Ultrakoki COFFEESECRET CS-900 Bedienungsanleitung

COFFEESECRET

Smart Coffee Scale

[CS-900 Operating Manual ]

The instructions in this operation manual apply to coffeesecret smart coffee scale.

Thank you very much for purchasing our smart digital scale.

With normal care and proper treatment it will provide years of reliable service.

Please read all the operating instructions carefully before using the product.

CAUTION

USB

Charging

Port.

1 2

Be careful

for falling.

Remove the

lower scale.

Do not press.

Do not lift up.

Do not beat.

Max.2kgMax.1kg

Do not tilt.

Put back the

lower scale.

1. Due to low battery the new scale isn't turn on. Please charge fully first, then use it.

2. As the smart coffee scale is a precise device, please manipulate with care.

When moving, please hold the wooden handle in one hand and hold the weighing scale in the other hand.

Please try to avoid shakings or other rough handling caused to damages.

3. The maximum weighing capacity for upper scale ring is 1kg.

Please use it not in overloading or not with collision tilt to avoid damages.

4. If you need to remove the lower scale, please grip the wooden handle in one hand and hold the lower scale in the other hand.

After gently taking from Position 1, next take from Position 2. As to installing the lower scale,

please manipulate in reverse direction, i.e. put it back on Position 2 first and then on Position 1 POGOPIN for connecting.

5. The maximum weighing capacity for upper scale is 1kg. The maximum weighing capacity for lower scale is 2kg.

Do not overload.

6. Please do not dismantle any screws to avoid weight inaccuracy, if you are not our maintenance staff.

7. If you need to download app, please visit the web site www.ultrakoki.com or scan the QR code.

Any enquires or services after sale, please e-mail to ser[email protected].

Scale Overview

＊CS-900S: 130mm(L) x 195mm (W) x 210mm (H)

＊Weight:1000g

＊CS-900L: 130mm(L) x 195mm (W) x 260mm (H)

＊Weight:1200g

＊Capacity for the upper scale: 2.2lbs/1kg

＊Capacity for the lower scale: 4.4lbs/2kg

＊Measuring units: oz,g

＊Display: OLED

＊Battery & Power: Rechargable Lithium-ion battery, 3.7V,1000mAh

＊Connectivity: Bluetooth 4.0

＊Colors: Black / White

＊Turn on/ off : Press Key On / Off / Auto-off

Coffeesecret smart coffee scale from Ultrakoki

includes following items:

1. a frame of coffee scale

2. a main unit of coffee scale

3. an operation manual

4. a Micro-USB charging cable(1m)

Material & Components:

＊OLED: glass

＊Scale plate: PMMA ＋Stainless steel

＊Plastic Upper Cover: PMMA

＊Plastic lower Cover: ABS

＊Stand: Aerospace aluminum alloy / preservative stainless steel

Electrical Requirements:

＊Fixed Voltage: DC3.7V

＊Battery: High Density Lithium Polymer Battery - Soft Pack

＊High Stability

Functions:

＊Weighing Range for Upper Scale: 0~1000g

＊Weighing Range for Lower Scale: 0~2000g

＊Division: 0~200g : 0.1g, 200~500g : 0.5g

500g~2000g : 1g

Required Temperature & Humidity:

＊Temperature for Operating: 5-35℃

＊Humidity for Operating: 30-85﹪RH

＊Temperature for Preservation: 20-60℃

＊Humidity for Preservation: 0-95﹪RH

＊Lifetime: 3 years

Lower Scale:

Main Unit

Upper Scale: Stand

Temperature Plate

Anti-slip Design

OLED Display

Detective Touch

Buttons

POGOPIN

Bottom plate

Stand

Filter holder

CONSTRUCTIONS

OF MAIN UNIT SCALE

CONSTRUCTIONS

OF UPPER SCALE FRAME

Functions and Panel illustration

32 1

4.2

4.1 12

78 5.1

11 5.2

1. Power Button & Scale Select: - First Press to turn on the scale.

- Press and Hold for 3 seconds to turn off the scale.

- While brewing, click to switch through 4 different scale modes indicating

"Upper Scale", "Lower Scale", "Upper & Lower Scale", "Upper Scale ＋ Lower Scale".

2. Button for Tare Operation(Zero): Click to tale depending on different scale modes.

3. Start Button: - Click for Learning/Profession modes before Timer mode setting.

- Click for Start/Pause after Timer mode setting.

- Press and Hold for 2 seconds to restart the process.

4. Weighing Indicators: - 4 via 5.1 shows the weighing of the upper scale.

- 4 via 5.2 shows the weighing of the lower scale.

- 4 via 5.1 & 5.2 ashing shows the total weighing of upper and lower scale.

5. - 5.1 for the upper scale, 5.2 for the lower scale.

- Both displays of 5.1 & 5.2 show both weighing or its total weighing value.

6. Weighing Units Indicators: - Pre-setting for g.

-To switch units setting is to be executed via APP.

7. Timer display shows in Timer Mode.

8. Ratio of water and coffee grinds - "Power Off" shows "Zero".

- Auto-Calculating the ratio gure concerning coffee weight in coffee pot/recorded coffee powder while brewing in Timer mode.

- Units: Multiple(×).

9. Temperature Indicator for coffee drip pot.

10.Temperature Units: - Pre-setting for ℃.

- To switch temperature units setting is to be executed via App.

11. "M" shows memory completion of coffee grinds weight.

12. Battery Indicator: Please charge in low battery. Charging. Full Charge.

13. Bluetooth Indicator: - "OLED ON" shows connecting via App.

- "OLED OFF" shows not connecting via App.

Click means less than 1 second button touching.

Teaching Mode of Hand-Drip-Brewing Coffee

Coffee Dripper and Paper Filter for the Upper Scale. Coffee-Drip Pot for the

Lower Scale. Auto-Tare after placing both of items.

If any disabled Zeroing under some factors, please click "T" Button once

again for Zeroing.

Add your required roasted coffee beans to Coffee Dripper with Paper Filter,

once the weight of Upper Scale is detected, then go next step, but the

weight display for Upper Scale shows the current gure.

Step 02

Weighing roasted coffee beans in

Coffee Dripper

Upper Scale Weight

Lower Scale Weight

Step 01

Upper Scale Coffee Dripper & Paper Filter

Lower Scale Coffee-Drip Pot

Upper Scale Weight

Lower Scale Weight

Empty the used water from the Coffee-Drip Pot, then enter next step.

Step 05

Wastewater Empty

Upper Scale Weight

Lower Scale Weight

Pour roasted coffee beans into Grinder , put the Coffee Dripper with Paper

Filter back to the Upper Scale, then enter next step.

Step 03

Grinding roasted coffee beans

Upper Scale Weight

Lower Scale Weight

Pour hot water into Paper Filter, after water dripping, then enter next step.

Step 04

Cleaning Paper Filter with hot water

Upper Scale Weight

Lower Scale Weight

- Indicating for both weighing of the upper and the lower scale. No switching from Step1 to Step8.

- From Step 9 to Step11, pressing Power Button can be switched into 4 different modes like "Upper Scale", "Lower Scale",

"Upper & Lower Scale", "Upper Scale + Lower Scale".

- From Step1 to Sep7, clicking Start button can be switched into the modes for Professional Hand-Drip-Brewing Coffee or

Teaching of Hand-Drip-Brewing Coffee.

Place the Coffee-Drip Pot back to the Lower Scale, after Auto-Zeroing for

Upper and Lower Scale, then enter next step.

Step 06

Place the Coffee-Drip

Pot back

Upper Scale Weight

Lower Scale Weight

You can stop to pour water, when your requested ratio of water and coffee grinds is attained.

There are two methods to complete Drip & Brew, i.e. taking the Coffee Dripper or the

Coffee-Drip Pot out. The indicator for "Completion for Drip & Brew" and the indicator for

nished time calculating display in turn. The digital data for the Ratio of water/coffee grinds

and the added Weight won't be changed while completing.

Press the " " and hold for 2 seconds to restart.

Step 11

Ratio of water and coffee grinds ×

Temperature℃

Completion for

Drip & Brew

Added Weight for the upper

and lower scale

It indicates Time of Pouring water, Ration of water and coffee grinds

(weight of Coffee-Drip Pot with liquid/weight of recorded coffee grinds),

Temperature of Coffee-Drip Pot and Weight of Liquid (The above setting is

for the added weight of the upper / lower scale. If you want to switch

different scale weighing, you can also press "Power Button" at any time.

Step 10

Ratio of water and coffee grinds ×

Temperature℃

Drip & Brew

Timer

Added Weight for the upper

and lower scale

"Start to pour water" ashed displays calculating upon the rst water drip,

then enter next step.

Step 09

Ratio of water and coffee grinds ×

Temperature℃

Start to

pour water

Added Weight for the upper

and lower scale

Click the Start Button for calculating that records the weight of Coffee

Grinds automatically. After Zeroing of the Upper Scale, enter next step.

Step 08

Press " " for operation

Upper Scale Weight

Lower Scale Weight

If any disabled Zeroing before this step, please click "T" Button once again

for Zeroing, then add coffee grinds into the Paper Filter. After stop of

adding, enter next step.

(At the same time, take the Coffee Dripper to adjust Coffee grinds equally,

then place it back to the Upper Scale.)

Step 07

Add coffee grinds

Upper Scale Weight

Lower Scale Weight

Professional Mode of Hand-Drip-Brewing Coffee

From Step1 to Sep7, clicking "Start Button" can be switched into the learning mode for Hand-Drip-Brewing Coffee or the

professional mode of Hand-Drip-Brewing Coffee.

Please enter directly Step 7" Add Coffee Grinds" for the Professional Mode of Hand-Drip-Brewing Coffee.

You can stop to pour water, when your requested ratio of water and coffee grinds is attained.

There are two methods to complete Drip & Brew, i.e. taking the Coffee Dripper or the

Coffee-Drip Pot out. The indicator for "Completion for Drip & Brew" and the indicator for

nished time calculating display in turn. The digital data for the Ratio of water/coffee grinds

and the added Weight won't be changed while completing.

Press the " " and hold for 2 seconds to restart.

Step 11

Ratio of water and coffee grinds ×

Temperature℃

Completion for

Drip & Brew

Added Weight for the upper

and lower scale

It indicates Time of Pouring water, Ration of water and coffee grinds

(weight of Coffee-Drip Pot with liquid/weight of recorded coffee grinds),

Temperature of Coffee-Drip Pot and Weight of Liquid (The above setting is

for the added weight of the upper / lower scale. If you want to switch

different scale weighing, you can also press "Power Button" at any time.

Step 10

Ratio of water and coffee grinds ×

Temperature℃

Drip & Brew

Timer

Added Weight for the upper

and lower scale

"Start to pour water" ashed displays calculating upon the rst water drip,

then enter next step.

Step 09

Ratio of water and coffee grinds ×

Temperature℃

Start to

pour water

Added Weight for the upper

and lower scale

Click the Start Button for calculating that records the weight of Coffee

Grinds automatically. After Zeroing of the Upper Scale, enter next step.

Step 08

Press " " for operation

Upper Scale Weight

Lower Scale Weight

If any disabled Zeroing before this step, please click "T" Button once again

for Zeroing, then add coffee grinds into the Paper Filter. After stop of

adding, enter next step.

(At the same time, take the Coffee Dripper to adjust Coffee grinds equally,

then place it back to the Upper Scale.)

Step 07

Add coffee grinds

Upper Scale Weight

Lower Scale Weight

FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/ TV technician for help.

CAUTION:

Any changes or modifications not expressly approved by the grantee of this device could void the user's

authority to operate the equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired

operation.

RF exposure warning

The equipment complies with FCC RF exposure limits set forth for an uncontrolled

environment.

The equipment must not be co-located or operating in conjunction with any other

antenna or transmitter.

Warning:

Inhaltsverzeichnis

Andere Ultrakoki Skala Handbücher

Ultrakoki

Ultrakoki CS900 Bedienungsanleitung

Beliebte Skala Handbücher anderer Marken

AWS

AWS ZEO-50 Bedienungsanleitung

Gima

Gima Glass Body Fat Analyzer Stücklistenhandbuch

Seca

Seca 374 Bedienungsanleitung

TEC

TEC TEC SL59 SERIES Bedienungsanleitung

Axis

Axis B/E Series Bedienungsanleitung

Alecto

Alecto ACW-40 Bedienungsanleitung

Rice Lake

Rice Lake MSI-4260 IS Bedienungsanleitung

IKA

IKA RCT basic safety control Bedienungsanleitung

ADE

ADE M20011 Bedienungsanleitung

Duronic

Duronic KS3000 Bedienungsanleitung

Digi

Digi SM-720 Bedienungsanleitung

Cardinal

Cardinal CS Series Bedienungsanleitung

Korona

Korona Kastella Bedienungsanleitung

A&D

A&D FC-50Ki Bedienungsanleitung

BDA

BDA CAMARGUE Bedienungsanleitung

Tanita

Tanita HD-357 Bedienungsanleitung

Leifheit

Leifheit 03173 Bedienungsanleitung

Lumme

Lumme LU-1340 Bedienungsanleitung
