iColor®500 Apparel Plus Printer

User Manual







UniNet 3232 W. El Segundo Blvd., Hawthorne, California 90250 | [email protected]

www.icolorprint.com



2



Table of Contents



iColor®500ModelSummaryPage3

PrinterSoftwareInstallationInstructionsPage4‐6

PrinterSettingsforiColor®TransferMediaPage7‐9

WhiteprintInstructionsPage10

MultipurposetraysettingsPage11‐13

iColor®TransferRIPInformationPage14

iColor®500PrinterSpecSheetPage15

iColor®500PrintingTipsPage16‐17



UniNet 3232 W. El Segundo Blvd., Hawthorne, California 90250 | [email protected]

www.icolorprint.com



3

iColor®500 Apparel Plus Printer



TheiColor®500printerhasbeendevelopedtoproducehigh‐qualityconventionalcolorprintswiththeoutof

theboxfunctionalityofprintinginwhite.

Pleasefollowtheenclosedquicksetupguidetogetstarted.Thestandardusermanual(providedonCD

enclosed)willprovidedetailedinstructionsforfullprinterfunctionality.TheiColor®500comescompletewith

4tonercartridgesforfullcolorandblackprinting(CMYK),aswellasourexclusivefluorescentwhiteprinting

kit(toneranddrumcombination).Justquicklyswaptheblackforwhitewhenyouwanttoaddwhiteeffects.

Blackcanthenbeproducedusingcompositeblack(madefromCMY),oriftrueblackandwhiteisneededat

thesametime,justpasstheprintthoughtheprinterasecondtime.Ourregistrationsystemwillensurethe

printsarelinedupperfectly.

Youwillalsohavetheoptiontoaddourfullfluorescentkitwhichcomescompletewith3[CMY]toner

cartridgesandmatchingdrumunits.Thissystemrequiresnoadditionalsoftwareorexpertisetoprint

conventionalCMYKimagesinvividfluorescentcolor.

Pleasenotethatvectorandlineartimages,includingtext,arelikelytoproducethebestresults.Forexciting

designideasandsuggestionsforusingtheiColor®500formaximumeffect,pleasevisitourwebsiteat

www.iColorprint.com.

iColor®premiumtransfermediahasbeenoptimizedtoprovidequalityresultswhenusedwiththeprinter,

enablingtheusertoproduceeye‐catchingdesignswhichmaybeappliedtoavarietyoftextilesandsurfaces.





UniNet 3232 W. El Segundo Blvd., Hawthorne, California 90250 | [email protected]

www.icolorprint.com



4



Installing iColor®500 printer on a PC

TheseinstructionsareforWindows7viaUSBcable,othersaresimilar.YoumusthaveAdministrator

privilegesonthecomputer.



1. UnpacktheprinteraccordingtotheSet‐upGuide.Donotturnitonorconnectittothecomputeruntilthe

installprogramasksyoutodoso.



2. PuttheinstallationDVDintothedriveandsetupshouldautomaticallyrun.



3. Chooseyourlanguageandselectprintermodel(targetdevice)C711.



4. Afteracceptingthesoftwareagreementandgoingpasttheenvironmentaladvicepages,youcanselect

softwaretoinstall.ClicktheNextbutton.



Also,nearthebottomofthisaretheonlinemanualsforlaterreference.





UniNet 3232 W. El Segundo Blvd., Hawthorne, California 90250 | [email protected]

www.icolorprint.com



5



Theinstallationwillproceed,clickNextafterhavingtheprinterandcablesasdescribed.



 



6. ClickEasyInstallation(Local)thenNext.Thenyouwillseethedialogboxbelow



UniNet 3232 W. El Segundo Blvd., Hawthorne, California 90250 | [email protected]

www.icolorprint.com



6



7. Usuallythenextscreenwillshowtheinstallationprogress,followedbytheFinishscreen.Ifnot,clickthe

InstallusinganotherportbuttonandaccepttheUSBdefaultshown.



Rename the Printer



1. Navigatefromthestartmenutothelistofinstalledprinters.TheWindow7pathis:



2. RightclickontheprinterOKIC711(PS)andselecttheprinterproperties.



3. OntheGeneraltabhighlighttheprinternameandchangeitto‘iColor500’,thenclickOK







UniNet 3232 W. El Segundo Blvd., Hawthorne, California 90250 | [email protected]

www.icolorprint.com



7



iColor®500 printer settings for iColor®

Premium Transfer Media

TheseinstructionsareshownusingthePostScriptorPSdriver.ThechoicesarethesameforthePCLdriver

butthedialogboxesaredifferent.



ThesecanbesetasPrinterPreferencesfromDevicesandPrintersorasDocumentPropertieswhenprinting.

SettingthemasPrinterPreferencesmeanstheywillbethesamethenexttimeyouusetheprinter.

1. UnderthePaper/Qualitytab,setthepapersourcetotheMulti‐purposeTray.







UniNet 3232 W. El Segundo Blvd., Hawthorne, California 90250 | [email protected]

www.icolorprint.com



8



2. ClickAdvancedbutton.Papertypeshouldbe

‘MediumLight’andthepagesizeshouldbe

‘A4’.Ifyouareprintingaverydenselycovered

page,itissuggestedyouchoose“heavy”for

thepapertypetoavoidapaperjamatthe

fuser.Ifyoudogetapaperjam,shutoffthe

printer,removethefuserandclearthejam,

thenprintsometestpagesonregularpaperto

cleartheexcesstoneroutofthefuser.Then

reprintwith“heavy”papersettings.



3.TheJobOptionstabisnormallyleftatdefaults.

Wesuggesttheprintqualitybesetto“Fine”.Click

theAdvancedbuttonandselecttheoptionfor

MirrorPrint.Thiswillensuretheimagelookscorrect

whentransferredtoagarment.Note:ThePCL

Driverdoesnotincludethisoption.



UniNet 3232 W. El Segundo Blvd., Hawthorne, California 90250 | [email protected]

www.icolorprint.com



9



4.ClicktheColortabandturnofftheTonerSavemode.TheColorSwatchUtilityallowsyoutoprinta

rangeofcolorstofindsettingsmatchingtheoneyouwant.Thehelpbuttononitdescribeshowtodothis.



5. Pleasedonotalteranyofthefactorysettingsonthemachineitself.Doingsocanproduceundesired

results







UniNet 3232 W. El Segundo Blvd., Hawthorne, California 90250 | [email protected]

www.icolorprint.com



10



Using white with the iColor®500 Printer

WiththeWhitekitinstalled,themachinewillprintwhitewheretheimage/textdisplaysblack,bydefault.

Pleasenotethatvectorandlineartimages,includingtext,arelikelytoproducethebestresults.Youmust

createimagesusingtrueblack:



CMYK: C:0%M:0%Y:0%K:100%



Thisistrueblackcolor.Textandgraphicscreatedinthiscolorwillgivethebestwhiteresultswhenprinted.

Theseprinterswillalsoprintcompositeblackwiththewhitekitinstalled.Fortrueblackprinting,simply

replacethewhitekit,withtheincludedblackkit.



Using white with colors to assure transfer of

halftones

Imagesthatcontainhalftonesorgradientscancauseproblemswithself‐weedingtransfermedia.Thisis

becausethebackgroundisassumedtobewhiteandnothingisprintedthere.

Itisusuallyeasiesttouseanimageeditingprogramtocreateacopyoftheimageusingtrueblackas

illustratedabove.Selecttheentireimageandchangethecolor,savingasaseparatefile.

Printthestandardcolorsontoatransfersheetfirst,thenprintthetrueblackimageyousavedpreviouslyover

theprintedcolorimagebypassingthetransfersheetthroughtheprinterasecondtimeusingthemulti‐

purposetray.FromtherefollowtheusualprocessfortheiColor®premiumtransfermedia.


