eatures Beneﬁts

8900 North 55th Street • Milwaukee, Wisconsin 53223 • Phone: 414-354-0300 • Fax: 414-354-7905

www.u-line.com

REFRIGERATOR

MODEL 2175R

Capacity: 5.7 cubic feet all refrigerator

Defrost Type: Automatic (cycle) Defrost

Colors: Stainless Steel, Black, White

Feature Benefit

Touch Control Digital Technology • Full-featured, easy-view command center - right at your

fingertips

• Easy to set and see temperatures

• Manages key model functions and provides user alerts

Open door alarm Audible alert when door is left open

Optional 3/4" full overlay door

panel

• Provides a fully integrated appearance with surrounding décor

while maintaining zero door clearance

• Easy to install

• Black and white models only

• Must order kit number U-OL2175

Standard door will accept a 1/4"

panel

• Ability to match surrounding décor and cabinets

• Black and white models only

Built-in or freestanding • Provides custom look

• No additional clearance around sides, top or rear for

ventilation. Do not obstruct front grille.

Stainless steel model • Offers a full wrap stainless door and cabinet, along with a

curved, sculpted stainless door handle and a stainless-like grille

• Must order right- or left-hand hinged

• Optional bold commercial-style stainless handle available for

purchase

Three fully encapsulated, curved

glass shelves

Contains spills while providing an upscale appearance. Easy to

clean.

Two contoured, adjustable

in-door storage shelves

Easy access, flexible storage

Self-closing door • Engages when the door is open 8-10"

• Ensures a positive door seat and prevents bounce-back

Field-reversible doors • Flexible installation options - can fit any location with easy

access

• Black and white models only

Integrated handle • Sleek designer look that does not add depth to the cabinet

when built in

• Black and white models only

Vinyl-clad cabinets • Textured, rich look. More resistant to scratching, peeling and

flaking.

• Cabinet extends to the floor

• Black and white models only

Recessed interior light • Automatically illuminates when door is opened

• Does not interfere with product access or storage

Leveling legs • Achieve a more precise undercounter fit

• Durable, strong legs will not bend when unit is installed

Sabbath or “Black Out” mode • Easily turns off all lights and control displays

• Automatically resets after 36 hours

Contemporary grille design Integrates seamlessly into surrounding cabinetry

Outdoor use The stainless model is deemed suitable for outdoor use by UL.

imensions Speciﬁcations

8900 North 55th Street • Milwaukee, Wisconsin 53223

Phone: 414-354-0300 • Fax: 414-354-7905 • www.u-line.com

Refrigerator Model 2175R

Specifications Capacities

(1) Amps pertain to a 110/115 volt, 60 Hz electrical environment.

Stainless steel model must be ordered right- or left-hand hinged.

Stainless steel models: Allow 2-1/2" clearance on hinge side for 90° door opening when installed against a wall.

Please visit www.U-Line.com for Installation Guide.

All specifications subject to change without notice.

2175R

(Stainless Steel)

23-15/16

(60.6)

*POWER CORD

*ON BACK OF UNIT 5-7/8

(14.9)

2-7/8

(7.3)

34-1/8

(86.7)

FULL

RETRACT

HEIGHT

35-1/8

(89.2)

FULL

EXTEND

HEIGHT

3-3/8

(8.6)

23-11/32

(59.3)

(53.3)

25-13/32

(64.6)

23-3/32

(58.6)

(53.3)

INCHES (CENTIMETERS)

Shipping Weight:

Black and White Models

Stainless Steel Models

129 lbs (59 kg)

147 lbs (67 kg)

(1) Running Amps 2.4

(1) Maximum Start-up Amps 9.8

Refrigerator volume 5.7 cubic

feet

Freezer volume N/A

Approximate daily ice production N/A

Ice storage N/A
