Unit UT321 Bedienungsanleitung
Table of Contents
4
7
8
10
12
16
16
17
17
18
18
18
19
19
19
20
21
Title Page
Safety Information
Getting Started
Components
Display Elements
Buttons
Using the Thermometer
Changing Setup Options
Entering and Exiting Setup
Changing the Logging Interval
Changing the Thermocouple Type
Changing the Offset (T1)
Changing the Offset (T2)
Sleep Mode
Changing the Line Frequency
Setting the Time
Setting the Low Limit Alarm (Lo)
Setting the High Limit Alarm (Hi)
1
Model UT321/322/323/325: OPERATING MANUAL
23
23
24
25
25
26
26
26
26
27
27
27
28
29
29
30
31
31
Title Page
Measuring Temperatures
Connecting a Thermocouple
Displaying Temperatures
Holding the Displayed Temperatures
Turning on and off of display backlight
Viewing the MIN, MAX, and AVG Readings
Using the Offset to Adjust Probe Errors
Over Limit Alarm
Over Limit Signal Output
Debug
Using Memory
Starting and Stopping Logging
Viewing Logged Readings
Clearing Memory
Communicating with a PC
Enabling or Disabling Over Limit Signal Output
Enabling or Disabling Normal Temperature Compensation (NTC)
Enabling or Disabling Debug
Model UT321/322/323/325: OPERATING MANUAL
2
Maintenance
Replacing the Battery
Cleaning the Case
Specifications
Environmental
General
Electrical
Title Page
32
32
32
33
33
33
33
Model UT321/322/323/325: OPERATING MANUAL
3
Safety Information
The Uni-Trend Model UT321, UT322, UT323 and UT325 Thermometers (‘the
thermometer) are microprocessor-based, digital thermometers designed to use
external J-, K-, T-, E-, R-, S- and N- type thermocouples (temperature probes) as
temperature sensors.
UT321: T1, suitable for K-, J-, T- and E- type thermocouples
UT322: T1 and T2, suitable for K-, J-, T- and E- type thermocouples
UT323: T1, suitable for K-, J-, T-, E-, R-, S- and N- type thermocouples. Equipped
with over limit alarm, over limit signal output and user self-debug features.
UT325: T1 and T2, suitable for K-, J-, T-, E-, R-, S- and N- type thermocouples.
Equipped with over limit alarm, over limit signal output and user self-debug features.
Use the thermometer only as specified in this manual. Otherwise, the protection
provided by the meter may be impaired.
Model UT321/322/323/325: OPERATING MANUAL
4
Refer to safety information in Table 1 and the international symbols in Table 2.
Table 1. Safety Information
Before using the thermometer inspect the case. Do not use the thermometer if it
appears damaged. Look for cracks or missing plastic. Pay particular attention to the
insulation around the connectors.
Disconnect the thermocouple(s) from the thermometer before opening the case.
Replace the batteries as soon as the battery indicator ( ) appears. The possibility
of false readings can lead to personal injury.
Do not use the thermometer if it operates abnormally. Protection may be impaired.
When in doubt, have the thermometer serviced.
Do not operate the thermometer around explosive gas, vapor, or dust.
Do not apply more than the rated voltage, as marked on the thermometer (30V|),
between the thermocouple(s), or between any thermocouple and earth ground.
When potential differences are anticipated between the thermocouples, use electrically
insulated thermocouples.
When servicing the thermometer, use only specified replacement parts.
Do not use the thermometer with any part of the case or cover removed.
Warning
A warning identified conditions and actions that pose hazards to the user. To avoid
electrical shock or personal injury, follow these guidelines:
Model UT321/322/323/325: OPERATING MANUAL
5
Caution
A caution identifies conditions and actions that may damage the meter or the
equipment under test.
Use the proper thermocouples, function, and the range of your thermometer.
When carrying two thermocouples measurement, make sure there are no
potential differences between two thermocouples.
Do not attempt to recharge the battery.
Match the + and – polarities of the battery with the battery case.
Table 2. International Symbols
Refer to the manual for information about this feature
Complies with European Union directives
Battery
Model UT321/322/323/325: OPERATING MANUAL
6
Getting Started
Everything in this Users Manual applies to all Models of UT321, UT322, UT323 and
UT325 unless otherwise indicated.
To become familiar with the thermometer, study the following:
Figure 1 and Table 3 describe the components
Figure 2 and Table 4 describe the display.
Figure 3-a and 3-b and Table 5 describes the functions of the buttons.
Then read the following sections.
Model UT321/322/323/325: OPERATING MANUAL
7
Figure 1. Components
Model UT321/322/323/325: OPERATING MANUAL
8
Table 3. Components
Display
Buttons
Thermocouple T1 input
Thermocouple T2 input (UT323 and UT325 only)
USB Port
SIGN Port - Over Limit Signal Output (UT323 and UT325 only)
NTC
Battery Door
9V battery (6F22 )
1
2
3
4
5
6
7
8
9
Model UT321/322/323/325: OPERATING MANUAL
9
Model UT321/322/323/325: OPERATING MANUAL
10
