Unit UT81C Bedienungsanleitung
P/N:110401103423
Model UT81C
OPERATING MANUAL
Chapter Title Page
6
6
7
8
8
10
11
11
12
13
15
15
15
17
19
19
20
20
22
27
29
31
33
Model UT81C: OPERATING MANUAL
1
Table of Contents
1 Before You Start
Overview
Unpacking Inspection
Safety Information
Rules For Safe Operation
International Electrical Symbols
2 Using The Testing Tool
Reading the screen
The Meter Structure
Functional Buttons
3 Making Measurements
A. Scope Mode
i. Setting up the Sleep Mode, Contrast, Beep
ii. ACV, DCV, Hz, ACV and DCA Range
iii. Trigger function
iv. Waveform data save and recall
B. Digital Multimeter Mode
i. Measuring Voltages
ii. Measuring Currents
iii. Measuring Resistance
iv. Testing Diodes
v. Testing for Continuity
vi. Measuring Frequency / Duty Cycle
2
Model UT81C: OPERATING MANUAL
35
37
38
38
39
40
41
41
42
43
43
44
44
45
45
46
46
47
48
49
49
50
Chapter Title Page
Table of Contents
A.
B.
C.
D.
E.
F.
G.
DC Voltage
AC Voltage
DC Current
AC Current
Resistance
Diode Test
Continuity Test
vii. Measuring Capacitance
4 Using Software
5 Maintenance The Test Tool
A. General Service
B. Replacing the Fuses
C. Replacing the Battery
6 Specifications
Safety and Compliances
Physical Specifications
General Specifications (Digital Multimeter)
General Specifications (Scope)
Feature Summary
Basic Specifications (Digital Multimeter)
Basic Specifications (Scope)
Detailed Accuracy Specifications
3
Model UT81C: OPERATING MANUAL
50
51
Chapter Title Page
Table of Contents
H. Frequency and Duty Cycle %
I. Capacitance
4
Model UT81C: OPERATING MANUAL
7
10
11
13
Table Title Page
List of Tables
1-1 Unpacking Inspection
1-2 International Electrical Symbols
2-1 Reading the Screen
2-2 Functional Buttons
5
Model UT81C: OPERATING MANUAL
12
13
17
21
23
24
25
27
29
31
33
35
39
40
Figure Title Page
List of Tables
2-1 Meter Structure
2-2 Functional Buttons
3-1 Waveform Display
3-2 Voltages Measurement
3-3 μA Range Measurement
3-4 mA Range Measurement
3-5 10A Range Measurement
3-6 Resistance Measurement
3-7 Diode Test
3-8 Continuity Test
3-9 Frequency / Duty Cycle Measurement
3-10 Capacitance Measurement
5-1 Fuse Replacement
5-2 Battery Replacement
6
Model UT81C: OPERATING MANUAL
Overview
This Operating Manual covers information on safety
and cautions. Please read the relevant information
carefully and observe all the Warnings and Notes
strictly.
Warning
To avoid electric shock or personal injury, read the
“Safety Information” and “Rules for Safe Operation”
carefully before using the Meter.
Scope Digital Multimeter UT81C (hereafter referred to
as “the Meter”) is a 3999 counts and 3 3/4 digits adopting
digital control techique with both waveform and
multimeter all in one.
Scope mode is a complete intelligent measurement
system including signal input, sampling, data process,
auto search and waveform save and recall. It has
Chapter 1
Before You Start
bandwidth UT81C:16MHz real-time sample rate 80MS/s
with peak rate sampling process can catch up pulse
industrial signal. It can measure AC/DC engine,
transducer, circuit, control, UPS and industrial
equipments. It is an ideal tools in professional repairing
industries.
Digital Multimeter mode can measure AC voltage and
current, DC voltage and current, Resistance,
Capacitance, Frequency, Duty Cycle, Diodes and
Continuity.
7
Item Description Qty
Model UT81C: OPERATING MANUAL
Unpacking Inspection
Open the package case and take out the Meter. Check the items shown on Table 1-1 carefully to see any missing
or damaged part:
In the event you find any missing or damage, please contact your dealer immediately.
1
2
3
4
5
6
7
8
9
10
English Operating Manual
USB interface cable
CD-ROM (Installation Guide & Computer Interface Software)
Test Lead
Alligator Clip
Power Adaptor
1.5V Batteries (R6)
Carrying bag
Scope Probe (available at extra cost)
BNC probe (available at extra cost)
1 piece
1 piece
1 piece
1 pair
1 piece
1 piece
4 pieces
1 piece
1 piece
Table 1-1. Unpacking Inspection
8
Model UT81C: OPERATING MANUAL
Safety Information
This Meter complies with the standards IEC61010 safety
measurement requirement: in pollution degree 2,
overvoltage category (CAT. II 1000V, CAT.III 600V) and
double insulation.
CAT.II: Local level, appliance, PORTABLE EQUIPMENT
etc., with smaller transient overvoltages than CAT. III
CAT. III: Distribution level, fixed installation, with smaller
transient overvoltage than CAT. IV
Use the Meter only as specified in this operating manual,
otherwise the protection provided by the Meter may be
impaired.
In this manual, a Warning identifies conditions and
actions that may pose hazards to the user, or may
damage the Meter or the equipment under test.
A Note identifies the information that user should pay
attention to.
Warning
International electrical symbols used on the Meter and
in this Operating Manual are explained on page 10.
Rules For Safe Operation
To avoid possible electric shock or personal injury,
and to avoid possible damage to the Meter or to the
equipment under test, adhere to the following rules:
Before using the Meter inspect the case. Do not
use the Meter if it is damaged or the case (or
part of the case) is removed. Look for cracks
or missing plastic. Pay attention to the insulation
around the connectors.
Inspect the test leads for damaged insulation or
exposed metal. Check the test leads for
continuity. Replace damaged test leads with
identical model number or electrical
specifications before using the Meter.
Do not apply more than the 1000V rms between
any terminal and grounding to avoid electric
