Turtle Beach Ear force ATLAS Bedienungsanleitung

User Guide

FOR Xbox One™ I Xbox 360® I PC

Congratulations on your purchase of the Titanfall™ Ear Force® Atlas headset from Turtle Beach. You’ll

enjoy powerful gaming audio and chat with Xbox 360 and Xbox One consoles as well as PCs and even mobile

entertainment sources. Turtle Beach brings over 35 years of expertise to transforming your listening experience.

Welcome to Turtle Beach!

In the Box

Go to Table of Contents

For our Knowledgebase and Technical Support please visit:

turtlebeach.com/support

Xbox 360 Chat Cable

Titanfall Ear Force ATLAS Headset Xbox One™ Audio Adapter

RCA Splitter Cable Turtle Beach Sticker

Titanfall Ear Force ATLAS

In-line Amplifier

USB Micro Cable

B C

E F

Table of Contents

About the Titanfall Ear Force Atlas Headset 5

Parts and Controls 6

Setup and Connections: Xbox One Consoles 7

Setup and Connections: Xbox 360 Consoles 9

Setup and Connections: PC 15

Setup and Connections: Mobile Sources 17

Specifications 18

Troubleshooting Tips 19

Important Safety Information 20

Go to Table of Contents

About the Titanfall Ear Force Atlas Headset

The Titanfall Ear Force Atlas unlocks the audio potential of Titanfall on every platform: Xbox One, Xbox 360 and PC.

To get the most from your headset, please take a few moments to review this introduction.

Overview

Engage in fast-paced, vertical warfare with the Titanfall™ Ear Force® Atlas Official Gaming Headset. Feel every

bone-jarring footfall of your massive Titan, pinpoint enemy locations and stay in clear communication with other pilots

as you battle for control of the Frontier.

• Ready for Titanfall. Designed for Xbox One and compatible with Xbox 360 and PC to work with all versions of Titanfall.

• Customize your audio. Personalize game and chat mix volume, plus mic mute right at your fingertips.

• Be heard loud and clear. High-quality removable mic for chat on Xbox One, Skype, Xbox 360 and many other

voice applications.

• Comfortable, twist-cup design. Breathable mesh cushions on the earcups rotate to flat for wearing around your neck.

• Mobile device compatibility. Take your headset with you for mobile gaming on phones, tables or other devices.

• Bass boost. Adds more depth and punch to the game audio (Xbox 360 and PC only).

• Mic monitor. Hear your own voice in the headset to avoid shouting.

• For Your Entertainment. The headset isn’t just great for Titanfall. Enjoy your favorite movies and TV shows with

superior sound. Then crank up your tunes from music services like Xbox Music, or Skype with friends!

Go to Table of Contents

MODE SWITCH

Top View

Parts and Controls

In-Line Amplifier (for Xbox 360 and PC)

Xbox One Audio Adapter

Mic Status LED

Green = Mic On

Red = Mic Off

Mic Switch

Mic On

Mic Off

Xbox 360 Chat Jack

Connect the Xbox 360

chat cable here.

Always insert firmly.

Game Volume

Adjusts the volume for game,

music and other audio sources.

Chat Volume

Adjusts the volume for chat.

Headset Jack

Connect the headset plug here.

Always insert firmly.

Volume Up

Press to increase overall

game and chat volume.

Volume Down

Press to lower overall

game and chat volume.

Headset Jack

Connect the headset

plug here. Always insert firmly.

Mic Mute

Press to turn off the microphone. Press

again to turn it back on.

(LED will glow when muted)

Chat/Game Balance Buttons

Adjust the relative volume

level to emphasize either

Game (controller icon)

or Chat (person icon).

Go to Table of Contents

Setup and Connections: Xbox One Consoles

Updating the Xbox One controller firmware

To use the adapter with an Xbox One controller, you first need to update the controller firmware.

Perform the following steps.

1. Confirm that your Xbox One console is powered on.

2. Open the battery compartment on the back of the Xbox One controller and remove the batteries.

3. Insert the Xbox One Audio Adapter into the Xbox One Controller.

4. Insert the cable from your headset firmly into the headset jack of the Xbox One Audio Adapter.

5. Plug the big end of the USB cable supplied with the Xbox One Controller into the USB port on the side of the

console.

6. Plug the small end of the USB cable into the top of the controller.

7. Follow the on-screen instructions from your Xbox One console to update the firmware.

NOTE: Do not disconnect your controller or turn off your Xbox One console while the update is in progress.

8. When the update is complete, unplug the USB cable from the controller and replace the batteries.

9. Press the Xbox button on the controller to turn it back on.

NOTE: Confirm that all connections are firmly inserted.

The Titanfall Ear Force Atlas headset is supplied with a convenient Xbox One Audio Adapter that plugs directly into

the Xbox One controller (not supplied with the headset). The adapter places game volume, chat volume and mic mute

controls right where your thumbs can operate them.

USB Micro Cable

Xbox One™ Audio Adapter

Controller not Included

Go to Table of Contents

Connecting to the Xbox One controller

1. Insert the microphone boom plug into the jack on the left earcup of the headset .

2. Insert the Xbox One Audio Adapter into the Xbox One Controller.

3. Insert the cable from your headset into the headset jack of the Xbox One Audio Adapter.

NOTE: For reliable sound, confirm that all connections are firmly inserted.

Setup and Connections: Xbox One Consoles

Go to Table of Contents

Setup and Connections: Xbox 360 Consoles

The Titanfall Ear Force Atlas headset is packaged with an In-Line Amplifier, an Xbox 360 Chat Cable and an RCA Splitter

Cable that provide connection to the Xbox 360 Console and Xbox 360 controller (not supplied with the headset). The

In-Line Amplifier places game volume, chat volume and mic mute controls within easy reach. The In-Line Amplifier also

provides bass boost.

MODE SWITCH

Titanfall Ear Force ATLAS

In-line Amplifier Xbox 360 Chat Cable

RCA Splitter Cable

Determine your Xbox 360 console type and connection type

Your method of connecting will depend on the specific type of Xbox 360 console you own (Original, Slim or E) and the

method you’re using to connect the console to your television (HDMI™ or RCA cable).

1. Identify your Xbox 360 console.

Xbox 360 Original and Slim consoles use a trapezoidal AV

connector.

Xbox 360 E consoles use a circular AV

connector.

2. Identify the connection from your Xbox

360 console to your TV.

2. Identify the connection from your Xbox

360 console to your TV.

An HDMI connection to your

TV uses a single plug for

both Video and Audio.

Composite and

component video

connections to your TV use

three or more color-coded

RCA plugs.

An HDMI connection to your

TV uses a single plug for

both Video and Audio.

Composite and

component video

connections to your TV use

three or more color-coded

RCA plugs.

Go to page 10. Go to page 11. Go to page 12. Go to page 13.

HDMI

white

yellow

red

HDMI

white

yellow

red

Go to Table of Contents

Setup and Connections: Xbox 360 Consoles

Xbox 360 Original and Slim HDMI® Connections

HDMI

Xbox 360

Audio Adapter*

E D

HDMI

USB

1. Insert the microphone boom plug into the jack on the left earcup of the headset.

2. Insert the cable from your headset into the headset jack of the In-Line Amplifier.

3. Insert the Xbox 360 Audio Adapter, sold separately, into the multi-pin connector on the Xbox 360 console.

4. Insert the Red and White RCA plugs of the RCA Splitter Cable, into the Red and White RCA jacks of

the Xbox 360 Audio Adapter.

5. Insert the 3.5 mm plug from the In-Line Amplifier into the 3.5 mm jack of RCA Splitter Cable.

6. Insert the L-shaped 2.5 mm plug of the Xbox 360 Chat Cable into the chat jack of the Xbox 360

controller (not included).

7. Insert the straight 2.5 mm plug of the Xbox 360 Chat Cable into the Xbox 360 Chat Jack of the In-Line

Amplifier.

8. Insert the USB plug of the In-Line Amplifier into a USB port of the Xbox 360 console.

NOTE: For reliable sound, confirm that all connections are firmly inserted.

* Xbox 360 Original and Slim models require an Xbox 360 Audio Adapter, sold separately, when used with an HDMI

connection. This adapter is available from turtlebeach.com.

* As an alternative, if your television has available RCA Audio Output jacks, you can use these to supply sound from the

television to the headset. (Only use the television’s Audio Output jacks. Audio Input jacks will not send sound to your

headset.)
