Working Space Warning
For easy maintenance and repair in case of problems , ensure that there is enough
working space around the product. This helps to prevent overheating.

Doc. No. TZ3200C_MN_Ver1.0 Rev 0 8 / 22
TZ3200C ADSL Ethernet Modem User’s Manual
Modem / Telephone use
yAvoid using a modem/telephone (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lightning.
yDo not use the telephone to report a gas leak in the vicinity of the leak.
yIf telephone service is required on the same line and for optimum ADSL
performance, distributed filters must be installed. Depending on your ADSL
configuration and type of filters, installation must be carried out by qualified
service personnel.
yConsult your Telephone Company or ADSL Service Provider for instructions.

Doc. No. TZ3200C_MN_Ver1.0 Rev 0 9 / 22
TZ3200C ADSL Ethernet Modem User’s Manual
Chapter 2 Installation and Setup
2.1 Unpacking the Box
Check the shipping carton carefully to ensure that the contents include the items
you ordered.
ADSL Modem (1) ADSL (Phone) Cable (RJ11 to RJ11) (1)
Direct UTP (LAN) Cable (RJ45 to RJ45) (1) User’s Manual CD-ROM (1)
AC Power Adaptor (1) External In-line Filter(1) (Option)
Note) The following hardware is not provided but is necessary to install and
configure the TZ3200C. Before installing the TZ3200C, prepare the
following hardware:
yExternal Micro-filter or splitter (provided separately by your service
provider)

Doc. No. TZ3200C_MN_Ver1.0 Rev 0 10 / 22
TZ3200C ADSL Ethernet Modem User’s Manual
2.2 Connectors & LED’s
TZ3200C (Front view)
LED Operations
LED Colour Status Meaning
POWER - Solid
- Off -DC Power is being supplied to the TZ3200C.
- Power Off
LAN - Flashing
- Solid - Data is transmitted or received to the LAN side
- Ethernet interface is active.(100M/10M)
LINK - Flashing
- Solid
- Trying to connect the ADSL line
- ADSL line has synchronized with your service
provider
DATA - Flashing - Data is transmitted to the ADSL line
PPP
Green
- Flashing
- Solid
- Trying to connect the PPP Mode
- Solid green when using PPPoE or PPPoA, if
the user has authenticated to the ISP’s server.
