EN 3
cable drum PVD2 / PVD3 / PVD4
• Insert the mains plug into a properly secured mains
socket.
• Observe the following safety rules when performing work
on the electrical equipment: 1.De-energise, 2.Secure
against restart, 3.Verify de-energised state, 4.Earth and
short-circuit, 5.Cover or fence off live parts.
• Before carrying out maintenance, care or repair work on
the device, remove the mains plug from the mains socket.
Hold onto the mains plug while doing so.
• Do not under any circumstances use the device if you
detect damages on the mains plug or power cable. If the
supply cord is damaged, it must be replaced by the
manufacturer, his service agent or similarly qualified
persons in order to avoid a hazard. Defective power cables
pose a serious health risk!
• Observe the storage and operating conditions as given in
the Technical data chapter.
• Do not expose the device to heat or direct sunlight.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Any operation other than as described in this manual is
prohibited. Non-observance renders all claims for liability
and guarantee null and void.
Intended use
The device serves as extension line for electrical connections.
For the PVD2 model, the sum of the maximum permissible
connected load must not exceed 3600watts when unreeled and
1300watts when rolled up. For the PVD3 and PVD4 models, the
sum of the maximum permissible connected load must not
exceed 3500watts when unreeled and 1250watts when rolled
up.
Improper use
Do not use the device in potentially explosive areas. Do not
place the device on wet or flooded ground.
Any unauthorised changes, modifications or alterations to the
device are forbidden.
Personnel qualifications
People who use this device must:
• have read and understood the operating manual, especially
the Safety chapter.
Initial start-up and maintenance tasks which require the
housing to be opened must only be carried out by qualified
electricians.
Symbols on the device
Note
Do not remove any safety signs, stickers or labels from
the device. Keep all safety signs, stickers and labels in
legible condition.
The following safety signs and labels are attached to the cable
drumPVD2:
Symbols Meaning
This symbol located on the device indicates
that, when rolled up, the maximum
connected load must not exceed
1300watts.
This symbol located on the device indicates
that, when unreeled, the maximum
connected load must not exceed
3600watts.
The following safety signs and labels are attached to the cable
drumsPVD3 and PVD4:
Symbols Meaning
This symbol located on the device indicates
that, when rolled up, the maximum
connected load must not exceed
1250watts.
This symbol located on the device indicates
that, when unreeled, the maximum
connected load must not exceed
3500watts.
