At last, a control sytem that bridges the gap between
digital media and the home entertainment system...
MX-6000
Two Way Touch Screen
With PSX-1 Personal Audio Video Server
MX-6000: The Networked Home Theater Revolution Begins...
The revolutionary MX-6000
brings the power of WiFi networking
to the home theater, without compro-
mising simplicity.
The MX-6000 is the first home the-
ater remote control to offer two inde-
pendent communications and control
methods simultaneously. The MX-
6000 provides both a narrow band
418 MHz transmitter for instant con-
trol of conventional home theater
components and a WiFi transceiver
for high speed transfer of cover art,
artist, album and title metadata.
The MX-6000 offers home theater
owners instant no rules control of AV
receivers, flat screen TVs, projectors,
cable and satellite receivers, DVD
players and changers.
Unlike other WiFi remote controls, the
MX-6000 uses a second RF (Radio
Frequency) transmitter to control con-
ventional gear instantly, without the
frustrating delay of waiting for the
remote control to "join the network"
when you simply want to turn the sys-
tem on.
There are three possible companion
RF base stations that provide instant
control. The MSC-400 Master System
Controller enhances the capabilities of
the MX-6000 by storing and issuing
Smart Macros to your main system
components. These smart macro
commands offer the ultimate in relia-
bility and speed, since a single com-
mand, measuring fractions of a sec-
ond, can trigger long complex macro
routines with RS-232, IR, relays or
even USB keyboard commands to a
PC.
The MRF-350 and MRF-260 RF base
stations enable an MX-6000 to
address or route IR commands to con-
ventional components anywhere
in your home. By placing MRF base
stations near your TVs, cable/sat
receivers and other conventional IR
controlled components, you can
enjoy instant, no pointing, no rules
operation everywhere in your home.
At last, you can fully control the
lighting in your home without expen-
sive black boxes and exotic wiring. A
lighting system can be as simple as a
single URC RF lamp dimmer on a
lamp that you’d love to control with-
out getting out of your chair.
The MX-6000 directly controls lights
connected to URC RF Dimmers and
Switches. You can brighten, dim, and
recall scenes, and you can store new
scenes whenever you like, without a
PC or a programmer. Simply manual-
ly adjust each dimmer to the new set-
ting, then press and hold the scene
button on your MX-6000 (just like
storing radio stations in your car!).
When the MX-6000 is connected to
the Internet, pre-programmed mod-
ules enable instant access to person-
alized news, sports, weather and
stocks.
Unlike other devices, the MX-6000’s
news, sports, weather and stocks
modules are user-configurable with-
out a programmer or a PC. On a
whim, you can check out the oppos-
ing team’s scores, or get the weather
forecast for a vacation destination.
WiFi Speed Brings Cover Art, Artist, Album and Titles
to the Touch Screen!
Internet Connection Provides Real Time News,
Sports, Weather and Stocks
Narrow Band RF for Instant Control of Home
Theater Components without Delays at Turn On
Native Lighting Control —
Touch the Screen to Set a New Scene!
The high speed of the built-in 802.11 B/G WiFi transceiver enables the MX-6000 to
display lists of artists, albums or songs and to display the cover art of the selected
album on the Now Playing screen of the remote control.
News, Sports, Weather and Stocks modules
require that the MX-6000 be installed to a
WiFi router with an Internet connection.
Installation by Stone Glidden of King of Prussia, PA.
No Installer Required for
New Content!
You Add New Content
from any PC or Mac with
iTunes on the Network
The secret to the unique PSX-1 is the
storage drive. The PSX-1 doesn’t have
one. Instead you insert any iPod (even
a visiting friend’s) into the docking con-
nector. The PSX-1 includes PSXLink
software for both Macs and PCs. Any
new content you add to your iTunes
library can be synchronized to the iPod
in the PSX-1 without ever removing it.
Of course, a single MX-6000 can con-
trol any number of PSX-1s. So if your
family has a number of iPods, you may
choose to install multiple PSX-1s, one
for each family member. Conveniently,
the PSX-1 has a customizable label on
the front and docks magnetically with
another PSX-1 beside it.
Extraordinary Automation
iPod docks just put files on a TV. Only
URC's PSX-1 adds the exciting features
that turn your iPod into a true Personal
Server. Everything you’ve downloaded,
from podcasts to music videos, movies
and TV shows is selectable on the
screen of the MX-6000.
Once you touch the unique personal
server features, the difference between
looking at endless lists and the revolu-
tionary automation of the PSX-1
becomes extraordinarily attractive.
At last, complicated actions are simple
and intuitive. PSX-1 makes it easy to
explore your large collection in previ-
ously impossible ways.
PSX-1: Personal Audio Video Server for the MX-6000
Complete Editing Control
At any time, you can choose to View
the Jukebox. When viewing the
Jukebox, new controls appear that
allow you to change the order of the
songs in the list, delete or search for
new items to add. Of course, at any
time you can clear the entire Jukebox
playlist and start again.
Search for Any Artist,
Album or Song
The “search” button appears in the
upper right whenever you are looking
at a Menu or Jukebox screen. Once
you click on Search, an alphabetical
keyboard appears. Simply type in as
many letters as you like, then touch
“Go.” You can enter characters using a
number, qwerty, or alphabetic key-
board.
Both Composite and
HD Component Video
The PSX-1 is equipped with installer
selectable Composite and HD quality
Component Outputs to match the out-
put of your iPod.
Shortcuts to finding playlists,
albums, artists, etc. without
endless ups and downs in
menus.
Shuffle exactly what you
want (this album, this
artist, this genre, etc.)
More from this artist, this
album, this genre, even this
composer...
Jukebox lets you build and
manage your own playlist
without accessing your PC.
Six Screen Labeled Buttons give you fast access to
frequently used commands like Play, Pause, Skip, etc.
Shortcuts to Any Content
Instantly Without Menus
The “Shortcuts” button makes navigat-
ing from videos to musical genres a
simple process.
Example: Touch the “Artists” button on
the shortcuts screen to jump directly to
the Artists menu.
Unlike other iPod docks or traditional
music servers, you are not forced to
constantly navigate up, down, left and
right through a maze of menus to
access new audio video content.
Explore Your Content:
Shuffle Exactly What You
Feel Like Listening To
With other music servers, shuffle is a
frustrating mix of too many kinds of
music. With the PSX-1, shuffle becomes
a powerful tool for listening and explor-
ing your music collection.
Imagine shuffling just your jazz, or just
the songs of a particular artist. You can
shuffle play any genre, any artist or any
album at any time by simply accessing
the MX-6000’s shuffle screen.
Play More From:
When Something Catches
Your Fancy...
Imagine exploring all the hard rock
albums of your youth with Shuffle
Genres. When you hear a song you
love, instead of having to browse
through the hundreds of artists in your
collection, you simply touch the ”Play
More From” button. By then selecting
the “More from this Artist” button, all
the songs from the current Artist will be
played in sequential order.
Friends Coming Over?
Make Your Own Jukebox
Playlist in Seconds
Arranging the perfect music to play-
back for any event is a delightful activi-
ty with the PSX-1. You can freely play
music, browsing and shuffling as you
like. When you hear something you’d
like to add to your Jukebox playlist,
simply touch “Add Song to Jukebox” or
“Add Album to Jukebox” on the
Jukebox screen. To play the jukebox
you’ve created, simply touch “Play
Jukebox”.
Rotate the Scroll wheel
exactly like an iPod to
navigate lists of artists,
albums, videos, etc.
Press the OK button
to select content.
Press the Menu button
to browse back to the last
list you displayed.
PC Server for MX-6000 Reinventing the Touch Screen
Instead of purchasing an expensive
“Media PC” or dedicated music
server, any PC with iTunes and/or
Windows Media Player can be
connected to your audio system to
act as a high powered music server
with the most engaging, intuitive user
interface you’ve ever seen.
Up to now, the complexity of having
to deal with a keyboard and a mouse
in your listening room has made this
an uncomfortable choice.
You know the frustrating feeling—
some of your music was downloaded
via iTunes and some of your music
via Windows Media Player, you’ve
had to keep separate libraries.
Finding the music you paid for was
difficult.
MX-6000 Server is a software
application that once installed on a
PC, combines your iTunes library
with your Media Player library. The
MX-6000 utilizes its network
connection via WiFi to communicate
with the server software on the PC.
Since all communication happens at
WiFi “G” speeds, there are no lags or
delays displaying the information or
lists on the screen of the MX-6000.
All your cover art, artist, album and
song title metadata appear on the
screen of the MX-6000. Lists are
navigated via the integrated scroll
wheel without ever connecting a
keyboard or mouse to the PC.
At last, you have access to all the
music you’ve paid for... all the music
you want without the hassles... the
music simply plays...
Converts any PC with iTunes or Windows Media
Player into a Powerful Music Server with an Intuitive,
Friendly User Interface
The MX-6000 browses the combined library of content you downloaded from iTunes
and content you purchase or burn with Windows Media Player. When you select a
song, the correct player is automatically selected and loaded in an instant.
Installation by Stone Glidden of King of Prussia, PA.
Automatic Backlighting
The integral motion sensor
detects any movement of the
touch screen and automatically
backlights the screen. The user
does not have to press any button
to display the screen. Any move-
ment of the MX-6000 renews the
backlighting. Without movement,
the touch screen stays lit for 1 to
99 seconds (programmed by the
installer).
Not Just Color, Animated
Color!
Powered by a 533MHz ARM9
microprocessor, the MX-6000 is
the first touch screen designed for
animation. The powerful central
processor enables quick, fluid
page transitions and animated
macros. The 4.3” screen offers a
480x272 pixel window to any
graphic. Your professional
installer can place BMPs, JPEGs,
GIFs, animated GIFs or FLASH
SWF files in your configuration.
The World of Sound
Equipped with a speaker and a PC
recording, your installer can add
talking help buttons (recorded on
any PC with a microphone) or music
to your macros via any WAV file.
The MX-6000’s profile (shown life size in
this image) is carefully contoured to nat-
urally fit the hands of the end user.
The back of the
MX-6000 is tex-
tured in soft
rubber to give
the user a com-
fortable and
secure grip.
When not is use, the MX-6000 sits on its
recharging cradle.
Double Capacity Lithium
Ion Batteries and
Charging Base
The demands of WiFi and high speed
transfers coupled with a large color
touch screen raise the demand for
power to a new high. The MX-6000
is equipped with a unique double
capacity Lithium Ion battery, provid-
ing over 4 hours of continuous use
before recharging is necessary.
Should the MX-6000 be left on a
table, it will remain in standby mode
for ten days without requiring a
recharge.
The attractive charging base offers an
ideal angle to use while charging, so
may be placed on or near your chair.
In addition, the MX-6000 offers a
power input on its side panel, so that
it can be hand held while charging
directly from the power adapter.
Powered by
Designed for the Most Discriminating...
Refined by the Experience and Feedback of
Thousands of Professional Installers
500 Mamaroneck Avenue
Harrison, NY 10528
Phone: (914) 835-4484
Fax: (914) 835-4532
More information on Complete
Control and other Universal
Remote Control products are avail-
able on the web at:
www.universalremote.com
© 2008 Universal Remote Control, Inc.
Complete Control is a registered trade-
mark of Universal Remote Control, Inc.
Universal Remote Control Lighting by
Lutron is a trademark of Universal
Remote Control, Inc and Lutron
Electronics, Inc. All other brand or prod-
uct names are trademarks or registered
trademarks of their respective companies
or organizations.
MX-6000 Touch Screen Specifications
Microprocessor: ARM9 core @533MHz
4.3" Wide Screen TFT (480 x 272
QVGA) 65,536 Colors
Memory - 128 Megabytes of SDRAM
Devices - Up to 255 Devices with text,
less with heavy graphics
Pages - Up to 255 Pages per device
with text, less with heavy graphics
Learning Capability - Standard frequen-
cies (15kHz to 455kHz)
Macro Capability - Up to 255 steps each, however nesting is allowed
IR Range (Line of Sight via Infrared): 30-50’ depending on the environment
RF Range (radio frequency): 50 to 100’ depending upon the environment
RF Frequency: 418MHz
WiFi: IEEE802.11 b(11Mbps)/g(54Mbps)
Batteries: Lithium Ion battery pack included
Battery Capacity: 4800mAh (4 hours of continuous use, 9 Days in standby)
Weight: 15 oz. (with battery)
Size: 7.5" x 5.1" x 1.3"
PSX-1 Personal Server Specifications
Microcontroller: 166MHz ARM922T
Flash memory: 16Megabit
RAM: 64Megabit SDRAM
Jukebox Entries: Supports up to 1024 songs
Jukebox Memory: Volatile, but retained when the same iPod is removed and
re-inserted. Jukebox is deleted when a different iPod is inserted or on reboot
(or power failure)
Front Panel IR Sensor: Receives URC PSX-1 commands via IR
IR Range (Line of Sight via Infrared): 20-30’ depending on the environment
Rear Panel IR Input: Compatible with all MRF and MSC base stations
Ethernet: 10Base-T/100Base-TX network connector
Audio: 2 RCA audio output connectors (L + R)
Composite Video: 1 RCA video output connector (Composite)
Component Video (Y/Pr/Pb): 3 RCA video output connectors
Power: 12V DC (minimum 650 Milliamp wall adapter required)
Size: 6.75” W x 5” D x 1.6” H
Weight: 13.5 oz
COMPLETE
™
CONTROL
COMPLETE
Andere Handbücher für MX-6000 -
1
Andere Universal Remote Control Fernbedienung Handbücher
Universal Remote Control
Universal Remote Control UR2-DTA Bedienungsanleitung
Universal Remote Control
Universal Remote Control Aurora MX-950 Betriebsanleitung
Universal Remote Control
Universal Remote Control UR-S475TVE Bedienungsanleitung
Universal Remote Control
Universal Remote Control PHAZR-5 Bedienungsanleitung
Universal Remote Control
Universal Remote Control Easy Clicker UR3-SR2 Bedienungsanleitung
Universal Remote Control
Universal Remote Control UR4U-MDVR2 Bedienungsanleitung
Universal Remote Control
Universal Remote Control Medius TX-1000 Complete Control Bedienungsanleitung
Universal Remote Control
Universal Remote Control PHAZR-5 Bedienungsanleitung
Universal Remote Control
Universal Remote Control UR2-DTA Bedienungsanleitung
Universal Remote Control
Universal Remote Control RF30 MASTERCONTROL Bedienungsanleitung
Universal Remote Control
Universal Remote Control UR4-EXP Bedienungsanleitung
Universal Remote Control
Universal Remote Control UR5-8400 Bedienungsanleitung
Universal Remote Control
Universal Remote Control Clikr-5 UR5U-8820L Bedienungsanleitung
Universal Remote Control
Universal Remote Control MX-900 Bedienungsanleitung
Universal Remote Control
Universal Remote Control UR5-8400 Bedienungsanleitung
Universal Remote Control
Universal Remote Control UR4U-MDVR2 Bedienungsanleitung
Universal Remote Control
Universal Remote Control PHAZR-5 Bedienungsanleitung
Universal Remote Control
Universal Remote Control PHAZR-5 series Bedienungsanleitung
Universal Remote Control
Universal Remote Control UR3-J22TWM Bedienungsanleitung
Universal Remote Control
Universal Remote Control CLIKR-5 UR5U-8500 Bedienungsanleitung
Universal Remote Control
Universal Remote Control UR-J2000TVE Bedienungsanleitung
Universal Remote Control
Universal Remote Control Easy Clicker UR3-SR3-DTA Bedienungsanleitung
Universal Remote Control
Universal Remote Control Complete Control MX-810I Bedienungsanleitung
Universal Remote Control
Universal Remote Control Easy Clicker UR2-211 Bedienungsanleitung
Beliebte Fernbedienung Handbücher anderer Marken
Panasonic
Panasonic EUR7622KB0 Bedienungsanleitung
Bang & Olufsen
Bang & Olufsen Beo4 Bedienungsanleitung
Sunwave Tech.
Sunwave Tech. RemoteComm SRC-7000 Bedienungsanleitung
Multiplex
Multiplex PROFI TX 9 Bedienungsanleitung
One Remote
One Remote RMB4 Bedienungsanleitung
FUTABA
FUTABA 9ZAP - PART2 Bedienungsanleitung
