MT650 Video T&A Terminal

MT650

User’s Manual

400815G Version 1.1

About This Manual

Preface

This manual explains how to install, operate and maintain the MT650 Video

T&ATerminal. No part of this publication may be reproduced or used in any

form, or by any electrical or mechanical means, without permission in writing

from the manufacturer. This includes electronic or mechanical means, such as

photocopying, recording, or information storage and retrieval systems. The

material in this manual is subject to change without notice.

Unitech global website address: http:\\www.unitech-adc.com

Microsoft, Windows and ActiveSync are either registered trademarks or

trademarks of Microsoft Corporation. Other product names mentioned in this

manual may be trademarks or registered trademarks of their respective

companies and are hereby acknowledged.

Regulatory Compliance Statements

FCC Warning Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if

not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following:

¾Relocate the receiving antenna.

¾Increase the separation between the equipment and receiver.

¾Connect the equipment into an outlet on a circuit that is different from

the receiver.

¾Consult the dealer or an experienced radio/television technician for

help.

1. This Transmitter must not cohabitate or operate in conjunction with any

other antenna(s) or transmitter(s).

2. This equipment complies with FCC RF radiation exposure limits set forth

for an uncontrolled environment. To maintain compliance with FCC RF

exposure compliance requirements, avoid direct contact to the

transmitting antenna during transmission.

3. Any changes or modifications (including the antennas) made to this device

that are not expressly approved by the manufacturer may void the user’s

authority to operate the equipment.

This equipment must be installed and operated in accordance with provided

instructions and the antenna(s) used for this transmitter must be installed to

provide a separation distance of at least 20 cm from all persons and must not

be co-located or operating in conjunction with any other antenna or transmitter.

Canadian Compliance Statement

This Class B Digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

Cet appareil numérique de la classe B respecte les exigences du Règlement

sur le matériel broilleur du Canada.

European Conformity Statement

Declaration of Conformity with Regard to the R&TTE 1999/5/EC and EMC 89/336/

EEC directives.

RoHS Statement

This device conforms to RoHS (Restriction of Hazardous Substances)

European Union regulations that set maximum concentration limits on

hazardous materials used in electrical and electronic equipment.

Notices

The unit is equipped with a Lithium-Ion battery pack.After extended storage

periods, however, the unit may not power-on without external power due to

battery discharge. In this case connect the unit to the power cable and

recharge the unit for about 6 hours to charge the battery to full capacity.

The battery supplies operational power to the unit for approximately 1 hour

iii

(depending on hardware configuration and with limited backlight use) or

provides backup RTC data for 6 days when there is no external power

connected.

Battery Charge Notice

It is important to consider the environmental temperature whenever the

Lithium-Ion battery pack is charged. Charging is most efficient at normal room

temperature or in a slightly cooler environment. It is essential that the battery

are being charged within the stated range of 0°C to 45°C. Charging the battery

outside of the specified range could damage the battery and shorten their

charging life cycle

Storage and Safety Notice

Although charged Lithium-Ion battery may be left unused for several months,

their capacity may be depleted due to build up of internal resistance. If this

happens they will require recharging prior to use. Lithium-Ion battery may be

stored at temperatures between -20°C to 60°C, however they may be depleted

more rapidly at the high end of this range. It is recommended to store the

battery within normal room temperature ranges and replace the used battery

with a new one every year.

Warranty

Under unitech limited Warranty, the following items are covered:

zThe MT650 Video T&ATerminal is covered by one-year limited warranty.

zCables are covered by one-year limited warranty.

zBattery is covered by a one-year warranty.

Table of Contents

Preface

Regulatory Compliance Statements...........................................................i

Notices......................................................................................................ii

Warranty .................................................................................................. iii

Chapter 1

Introducing the MT650..............................................................................1

Package Contents ....................................................................................3

Tour of the MT650.....................................................................................4

Setting up the MT650 ...............................................................................5

Turning the MT650 on for the First Time...................................................6

Chapter 2

Using the Keypad .....................................................................................9

Using the Stylus......................................................................................11

Using Proximity, MSR, or Barcode Reader.............................................11

Testing Reader Data........................................................................12

Using the Mifare Reader.........................................................................12

Using the Finger Print Reader ................................................................15

Using the Camera...................................................................................17

Chapter 3

Establishing Device-PC Connection.......................................................19

Setting up the Wireless Local Area Network Card...........................20

Using ActiveSync....................................................................................21

Installing Microsoft ActiveSync.........................................................22

Connecting the Device to Your Computer........................................22

Chapter 4

Charging the Backup Battery for the First Time......................................25

Checking the Battery Status ............................................................25

Extending Battery Life.............................................................................26

Changing the Automatic Power Settings..........................................26

Adjusting the Backlight ....................................................................27

Performing a Hardware Reset ................................................................27

Performing a Cold Boot ...................................................................27

Appendix A System Specification ................................................................29

Appendix B Overview of the Terminal Block................................................31

Terminal Block Pin Assignment........................................................32

Relay ...............................................................................................32

Digit Input ........................................................................................32

Appendix C Worldwide Support...................................................................33

Getting Started

Chapter 1

Introducing the MT650

Thank you for purchasing the MT650 Video T&ATerminal. Your MT650 was

designed for users needing a compact and durable computer for data

collection and real time transactions.

The MT650 is a T&A(Time management and access control) terminal with a

large 480 x 640 pixel color touch screen and the Windows CE operating

system. The MT650 was designed to meet the requirements of Time &

Attendance, Loyalty Programs, and Work-In-Process applications.

The MT650 communicates with central host security and T&Asystems through

standard Ethernet or WLAN networks. The built-in CMOS digital camera,

microphone, and audio speaker provide complete area security with a small

footprint.

The MT650 features a variety of built-in readers including proximity and finger

print identification. Powered by Windows CE.NET 6.0, the MT650 package

includes programming tools and support software for developing custom

security and provides cost-efficient solution for T&A applications.

Features

Powerful system

zMicrosoft Windows CE 6.0

Professional Plus operating

system

zSamsung 6410 processor with

speeds up to 667Mhz

System memory

z256 MB SDRAM

z256 MB Flash ROM

Expansion slot

zSD memory slot

Proximity reader

zEM, 125kHz

zHID, 125kHz

zMifare, 13.56MHz

Wireless connectivity

z802.11b/g

Communication

zRS232/485

zUSB 1.1 host

zOutput relays x 2

zEthernet connection

zPower over Ethernet

Display

z5.7inch VGA LCD touch-sensitive

screen

z480 x 640 resolution

Multimedia

z2.0 megapixel CMOS camera

zAudio output via 0.8 watt speaker

zBuilt-in microphone

Fingerprint reader

zSensor: Suprema SFM3020-OP

zVerification time: 1 second

zEqual Error Rate: <0.1%

zEnrollment time: 1 second

zTemplate capacity: 1900 at 1MB

flash

zTemplate format: Suprema or ISO

19794-2 standard

Battery life

zNormal usage: 1 hour

zCharging time: 6 hours

User interface

zSix hard keys

zTouch-sensitive screen with stylus

Software programming tools

zVisual Studio

zC++, C#, VB.NET
