Turbo E2T Series Bedienungsanleitung

ECONOMISER

SERIES

E2T

USER MANUAL

01/03/2016

Manual Release 1.25

Hardware Release 1.3

TURBO

s.r.l.

Electronic Control Systems For Dust Collectors

e-mail: info@turbocontrols.it

web: www.turbocontrols.eu

Tel. 39 (0)362 574024 Fax 39 (0)362 574092

General Description

Economiser for controlling the pneumatic cleaning function of industrial dust collection

s stems. The pressure differential is digitall controlled b an internal transducer allowing

to determine filter obstruction with accurac . It has 2 output rela contacts and 2 digital

input contacts. A large, bright displa is provided for reading the filter obstruction level,

the active solenoid valves and an alarms in an moment.

Technical Specifications

Casing

•Made of insulating, ABS base and pol carbonate lid.

•Degree of protection to water and dust: IP65 (EN60529).

•Shock resistance IK07 2 Joule (EN62262).

Performance Of The Device

LED displa with 7 segments, 3 digits, 0.8” each.

Four operation modes: manual; automatic;

automatic with forced c cle; proportional.

Operating times expressed in seconds with selectable ranges for an application.

Pressure measurements expressed in kPa.

Power voltage 115-230 Vac 50-60 Hz selectable b means of jumpers, optional 24

Vac / Vdc.

Output voltage 24 Vdc, 24-115-230 Vac selectable b means of jumper, must also

set with F05.

Washing function with the fan off (post-cleaning) through the “dP fan” threshold in

the automatic/automatic with forced c cle/proportional modes and through contact

in the manual mode with up to 99 c cles that can be selected.

Total and partial hour counter for maintenance.

Two alarm rela s, normall closed.

Maximum dP (filter obstructed) alarm.

Minimum dP alarm (broken sleeve/cartridge), with possibilit of inclusion/exclusion.

Solenoid valve not working alarm.

Filtering element maintenance deadline alarm (with on/off selection).

External contact cleaning activation.

Compressed air presence enable input.

Pre-coating function (with possibilit of inclusion/exclusion).

Active 4-20mA output proportional to dP reading for remote pressure reading.

Manual solenoid valve activation.

Important: Read the

installation instruction section

before connecting the device.

Important: Higher pressures may

damage the device. Do not

connect the obstruction measuring

pipes to the compressed air circuit.

Electric Specifications

Electric Power

•115 Vac ± 10% 50-60 Hz – 25W

•230 Vac ± 10% 50-60 Hz – 25W

•24 Vac ± 10% 50-60 Hz – 25W (optional)

•24 Vdc ± 10% 25W (optional)

Selectable Output Voltage

•24 Vdc

•24 Vac

•115 Vac

•230 Vac

Inputs An Outputs Not Galvanically Insulate

•Enable contact (remote cleaning enable).

•Fan contact (post-cleaning).

•4 – 20mA (dP remote reading).

The solenoid valves connected to the unit are normall closed.

The activation of a solenoid valves causes them to open and consequentl let out a jet of

air.

Alarm Relay

The two alarm rela s contain 2 clean contacts on terminals 4-5 and 6-7.

Maximum permitted load: 3A @ 250 Vac - 2A @ 24 Vdc, Vac.

The rela s are normall closed, opens in case of alarm, and opens to the control unit off in

the absence of power.

Fuses:

1 x 1 A @ 230 Vac.

1 x 1 A @ 115 Vac.

1 x 3 A @ 24 Vac (optional).

1 x 3 A @ 24 Vdc (optional).

Working Temperature

from -10°C to 55°C

Storage Temperature

-20°C to 60°C

imer Specifications

Pulse time (valve opening)

from 50 ms to 5 sec

Pause time (interval between valve openings)

1 sec - 999 sec

Differential Pressure Gauge:

Measurable pressure range: from 0 to 4 kPa

Maximum applicable pressure: 16 kPa - 0.16 bar

Warning Symbols Use In This Manual

The information regarding safet are highlighted using the s mbols:

Warning-Danger

Generic - Warning-

Risk – Danger Electric Current

Dispose according to the standards for electrical and

electronic equipment RAAE

Installation Rules Notes an Warnings



Protect the device from direct exposure to sunlight.



Do not position the device near or directl in contact with sources of heat or

electromagnetic fields.



Fix the device of a height of at least 60 cm from the ground.

In a clearl visible place easil accessible.



Connect the device to power lines other than those for operating motors or other

large power devices which could generate network interference or instabilit .



The electrical suppl of the unit must be protected b a differential switch 230Vac~

30mA and a bipolar magneto thermic 230Vac~ 10A, positioned in a place easil

accessible.



Before working on the equipment to perform an operation switch off the

magneto thermic differential switch.



For electric operations, alwa s remove voltage, wait 30 seconds for the

inside capacitors to discharge before opening. At the end of the operations,

close the device to restore the correct degree of protection before powering up.



For the connection of the suppl voltage, use anti-flame wires with a minimum

section of 0.75mm² certified and conform to the standard IEC60227 or IEC60245.



Use flame-retardant cables with a minimum cross-section area of 0.75 mm² for all

control signals.



Use flame-retardant cables with a minimum cross-section area of 0.75 mm² to

connect to the indicating rela s.



Use flame-retardant cables with a minimum cross-section area of 0.5 mm² for

electro valves control signals.



The wire ground conductor of protection must be ellow/green.



The wire ground conductor of protection must be connected first.



The wire which is colored ellow/green must onl be used for the ground conductor.



The cable glands must be chosen according to the diameter of the cable to be used.



The sealing of the press cable is guaranteed b the compression of the rubber gasket

that tightens on the outer diameter of the cable.



The tightness of the cable gland is guaranteed b the compression of the rubber seal

that tightens on the outer diameter of the cable.



The size of cable and cable gland must ensure that a power cord traction is not

acting on the terminals.



The terminal block must not be the point of mechanical anchoring of the conductors.



The cable gland PG9 supplied on request, has cable diameter minimum of 4mm and a

maximum of 8mm, with clamping nut b 19mm.



An use not described in this user instruction manual or incorrect use of the device

ma cause damage to the device or to the devices connected to it.



Furthermore, incorrect use or tampering with the device ma cause injur .



Waterproofness of the casing is guaranteed when the flap is closed.



Make sure that rigid or flexible ducts used for wiring, if an , do not fill up with water

or other liquids.



Do not make holes not protected on the container or protected b accessories with

protection degree lower than that of the housing of the control unit.



Cut off power suppl immediatel if water is found in the casing.



If the control unit is used in wa s not specified b the manufacturer, the protection

provided b the device ma be impaired.



The Control Unit does not release potentiall toxic or harmful substances to the

health and the environment.



No part with dangerous voltage is normall accessible.

Do not use the control unit if ou have not read or do not understand this manual.

Display / Keypa

There are four round buttons on the front panel for controlling the device and

turning on the displa as shown in the following figure.

The SET button enables to enter and exit the

programming menu, and activate the manual

testing of select4ed solenoid valve function F06.

The + and – buttons enable to scroll functions

from F01 to Fxx. After entering one of the Fxx

functions use the OK button to select and then +

and - increase or decrease the values.

The OK button is used to confirm data and reset

alarms.

If the + button is pressed during ordinar

operation, the activit hour meter is displa ed.



The - Button pressed during the ordinar

operation, displa s the counts partial hours of

activit .

Menu Diagram

Press SET, the letter F flashes.

Press + and – to select the required function.

Press OK to confirm.

Increase or decrease the value of the parameter.

Holding down the + and - buttons to scroll through

all the functions until the end of the left or right.

Press OK to confirm and exit.

Press SET again to exit programming mode.

List Of Functions

F01:

Configuring the operation mode.

Possible values: 0 – Manual (dP excluded)

1 – Automatic (dP included) Default

2 – Automatic with forced c cle (dP included)

3 – Proportional (dP included)

By setting the Manual Mode, it is necessary change the alue of F11 Fan Recognition on 0,

detection by contact and not by dP, close together the contacts to 12.13 on J2 terminal block.

F02:

Solenoid activation time.

Possible values: 0.05” – 5.00” step 0.01”.

Default = 0.20”.

F03:

Washing pause time between solenoid valves.

Possible values: 001” – 999” step 1”.

Default = 020”.

F04:

Number of connected outputs.

Possible values: 01 – 16 step 1.

Default = 001.

F05:

Output voltage setting, must agree with jumpers.

Possible values: d24, a24, 115, 230.

Default = a24.

F06:

Manual output activation.

Possible values: 1 – number of outputs set in F04.

Press SET to activate the set output.

F07:

Zero dP threshold.

Possible values: 0.00 kPa – 3.99 kPa step 0.01.

Default = 0.00 kPa.

F08:

Cleaning c cle start threshold high dP set point.

Possible values: 0.00 kPa – 3.99 kPa step 0.01.

Default = 0.80 kPa.

F09:

Cleaning c cle stop threshold low dP set point.

Possible values: 0.00 kPa – 3.99 kPa step 0.01.

Default = 0.40 kPa.

F10:

Max dP Alarm Threshold (Filter Clogging if detected for longer than 20 seconds)

Possible values: 0.00 kPa – 3.99 kPa step 0.01.

Default = 3.00 kPa.

F11:

Fan on recognition mode for after c cle cleaning.

Possible values: 0 from contact – 1 from dP.

Default = 1 from dP.

Set to 0 if F01 is 0, Manual Mode dP excluded.

F12:

dP threshold for fan on recognition if F11=1.

Possible values: 0.00 kPa – 3.99 kPa step 0.01.

Default = 0.10 kPa.

F13:

Number of post cleaning c cles after stopping the fan.

Possible values: 01 – 99 step 1.

Default = 01.

F14:

Post cleaning mode pause time between solenoid valves (fan off).

Possible values: 001” – 999” step 1”.

Default = 10”.

F15:

Maintenance frequenc expressed in tens of hours (e.g.: 1=10h, 10=100h).

Possible values: 001 – 999 step 1.

Default = 100 (=1000h).

F16:

Maintenance deadline alarm enable.

Possible values: 0 (disabled) – 1 (enabled).

Default = 0 (disabled).

F17:

Maintenance hour counter reset.

Possible values: 0 (disabled) – 1 (reset).

Default = 0 (disabled).

The maintenance hour counter will be reset and the F17 parameter will be set back to 0 by

setting F17 to 1.

F18:

Precoating function enabling.

Possible values: 0 (disabled) – 1 (enabled).

Default = 0 (disabled).

F19:

dP threshold for precoating function.

Possible values: 0.00 kPa – 3.99 kPa step 0.01.

Default = 2.00 kPa.

F20:

Enabling Minimum dP Alarm function if detected for longer than 60 seconds.

Possible values: 0 (disabled) - 1 (enabled).

Default = 0 (disabled).

F21:

Min dP Alarm Threshold (Broken Sleeve/Cartridge)

Possible values: 0.00 kPa – 3.99 kPa step 0.01.

Default = 0.20 kPa.

F22:

Selection of minutes or hours for Forced Cleaning C cle. (Onl if the operating mode

F01 = 2)

Default = Minutes (0 =minutes, 1 =hours).

F23:

Setting time interval for Forced Cleaning C cle in relation to the choice of F22.

Setting values: 1 - 999 step 1.

Default = 240 (240 minutes).

F24:

Exclusion of valve in Short Circuit.

The default setting is 0, the valve in Short Circuit is tested at each c cle.

If set to 1, when a al e is in short circuit is excluded from the cycle and is not rechecked.

Alarms

The unit runs a number of checks during the start-up c cle and during normal operation.

The possible alarms and respective solutions are shown in the following table.

No. Description Action

E01 F05 set to 24 Vdc

Vac jumper detected

- For 24 Vdc, switch the device off and move

the AC/DC jumpers to DC.

- For 24

Vac, press OK, then press SET, set the

function F05 using “+” and “-”, select A24 and

press OK to confirm.

E02 F05 set to 24 Vac

Vdc jumper detected

- For 24 Vac, switch the device off and move

the AC/DC jumpers to AC.

- For 24

Vdc, press OK, then press SET, set the

function F05 using “+” and “-”, select d24 and

press OK to confirm.

E03 F05 set to 24 Vac or Vdc.

Voltage out of range detected

- To use 24V valves, switch the device off and

move the output voltage selection jumper to

24V. - If the jumper is in the correct position,

press OK, then SET, select the F05 function

with “+” and “-”, set 115 or 230 (as jumper)

and press OK.

E04 F05 set to 115 Vac.

Voltage out of range detected

To use 115V valves, switch the device off and

move the output voltage selection jumper to

115V. -

If the jumper is in the correct position,

press OK, then SET, select the F05 function

with “+” and “-”, set 115 or 230 (as jumper)

and press OK.

E05 F05 set to 230 Vac.

Voltage out of range detected

To use 230V valves, switch the device off and

move the output voltage selection jumper to

230V.

If the jumper is in the correct position, press

OK, then SET, select the F05 function with “+”

and “-”, set a24, d24 or 115 (as jumper) and

press OK.

E06

Solenoid valve current lower than minimum

threshold or disconnected solenoid valve

Check correct connection of the solenoid valve

and respective data. The alarm is self-reset.

E07 Solenoid valve current higher than

maximum threshold

Check correct connection of the solenoid valve

and respective data. The alarm is self-reset.

E08

Output short circuit. Alarm

The signaling of the code E08 alternates

with the indication of the interested output

is shown as Uxx where xx is the number of

the output and the value of dP.

Switch the device off and back on after having

checked the solenoid valve s stem.

E09 dP maximum pressure exceeded (F10)

Detected for longer than 20 seconds. Check state of filtering elements.

E10 dP sensor hardware offset out of range.

The self-calibration of the dP sensor has

determined that a value is out of range.

Disconnect the air tubes and repeat the

function. Take the device to be serviced if the

alarm occurs again.

E11 Maintenance deadline reached Carr out maintenance.

E12 dP sensor full-scale value reached

Immediate reporting without an dela .

Check state of filtering elements.

IMPORTANT: Running in this condition ma

damage the device.

E13

Minimum dP alarm value ranging from F12

to F21 (warning: the alarm is generated

with a fixed dela of 60 seconds).

Check the status of the filtering elements.

E14

Indicates that a valve in short circuit has

been excluded from the c cle. The

signaling of the code E14 alternates with

the indication of the interested output is

shown as Uxx where xx is the number of

the output and the value of dP.

An output is considered a short circuit if

not responding for 3 following activations.

An activation without error resets the

counting.

Switch the device off and back on after having

checked the solenoid valve s stem.

Description Of Operation

The installed SW version and the s mbol ---, meaning that coherence between settings

stored in E2Prom and the set jumpers is being checked, will appear on the displa when

the economiser is powered up. A corresponding error code will appear in case of

discrepancies between settings (see Alarms Table). Onl editing functions will be allowed

on the unit. The operator ma switch off the unit and configure the jumpers correctl .

S mbol 0_0 will appear on the displa if the test is entirel successful. The following

pages will then appear:

•In automatic mode (F01=1):

odP value alternating with OFF if the enabling contact (14-15) is open

odP value alternating with -0- if the enabling contact (14-15) is closed and

the fan is off

odP value onl if the fan is enabled and active.

•In manual mode (F01=0):

oOFF if the enabling contact is open (14-15)

o-0- if the enabling contact (14-15) is closed and the fan is off

Manual Operating Mo e F01=0

The economiser will work as a programmable c cle sequencer in manual mode. The

connected outputs will be activated at the programmable frequencies. Manual mode can

be activated b accessing the configuration menu and setting F01 to 0. F02 and F03 will

set the activation time and the pause time, respectivel .

Automatic Operating Mo e F01=1

B selecting automatic mode (F01=1), the economiser will work autonomousl can carr

out the pneumatic washing c cle onl when needed. The device will start the washing c cle

if the obstruction is higher than Threshold_dP_Start (F08). Washing is suspended when

obstruction drops under Threshold_dP_Stop (F09) level until it reaches a value higher than

the Threshold_dP_Start threshold once again. When washing is active, the economiser

respects the times set in F02 (operating time) and F03 (pause time).

Automatic Mo e With Force Cycle F01 = 2

Identical to the automatic mode, except for the fact that it is possible to obtain a cleaning

c cle with the activation of the solenoid valves connected without reaching the

Threshold_dP_Start (F08). The forced cleaning interval ma range from 1 to 999 h and can

be selected through function F22 and F23.

Inhaltsverzeichnis

Andere Turbo Controller Handbücher

Turbo

Turbo Economiser E2T Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
