UTC RETAIL PD1200 Betriebsanleitung

PD1200 POLE DISPLAY

PROGRAMMING GUIDE

Congratulations on your purchase of UTC RETAIL’s innovative PD1200 Pole Display!

Designed to suit virtually any POS environment, the PD1200 Pole Display is as user-

friendly as it is customer-friendly. The display features selectable baud rates, 360°pole

rotation and 20°tilt.

The PD1200 Pole Display is a 2 line by 20 character vacuum fluorescent display, with

four programmable display intensities. The PD1200 can have a DB9 RS-232 Serial

interface, or a standard USB 1.1 interface.

This guide is designed to demonstrate how to efficiently program UTC RETAIL’s

PD1200 Pole Display. This guide is not designed for users who are using their PD1200

in an OPOS or JavaPOS Environment.

11393104 Rev G PD1200 Pole Display Programming Guide

UTC RETAIL2

PD1200 Pole Display Programming Guide

February, 2004

retrieval system, or transmitted in any form or by any means, electronic or

mechanical, including photocopying, recording, or otherwise, without the prior

written permission of UTC RETAIL

This Programming Guide was prepared by UTC RETAIL for use by Qualified

Service Personnel Only. All attempts have been made to ensure that the

information presented in this manual is correct. No liability, expressed or implied,

will be assumed by UTC RETAIL, its dealers, or affiliates, for damage resulting

from the use of this information.

If a unit needs to be shipped to UTC RETAIL for repairs, please return it in the

original packing material and shipping container. If you purchased the PD1200

Pole Display through a dealer, and the dealer is unable to answer your questions,

please call UTC RETAIL Technical Support at 1.800.349.0546.

This equipment has been tested and found to comply with the limits for a Class “A”

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference, in which case the user will be required to correct the interference at

his/her own expense.

UTC RETAIL

100 Rawson Road

Victor, NY 14564

1.800.349.0546

fax: 1.585.924.1434

www.utcretail.com

PD1200 Pole Display Programming Guide

UTC RETAIL 3

TABLE OF CONTENTS

PRODUCT INFORMATION.............................................................................................4

PD1200 Pole Display Components.................................................................4

Features..........................................................................................................5

General Specifications....................................................................................6

Service and Warranty......................................................................................7

PROGRAMMING............................................................................................................8

Display Control Features and Commands.......................................................8

Display Control.........................................................................................9

Dimming Feature......................................................................................9

Back Spacing Feature..............................................................................9

Horizontal Tab Feature...........................................................................10

Line Feeding Feature.............................................................................10

Carriage Return Feature ........................................................................10

Display Position Feature ........................................................................11

Normal Display Mode Feature................................................................11

Vertical Scroll Mode Feature..................................................................11

Reset Feature........................................................................................11

Flashing Text Start Feature....................................................................12

Flashing Text Stop Feature....................................................................12

Clear to End of Line Feature..................................................................12

Clear to End of Display Feature .............................................................12

Home and Clear Display Feature...........................................................12

Display Character Codes .......................................................................13

TECHNICAL INFORMATION........................................................................................14

Cable Pinouts................................................................................................14

Serial Operating Parameters selection..........................................................15

Jumper tables ........................................................................................15

USB Operating Parameters selection............................................................16

INDEX...........................................................................................................................18

11393104 Rev G PD1200 Pole Display Programming Guide

UTC RETAIL4

PRODUCT INFORMATION

The PD1200 is a 2 line, 20 character per line, Vacuum Fluorescent Display (VFD)

unit attached to a pole-mounting base. The serial version of the PD1200 ships

factory set for 9600 baud, 8 data bits, and no parity.

PD1200 Pole Display Components

You will find the following components inside the PD1200 Pole Display Box:

•VFD display and pole

•Hat bracket

•Cables

•Wall transformer

PD1200 Pole Display Programming Guide

UTC RETAIL 5

Features

The following is a list of the PD1200 Pole Display features:

•2 Line − 20 Character/Line Vacuum Fluorescent Display

•10.5 mm Character Height

•5 x 7 Dot Matrix

•RS232 Serial or USB 1.1

•360 Degree Rotation

•10 Degree Bi-directional Tilt

•4 Selectable Baud Rates (RS-232 Only)

•4 Programmable Display Intensities

•Flashing Text

•Vertical Scrolling

11393104 Rev G PD1200 Pole Display Programming Guide

UTC RETAIL6

General Specifications

NAME SPECIFICATIONS

Number of Characters 2 rows of 20 characters

Character Configuration 5 x 7 Dot Matrix

Character Set ASCII

Character Height 10.5 mm

Character Width 5.5 mm

Character Pitch 7.4 mm (Horizontal)

Peak Wave Length of

Illumination Green (505 nm)

Luminance 690 cd/m

(204fL)

Height 23”

Weight 2.50 lbs.

Width 8.75”

Depth 1.80”

Operating Temperature 0 to +50 degrees C

Storage Temperature -20 to +70 degrees C

Relative Humidity 90% Non-Condensing (Max.)

Power Requirements +5 VDC @ 800 mA

PD1200 Pole Display Programming Guide

UTC RETAIL 7

Service and Warranty

The PD1200 Pole Display comes with a three-year parts and labor warranty.

Assistance and customer service is always available from UTC RETAIL Technical

Support. If your dealer or service provider cannot answer your questions or

provide satisfactory service, please call UTC RETAIL Technical Support. When

calling for assistance or service information, please be ready to provide the model

number, part number and serial number of the pole display. This information is

found on a decal located on the bottom of the pole display.

If the pole display needs to be returned to a repair facility, please use the original

packing material and shipping carton.

The address and telephone numbers to be used for assistance, service, and

warranty information are:

UTC RETAIL

100 Rawson Road

Victor, NY 14564

1.800.349.0546

fax: 1.585.924.1434

www.utcretail.com

11393104 Rev G PD1200 Pole Display Programming Guide

UTC RETAIL8

PROGRAMMING

The PD1200 Pole Display operates by converting recognized data, supplied by a

communicating device, into a display message. The supplied data may also

contain commands that control the display.

The PD1200 uses a limited command structure for display control, requiring

minimal programming effort. Table 3-1 lists the display control features of the

PD1200 and control codes (in ASCII, DEC, and HEX expression). The display

control command structure, with examples, is described in this section.

Display Control Features and Commands

The following table outlines the PD1200 Pole Display control features and

commands:

FEATURE ASCII DEC HEX

Dimming* <EOT>x 4, x 04, xx

Back Space <BS> 8 08

Horizontal Tab <HT> 9 09

Line Feed <LF> 10 0A

Carriage Return <CR> 13 0D

Display Position* <DLE>p 16,p 10,pp

Normal Display <DC1> 17 11

Vertical Scrolling <DC2> 18 12

Reset <US> 31 1F

Flashing Text Start* <FS> 28 1C

Flashing Text Stop* <GS> 29 1D

Clear to End of Line** <CAN> 24 18

Clear to End of Display** <EM> 25 19

Home and Clear Display <RS> 30 1E

* See command subsection for special information regarding the USB PD1200

** This command is not supported on the USB PD1200

PD1200 Pole Display Programming Guide

UTC RETAIL 9

Display Control

The command and data sequence for all display control features follows the

following structure:

Dimming <EOT>x 04 DEC 04 HEX

Dimming Feature

The dimming command sets the brightness level for the characters displayed.

Where x is the option byte:

Dim Low Medium High

x = 20h 40h 60h FFh

USB Note: Both bytes of the command must be sent in one write to the port,

splitting the bytes between writes will not work.

DIMMING LEVEL ASC II DEC HEX

100 % - 255 FF

60 % ‘ 96 60

40 % @ 64 40

20 % Space 32 20

Back Spacing Feature

Back Spacing <BS> 08 DEC 08 HEX

When the backspace command is executed, the write-in position is shifted to the

left one position, erasing the character, if any, in that position. When the write-in

position is in the first (read from left to right) position of the first row, the write-in

moves to the last position of the second row. When the write-in is in the first

position of the second row, the write-in moves to the last position of the first row.

11393104 Rev G PD1200 Pole Display Programming Guide

UTC RETAIL10

Horizontal Tab Feature

Horizontal Tab <HT> 09 DEC 09 HEX

DC1 Mode

(Normal Display Mode)

The write-in position is shifted to the right one position. When the write-in is in the

last position of the first row, the write-in moves to the first position of the second

row. When the write-in is in the last position of the second row, the write-in moves

to the first position of the first row.

DC2 Mode

(Vertical Scroll Mode)

When the write-in is in the last position of the second row, the characters displayed

in the second row are shifted up to the first row and the write-in moves to the first

position of the second row. This action clears the second row.

Line Feeding Feature

Line Feeding <LF> 10 DEC 0A HEX

DC1 Mode

(Normal Display Mode)

The write-in moves up or down to another row, staying in the same horizontal

position.

DC2 Mode

(Vertical Scroll Mode)

When the write-in is in the second row, the characters displayed there are shifted

up to the first row, leaving the write-in at its present position. This action clears the

second row. When the write-in is in the first row, the write-in moves down to the

second row.

Carriage Return Feature

Carriage Return <CR> 13 DEC 0D HEX

The write-in moves to the first position of the same row.
