72" TRIPLE BANK
ROLLER CABINET
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 23e
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2022 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Roller Cabinet
Specifications
Electrical Rating
Input: 15A, 100-125V, 60Hz, 1875W Max
AC Output: 15A, 100-125V,
60Hz, 1875W Max
USB Output: 5VDC 3A/9VDC
2.22A/12VDC 1.67A
Type-C Output: 5VDC 3A/9VDC
2.22A/12VDC 1.67A
Total USB Output: 20 W (max)
Total Combined Weight Capacity
(Evenly distributed from bottom up.) 6600 lb
Drawer Capacity (per connected pair of slides) 120 lb
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS.
Assembly Precautions
1. Assemble only according to these instructions.
Improper assembly can create hazards.
2. Wear ANSI-approved safety goggles and
heavy-duty work gloves during assembly.
3. Keep assembly area clean and well lit.
4. Keep bystanders out of the area during assembly.
5. Do not assemble when tired or when under the
influence of alcohol, drugs or medication.
6. Weight capacity and other product capabilities apply
to properly and completely assembled product only.
7. Assemble on a flat, level, hard and smooth surface
capable of safely supporting a fully loaded unit.
Use Precautions
1. To prevent serious injury and death from tipping,
Do not have more than one drawer open at a time.
2. DO NOT SIT, STAND OR CLIMB ON THIS
ITEM. DO NOT STEP IN OR ON DRAWERS.
3. Unplug roller cabinet before drilling mounting
holes to mount workcenter hutch.
4. This product is not a toy nor a toy chest.
Do not allow children to play with or near this item.
5. Do not exceed weight capacities,
evenly distributed from bottom up.
Be aware of dynamic loading!
Sudden load movement may briefly create
excess load causing product failure.
6. Do not open more than one Drawer at once.
7. Empty, close, and lock Drawers before moving.
8. Use only on a flat, level, hard and smooth surface
capable of safely supporting a fully loaded Cabinet.
Do not roll Cabinet over concrete seams
or other rough/uneven surfaces.
9. Do not lift using handle(s).
Do not move or lift while loaded.
10. Lock Swivel Casters after moving.
11. Do not mount on truck bed or
any other moving object.
12. Do not operate equipment with a damaged cord.
13. Do not let a cord hang over the edge of the
table, bench, or counter or come in contact
with hot manifolds or moving fan blades.
14. If an extension cord is necessary, a cord with
a current rating equal to or more than that of
the equipment should be used. Cords rated for
less current than the equipment may overheat.
Care should be taken to arrange the cord so
that it will not be tripped over or pulled.
15. Always unplug equipment from electrical outlet
when not in use. Never use the cord to pull the plug
from the outlet. Grasp plug and pull to disconnect.
16. Loop cord loosely around equipment when storing.
Page 3For technical questions, please call 1-888-866-5797.Roller Cabinet
17. To reduce the risk of electric shock or fire,
never overload receptacles. Refer to markings
for the proper load on receptacles.
18. To reduce the risk of electric shock, do not
use on wet surfaces or expose to rain.
19. To reduce the risk of fire, do not use the
power strip in the vicinity of open containers
of flammable liquids (gasoline).
20. Do not use the equipment with a damaged cord or if
the equipment has been dropped or damaged – until
it has been examined by a qualified service person.
21. Use as intended only.
22. Inspect before every use;
do not use if parts are loose or damaged.
23. Maintain product labels and nameplates.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
24. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
In addition, people with pacemakers should:
• Avoid operating alone.
• Properly maintain and inspect to avoid
electrical shock.
• Properly ground power cord.
Ground Fault Circuit Interrupter (GFCI)
should also be implemented – it prevents
sustained electrical shock.
25. Keep hair, loose clothing, fingers, and all
parts of body away from moving parts.
26. Use only as described in this manual. Use only
manufacturer’s recommended attachments.
27. ALWAYS WEAR SAFETY GLASSES. Everyday
eyeglasses only have impact resistant
lenses, they are not safety glasses.
28. To reduce the risk of injury, close
supervision is necessary when this
product will be used around children.
29. To reduce the risk of injury, never overload the
drawers or shelves. Refer to loading instructions.
SAVE THESE INSTRUCTIONS.
Page 4 For technical questions, please call 1-888-866-5797. Roller Cabinet
Assembly Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document
including all text under subheadings therein before set up or use of this product.
1. Assemble on a flat, level, hard and smooth surface
capable of safely supporting a fully loaded unit.
2. Attach Side Handles (2) using Handle Screws (3).
Handle
Screws (3)
Handle (2)
Page 5For technical questions, please call 1-888-866-5797.Roller Cabinet
Connecting Cabinets
1. Unplug Cabinets from outlet.
2. Empty all Drawers from Cabinets.
3. Remove all attachments from Cabinets
4. Assemble on solid flat surface.
5. Remove Top Drawers from Cabinets.
6. Remove two Handle Screws (3) from
Handle (2) from Cabinet A.
7. Remove Handle.
Handle
Screws (3)
Handle (2)
Cabinet A
8. Rotate both Swivel Casters (22) sideways on
Cabinet A to keep Casters from hitting each other.
Cabinet A Cabinet B
Swivel Caster (22)
9. Place Cabinet A and Cabinet B together,
Ensure Cabinets are pressed firmly
together, refer to Figure A.
Cabinet A Cabinet B
install
Bolts
here
Figure A
10. Place two M6x25 Bolts (26) through upper outer
holes from one Cabinet to the other Cabinet.
Secure Bolts with M6x25 Nuts (25) and tighten.
Install Bolts Here
M6x25
Nut (25)
M6x25
Bolt (26)
Page 6 For technical questions, please call 1-888-866-5797. Roller Cabinet
11. Place two M8x40 Bolts (28) through holes underneath
Cabinets from one Cabinet to the other Cabinet.
Secure Bolts with M8x40 Nuts (27) and tighten.
Cabinet A Cabinet B
M8x40
Bolt (28)
M8x40
Nut (27)
Install Bolts Here
12. With Cabinets connected, remove eight Bolts (29)
from two Fixed Casters (21) on Cabinet B.
13. Remove two Fixed Casters from Cabinet B.
Cabinet A Cabinet B
Fixed Caster (21)
Bolt (27)
14. Install two Top Drawers into Cabinets.
Page 7For technical questions, please call 1-888-866-5797.Roller Cabinet
Operation Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document
including all text under subheadings therein before set up or use of this product.
1. Empty all Drawers.
2. Close all Drawers and lock them.
3. Unlock Swivel Casters.
4. Roll Cabinet to a flat, level, hard and smooth
surface capable of safely supporting a fully
loaded Cabinet. Do not roll Cabinet over concrete
seams or other rough/uneven surfaces.
5. Lock Swivel Casters.
Note: All Drawers have safety latches
under right ends of Drawer Handles.
6. Connect SJTOW Power Cord to a properly
grounded, GFCI-protected 120VAC outlet. Keep
Power Cord off the ground to prevent damage.
WARNING! To prevent serious injury from electric shock
and fire, ensure all cords are positioned where they will
not be pinched or cut by Drawer or Caster movement.
Keep Power Cord off the ground to prevent damage.
7. Plug devices into the Power Strip inside Drawer
on the right-hand side. Turn switch on.
Power
Strip
Switch
8. Unlock Drawers, and fill Cabinet evenly, from
bottom to top. Do not exceed weight capacities.
9. If the power to the outlets turns off,
check the following:
a. Check that switch has not been bumped to the
off position. Turn the switch off and on again.
b. Unplug Cabinet’s power cord from the wall.
Check that all device cords are
undamaged and not pinched.
c. If circuit breaker keeps tripping, check that
Power Strip’s amp rating is not exceeded and
all attached devices are working properly.
Page 8 For technical questions, please call 1-888-866-5797. Roller Cabinet
Maintenance and Servicing
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If any part becomes damaged,
have the problem corrected before further use.
TO PREVENT SERIOUS INJURY FROM ELECTRIC SHOCK:
Disconnect the Power Cord from the Cabinet before maintenance and servicing.
1. PERIODICALLY, inspect the general
condition of the Cabinet. Check for:
• loose hardware,
• misalignment or binding of moving parts,
• brake operation,
• caster swivel function and movement,
• cracked or broken parts,
• any other condition that may
affect its safe operation.
2. Wipe external surfaces of the
Cabinet with clean cloth.
3. Lubricate Drawer Slides as needed.
Page 9For technical questions, please call 1-888-866-5797.Roller Cabinet
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available individually
as replacement parts. Parts may not be interchangeable. Specify UPC when ordering parts:
Black: 70381; UPC 193175496454
Red: 58710; UPC 193175444998
Blue: 70382; UPC 193175496461
Gray: 70314; UPC 193175495754
Green: 70315; UPC 193175495761
Orange: 70316; UPC 193175495778
White: 70318; UPC 193175495792
Yellow: 70319; UPC 193175495808
Page 10 For technical questions, please call 1-888-866-5797. Roller Cabinet
Parts List and Diagram
Parts List
Part Description Qty
1 Rubber Mat 1
2 Side Handle 1
3 Handle Screw (M6X55) 2
4Drawer Trim 8
5 Drawer Latch 8
6 Trim Screw (ST4.8X7.2) 36
7Drawer Trim 4
8 Drawer Latch 4
9Drawer Trim 2
10 Drawer Latch Link 2
11 Drawer Latch 2
12 Drawer Mat 7
13 Drawer Mat 4
14 Drawer Mat 1
15 Drawer Mat 2
16 Drawer Slide 20
17 Lock 1
18 Key 4
19 Lock Link 1
20 Lock Lever 1
21 6″x2″ Fixed Caster 2
Part Description Qty
22 6″x2″ Swivel Caster with Brake 2
23 Power Strip Mounting Plate 1
24 Power Strip 1
25 M6x25 Nut 2
26 M6x25 Bolt 2
27 M8x40 Nut 2
28 M8x40 Bolt 2
29 Bolt 16
A Drawer 1
B Drawer 2
C Drawer 1
D Drawer 1
E Drawer 1
F Drawer 2
G Drawer 1
H Drawer 1
I Drawer 1
J Drawer 1
K Drawer 1
L Drawer 1
Dieses Handbuch passt für folgende Modelle
7
Inhaltsverzeichnis
Andere U.S. General Lagerung Handbücher
Beliebte Lagerung Handbücher anderer Marken
Spectra Logic
Spectra Logic T-Series Spectra T50e Bedienungsanleitung
Panasonic
Panasonic LKM-F931-1 Bedienungsanleitung
Tabernus
Tabernus Enterprise Erase E2400 Bedienungsanleitung
Rocstor
Rocstor COMMANDER 3F series Bedienungsanleitung
HP
HP P9000 Bedienungsanleitung
Western Digital
Western Digital Ultrastar Data60 Bedienungsanleitung
