Model UT60B/C/E: OPERATING MANUAL
3
Model UT60B/C/E: OPERATING MANUAL
Overview
This Operating Manual covers information on safety and
cautions. Please read the relevant information carefully
and observe all the Warnings and Notes strictly.
Warning
To avoid electric shock or personal injury, read the
“Safety Information” and “Rules for Safe Operation”
carefully before using the Meter.
Digital MultimeterModelUT60B, UT60CandUT60E
(hereafter referred to as “the Meter”) has autorange and
manual range options with maximum reading 3999. The
enclosure structure design adopted advanced “co-injection”
technique in order to provide sufficient insulation.
In addition to the conventional measuring functions, there
is a RS232C standard serial port equipped with Model
UT60E for easy connection with computer to realize
macro recording and monitoring and capture of transient
dynamic data, displaying change of waveform during the
measurement, providing data and evidence to engineering
technicians for scientific research.This is also a highly
applied digital multimeter of good performance with full
overload protection and backlight function. Model UT60E
also has true rms reading for AC voltage andAC current
measurements.
Except where noted, the descriptions and instructions in
this Operating Manual apply to all Model UT60B/UT60C
/UT60E .
Unless otherwise identified, all figures show the Model
UT60B.
Qty
1 piece
1 pair
1 pair
1 piece
1 piece
1 piece
1 piece
Item
1
2
3
4
5
6
7
Description
Operating Manual
Test Lead
Test Clip
Model UT60E:CD-ROM (Installation
Guide & Computer Interface Software)
Model UT60C/UT60E:Point
Contact Temperature Probe
Model UT60E:RS232C Interface Cable
9V Battery (NEDA1604, 6F22 or 006P)
(installed)
Model UT60B/C/E: OPERATING MANUAL
CAT IV: Primary supply level, overhead lines, cable
systems etc.
4
Unpacking Inspection
Open the package case and take out the Meter. Check the
following items carefully to see any missing or damaged part:
In the event you find any missing or damage, please
contact your dealer immediately.
Safety Information
This Meter complies with the standards IEC61010: in
pollution degree 2, overvoltage category (CAT. III 1000V,
CAT. IV 600V;)and double insulation.
CAT. III: Distribution level, fixed installation, with smaller
transient overvoltages than CAT. IV
Use the Meter only as specified in this operating manual,
otherwise the protection provided by the Meter may be
impaired.
In this manual, a Warning identifies conditions and
actions that pose hazards to the user, or may damage
the Meter or the equipment under test.
A Note identifies the information that user should pay
attention on.
International electrical symbols used on the Meter and
in this Operating Manual are explained on page 6.
Rules For Safe Operation
To avoid possible electric shock or personal injury, and to
avoid possible damage to the Meter or to the equipment
under test, adhere to the following rules:
lBefore using the Meter inspect the case. Do not use the
Meter if it is damaged or the case (or part of the case) is
removed. Look for cracks or missing plastic. Pay
attention to the insulation around the connectors.
lInspect the test leads for damaged insulation or exposed
metal. Check the test leads for continuity. Replace
damaged test leads with identical model number or
electrical specifications before using the Meter.
lDo not apply more than the rated voltage, as marked on
the Meter, between the terminals or between any
terminal and grounding.
lThe rotary switch should be placed in the right position
and no any changeover of range shall be made during
measurement is conducted to prevent damage of the
Meter.
lWhen the Meter working at an effective voltage over 60V
inDC or 30V rms in AC, special care should be taken for
there is danger of electric shock.
lUse the proper terminals, function, and range for your
measurements.
lDo not use or store the Meter in an environment of high
temperature, humidity, explosive, inflammable and
strong magnetic field. The performance of the Meter
may deteriorate after dampened.
lWhen using the test leads, keep your fingers behind the
finger guards.
lDisconnect circuit power and discharge all high-voltage
capacitors before testing resistance, continuity, diodes,
current, or capacitance.
lBefore measuring current, check the Meter’s fuses and
turn off power to the circuit before connecting the Meter
to the circuit.
lReplace the battery as soon as the battery indicator " "
appears. With a low battery, the Meter might produce
false readings that can lead to electric shock and
personal injury.
lRemove test lead, temperature probe, RS232C interface
Warning
5
Model UT60B/C/E: OPERATING MANUAL
Model UT60B/C/E: OPERATING MANUAL
cable and test clip from the Meter and turn the Meter
power off before opening the Meter case.
lWhen servicing the Meter, use only the same model
number or identical electrical specifications replacement
parts.
lThe internal circuit of the Meter shall not be altered at
will to avoid damage of the Meter and any accident.
lSoft cloth and mild detergent should be used to clean the
surface of the Meter when servicing. No abrasive and
solvent should be used to prevent the surface of the Meter
from corrosion, damage and accident.
l
l
l
l
The Meter is suitable for indoor use.
Under the environment with high (+/-4kV) electrostatic
discharge, the Meter may not be operated as normal
condition. The user may require resetting the Meter.
Please take out the battery when it is not being used
for a prolonged period to avoid damages to the Meter.
Please constantly check the battery as it may leak
when it has been using for some time, replace the
battery as soon as leaking appears. A leaking battery
will damage the Meter.
6
International Electrical Symbols
AC (Alternating
Current) Deficiency of Built-In
Battery
DC (Direct Current) Continuity Test
AC or DC Diode
Grounding Capacitance Test
Double Insulated Fuse
Warning. Refer to the
Operating Manual Conforms to Standards
of European Union
The Meter Structure(see figure 1)
(figure 1)
1 LCD Display
2 Functional Buttons
3 Rotary Switch
4HzV Input Terminal:
Input for voltage, frequency/duty cycle, resistance, diode,
continuity and capacitance measurements.
5COM Input Terminal:
Return terminal for all measurements.
Model UT60B:Input Terminal:
Input for 0.1 A to 400.0mA current measurements.
Input Terminal:
Input for 0.1 A to 400.0mA current measurements and
temperature testing.
710AInput Terminal:
Input for 0.01A to 10.00A current measurements.
7
Model UT60B/C/E: OPERATING MANUAL
Rotary Switch
Below table indicated for information about the rotary switch
positions.
Rotary
Switch
Position Function
VDC voltage measurement range from 400.0mV to
1000V or
AC voltage measurement range from 4.000V to
750.0V.
Continuity test.
Diode test.
Resistance measurement range from 400.0
Temperature in celsius
Hz Frequency measurement range from 10.00Hz to
10.00MHz.
AC or DC current measurement range from
A.
mA AC or DC current measurement range from
40.00mA to 400.0mA.
AAC or DC current measurement range from
4.000A to 10.00A.
to 40.00M .
Model UT60B/C/E: OPERATING MANUAL
8
Below table indicated for information about the functional
button operations.
Button Measuring
Function Operation Performed
POWER Any rotary
switch
position
Turn the power on and off.
VSwitches between AC and DC
voltage; the Meter beeps. DC is
default.
Model UT60B:Switches between
continuity and diode and resistance
measurements; the Meter beeps.
Resistance is default.
Model UT60C/UT60E:Switches
between continuity and diode and
resistance and capacitance
measurements; the Meter beeps.
Resistance is default.
Switches between AC and DC
current range from 400.0 A to
4000 A; the Meter beeps. DC is
default.
mA Switches between AC and DC
current range from 40.00mA to
400.0mA; the Meter beeps. DC is
default.
ASwitches between AC and DC
current range from 4.000A to
10.00A; the Meter beeps. DC is
default.
Disable Sleep Mode feature.
(BLUE)
Functional Buttons (1)
9
Model UT60B/C/E: OPERATING MANUAL
RANGE
Any rotary
switch
position
exceptHz
and
lPressRANGE to enter the
manual ranging mode; the Meter
beeps.
Manually selecting a range causes
the Meter to exit the Hold and REL
modes.
lPressRANGE to step through
the ranges available for the
selected function; the Meter beeps.
lPress and hold RANGEfor 2
seconds to return to autoranging;
the Meter beeps.
Hz 1. Press to start the frequency
counter; the Meter beeps.
2. Press again to enter duty cycle
mode; the Meter beeps.
3. Press again to return to the
frequency counter mode; the Meter
beeps.
Hz %
V, ,
mA or
A
1. Press to start the frequency
counter; the Meter beeps.
2. Press again to enter duty cycle
mode; the Meter beeps.
3. Press again to return to the
previous measurement mode; the
Meter beeps.
REL
Any rotary
switch
position
except Hz
Press to enter
and exit the REL mode in any
measuring mode except in
frequency/duty cycle; the Meter
beeps.
Any rotary
switch
position
PressHOLD H to enter and exit
the Hold mode in any mode, the
Meter beeps.
REL
Functional Buttons (2)
HOLD H
10
Model UT60B/C/E: OPERATING MANUAL
Dieses Handbuch passt für folgende Modelle
2
Inhaltsverzeichnis
Andere Unit Multimeter Handbücher
Unit
Unit UT15B PRO Bedienungsanleitung
Unit
Unit UT161 Series Bedienungsanleitung
Unit
Unit UT39E Bedienungsanleitung
Unit
Unit UT50D Bedienungsanleitung
Unit
Unit UT30B Bedienungsanleitung
Unit
Unit UT117C Bedienungsanleitung
Unit
Unit UT8806E Bedienungsanleitung
Unit
Unit UT61D Bedienungsanleitung
Unit
Unit UT8806E Bedienungsanleitung
Unit
Unit UT804 Bedienungsanleitung
Unit
Unit UT805A Bedienungsanleitung
Unit
Unit UT71C Bedienungsanleitung
Unit
Unit UT805 Bedienungsanleitung
Unit
Unit UT132B Bedienungsanleitung
Unit
Unit UT51 Bedienungsanleitung
Unit
Unit UT60C Bedienungsanleitung
Unit
Unit UT58E Bedienungsanleitung
Unit
Unit UT58D Bedienungsanleitung
Unit
Unit UT33B Bedienungsanleitung
Unit
Unit UT2000 series Bedienungsanleitung
Beliebte Multimeter Handbücher anderer Marken
Gossen MetraWatt
Gossen MetraWatt METRAmax 6 Bedienungsanleitung
PeakTech
PeakTech 4000 Gebrauchs- und Pflegehandbuch
YOKOGAWA
YOKOGAWA 90050B Bedienungsanleitung
Gossen MetraWatt
Gossen MetraWatt METRALINE DMM16 Bedienungsanleitung
Fluke
Fluke 8846A Bedienungs- und Wartungshandbuch
Tempo Communications
Tempo Communications MM200 Bedienungsanleitung
