Before you begin…

Check the box contents!

The retail motherboard package should contain the following:

1x Tiger K8W motherboard

1x 34-Pin floppy drive cable

4 x SATA cable

2 x SATA Drive Power Adapter

1 x Ultra-DMA-100/66 IDE cable

1 x Game Port Cable

1 x IEEE1394a Cable

1 x Tiger K8W user’s manual

1 x Tiger K8W Quick Reference guide

1 x TYAN driver CD

1 x Silicon Image SiI3114 SATA RAID driver diskette

1 x Silicon Image SiI3114 SATA Link driver diskette

1 x I/O shield

2 x CPU Retention Frame

If any of these items are missing, please contact your vendor/dealer for replacement

before continuing with the installation process.

http://www.TYAN.com

Chapter 1: Introduction

Congratulations

You are now the owner of one of the most advanced dual AMD Opteron processor

solutions available: the Tiger K8W. With an 8x/4x AGP slot, four USB 2.0 and four USB

1.1 compatible ports, four Dual-channel DDR DIMM sockets, a Gigabit Ethernet port,

plus 6-channel Audio and SATA RAID, the Tiger K8W S2875 is fast and flexible enough

to fit your workstation needs.

Remember to visit TYAN’s Website at http://www.TYAN.com. There you can find

information on all of TYAN’s products with FAQs, online manuals and BIOS upgrades.

Hardware Specifications

Processor

Dual µPGA 940-pin ZIF sockets

Supports up to two AMD Opteron™

processors

Onboard VRM, 4-phase PWM

128-bit DDR dual-channel memory

controller integrated in CPU

Chipset

AMD-8151™ HyperTransport™AGP3.0

Tunnel

AMD-8111™HyperTransport™I/O Hub

Winbond W83627HF Super I/O chip

Memory

128-bit DDR dual-channel memory

bus

Total four 184-pin 2.5-Volt DDR DIMM

sockets supports up to 8GB

Supports Registered ECC/Non-ECC

PC3200*, PC2700, PC2100 and

PC1600 DDR

Expansion Slots

One 1.5V AGP 8X/4X slot

Five 32bit/33MHz(5V) PCI slots

Integrated SATA Controller

Silicon Image SiI3114 SATA RAID

Supports SATA 1.0 Specification

Supports 4 channel SATA port for up

to four SATA devices

Supports RAID 0, 1, 0+1

Connected to legacy 32-bit 33MHz

PCI bus

Integrated PCI IDE

Dual channel master mode support up

to four IDE devices

Supports for Ultra ATA/133/100/66

IDE drives and ATAPI compliant

devices

Back Panel I/O Ports

Stacked PS/2 Mouse & Keyboard

ports

Stacked 2 USB 1.1 ports

Two 9-pin UART Serial port

One 25-pin SPP/ECP/EPP parallel

port

Stacked 2 USB 2.0 ports + One RJ45

10/100/1000 Base-T port w/ activity

LED

Three audio jacks (Mic. In/Line-

in/Line-out)

Integrated I/O Interface

One floppy connector for up to two

drives

Two USB 2.0 + two USB 1.1 ports

CD-in/Aux-in connectors

2 x 5 pin header for front panel audio

connector

One IRDA connector

Power/IDE LED connectors

Six 3-pin headers for CPU/Chassis

Fans

System Management

Winbond W83627 HF w/ hardware

monitoring function

Six 3-pin Fan headers(three w/

http://www.TYAN.com

Integrated Audio

Realtek ALC655

6-channel AC ’97 audio CODEC

Line-In/Line-Out/Mic-In audio jacks

CD-in/Aux-in connector

Integrated LAN Controllers

One Giga-bit LAN controller

Intel 82541EI GbE LAN controller

Operating at 32bit/33MHz PCI bus

Power

On board 4-phase VRM

ATX 12V & EPS12V universal power

connectors

4-pin auxiliary power connector

tachometer monitoring)

Temperature and voltage monitoring

Port 80 code display LED

BIOS

AMI® BIOS 8.0 on 4Mbit LPC Flash

ROM

Supports APM 1.2 & ACPI 1.0

PnP, DMI2.0, WfM2.0 Power

Management

Power Management S1, S4 and S5

support

Form Factor

6-layer PCB

ATX footprint

12.0” x 9.8”(305mm x 250mm)

Regulatory

FCC Class B (Declaration of

Conformity)

European Community CE

(Declaration of Conformity)

* with Opteron 246 C-stepping CPU’s and above

Software Specifications

OS (Operating System) Support

Microsoft Windows NT 4 Service Pack 6A

Microsoft Windows 2000

Microsoft Windows XP

Microsoft Windows Server 2003

SuSE Server 8.0 for AMD-64

Red Hat 7.3, 8.0, and 9.0

Other distributions of Linux pending validation

TYAN reserves the right to add support or discontinue support for any OS with or without

notice.

http://www.TYAN.com

Chapter 2: Board Installation

Installation

You are now ready to install your motherboard. The mounting hole pattern of the Tiger

K8W S2875 matches the ATX specification. Before continuing with installation, confirm

that your chassis supports a standard ATX motherboard.

How to install our products right… the first time

The first thing you should do is read this user’s manual. It contains important information

that will make configuration and setup much easier. Here are some precautions you

should take when installing your motherboard:

(1) Ground yourself properly before removing your motherboard from the antistatic

bag. Unplug the power from your computer power supply and then touch a

safely grounded object to release static charge (i.e. power supply case). For the

safest conditions, TYAN recommends wearing a static safety wrist strap.

(2) Hold the motherboard by its edges and do not touch the bottom of the board, or

flex the board in any way.

(3) Avoid touching the motherboard components, IC chips, connectors, memory

modules, and leads.

(4) Place the motherboard on a grounded antistatic surface or on the antistatic bag

that the board was shipped in.

(5) Inspect the board for damage.

The following pages include details on how to install your motherboard into your chassis,

as well as installing the processor, memory, disk drives and cables.

NOTE DO NOT APPLY POWER TO THE BOARD IF IT HAS BEEN DAMAGED

http://www.TYAN.com

2.00 – Board Image

This picture is representative of the latest board revision available at the time of

publishing. The board you receive may or may not look exactly like the above

picture.

The following page includes details on the vital components of this motherboard.

http://www.TYAN.com

2.01 – Block Diagram

S2875 Tiger K8W Block Diagram

AMD

Opteron

Processor

AMD

AMD-8151

AMD

AMD-8111

DIMM1

DIMM3

DIMM4

Winbond

W83627F/HF

LPC Super I/O

AK2001

Debug system

Floppy Disk Drive

Intel 82541

Gigabit LAN

16x16 Hyper Transport@1600MT/s

AMD Chipset

LPC

AMD

Opteron

Processor

DIMM2

32-Bit/33MHz

Silicon


SiI3114

4 X Serial ATA

RAID Ports

150MB/s

Registered DDR

Memory Bus

DDR 333/266/200

16x16 Hyper Transport@1600MT/s

CODEC

AGP SLOT

PCI

SLOT1

PCI

SLOT2

PCI

SLOT3

PCI

SLOT4

PCI

SLOT5

LAN

VIA 6307

VIA 6212

USB 2.0 x4

IEEE 1394a

Header IEEE 1394a

Header LPC

ROM

PS/2 Keyboard &

Mouse

Serial Port x 2

Parallel Port x 1

EIDE(ATA/100) x2

USB 1.1 x4

LINE IN

LINE OUT

MIC IN

LINK 0B

OUT

IN OUTLINK 0A

LINK 1

8x8 ncHyper Transport@400MT/s

IN OUT

USB Ports: 2 to backplane

2 to header

USB Ports: 2 to backplane

2 to header

http://www.TYAN.com

2.02 – Board Parts, Jumpers and Connectors

S2875

J44

KB-MS

J41

USB1

P2_FAN

J24

FAN2

BIOS

AMD

AMD-8111

SATA2

SATA1

BT1

PRI-IDE

SEC-IDE

Winbond

W83627HF

AMD

AMD-8151

PCI2

1394

USB (Bottom)

LAN (Top)Optional KB(Bottom)

Mouse(Top)

PCI1

FAN3

FAN4 FAN1

J22

CPU1

CPU2

BZ1

USB2

SATA4

COM1COM2

LPT1

J39

udio

ALC655

CD1

AUX1

AGP1

PCI3PCI4

PCI5

VIA 6307

VIA 6212

1394

J21

CMOS

USB3

J3 J2

P1_FAN

J23

J33

J26

FDD

J34

J40

J32

J38

J35

J36

J14

J20

J12

J15

J1 J5

Game

Port

This diagram is representative of the latest board revision available at the time of

publishing. The board you receive may not look exactly like the above diagram.

Andere Handbücher für TIGER K8W

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere TYAN Hauptplatine Handbücher

TYAN

TYAN Tiger i7322 S5351 Bedienungsanleitung

TYAN

TYAN TIGER MPX Bedienungsanleitung

TYAN

TYAN S8005 Bedienungsanleitung

TYAN

TYAN TITAN-PRO AT Bedienungsanleitung

TYAN

TYAN Triumph i7520 (S6623) Bedienungsanleitung

TYAN

TYAN THUNDER N3600S Bedienungsanleitung

TYAN

TYAN S8230 Bedienungsanleitung

TYAN

TYAN S7052 Bedienungsanleitung

TYAN

TYAN TITAN TURBO PLUS ATX Bedienungsanleitung

TYAN

TYAN TOMCAT K8S Bedienungsanleitung

TYAN

TYAN TIGER I7501R Bedienungsanleitung

TYAN

TYAN TRINITY 100AT Bedienungsanleitung

TYAN

TYAN TOMCAT I875P Bedienungsanleitung

TYAN

TYAN THUNDER 2400 Bedienungsanleitung

TYAN

TYAN Tiger MPX S2466 Montage- und Bedienungsanleitung

TYAN

TYAN S1837 Bedienungsanleitung

TYAN

TYAN TOMCAT K8SH Bedienungsanleitung

TYAN

TYAN S8032 Bedienungsanleitung

TYAN

TYAN S5515 Bedienungsanleitung

TYAN

TYAN THUNDERBOLT Bedienungsanleitung

TYAN

TYAN S7067 Bedienungsanleitung

TYAN

TYAN TOMCAT I915 Bedienungsanleitung

TYAN

TYAN S5548GM4NED83-4T Bedienungsanleitung

TYAN

TYAN Toledo i3210W Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Gigabyte

Gigabyte GA-9IVDT Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung
