UTC RETAIL 2170 Bedienungsanleitung
© 2013 UTC RETAIL. All rights reserved. 11921015 Rev A
2170 POS System
2170 User Guide
Thank you for selecting UTC RETAIL’s innovative Model 21 0 Point of Sale solution!
This guide is designed to acquaint you with the features and functionality of the 21 0 Point of
Sale System.
11921015 Rev A 2 © 2013 UTC RETAIL.
All rights reserved.
2170 POS System User Guide
All rights reserved. No part of this document may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic or mechanical, including
photocopying, recording, or otherwise, without the prior written permission of UTC RETAIL.
This User Guide was prepared by UTC RETAIL for use by Qualified Service Personnel only.
All attempts have been made to ensure that the information presented in this manual is
correct. No liability, expressed or implied, will be assumed by UTC, its dealers, or affiliates,
for damage resulting from the use of this information.
If a unit needs to be shipped to UTC RETAIL for repairs, please return it in the original
packaging material and shipping container. If you purchased the 21 0 POS System through
a dealer, and the dealer is unable to answer your questions, please call UTC RETAIL
Technical Support at 1.800.349.0546.
This equipment has been tested and found to comply with the limits for a Class “A” digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference, in which case the user will be required to correct
the interference at his/her own expense.
WARNING: CMOS Battery Damage
Replace your system’s CMOS RAM battery only with identical CR-2032 3V ithium-Ion
coin cell (or equivalent) battery type to avoid risk of personal injury or physical damage to
your equipment. Always dispose of used batteries according to the manufacturer’s
instructions, or as required by the local ordinance (where applicable). The damage due to
not following this warning will void your motherboard’s manufacture warrantee.
All access to internal components is restricted to Authorized Service personnel only.
© 2013 UTC RETAIL. 3 11921015A Rev A
All rights reserved.
Contents
21 0 POS System User Guide ................................................................................................... 2
Product Information .................................................................................................................... 4
21 0 POS System Components .......................................................................... 4
Peripheral Support............................................................................................... 4
21 0 POS System Specifications ........................................................................ 5
I/O Panel ............................................................................................................. 5
Connector Panel View ................................................................................ 5
COM Ports .................................................................................................. 6
Cash Drawer Interface ................................................................................
Supported Peripheral Options Details ..................................................................
Power Requirements ...........................................................................................
Connect Power Cable ................................................................................. 8
Expansion Options .............................................................................................. 8
Hard Drive Removal ................................................................................................................... 8
System Installation Guide .......................................................................................................... 9
11921015 Rev A 4 © 2013 UTC RETAIL.
All rights reserved.
Product Information
The 21 0 Touch Screen POS Workstation is designed for use in restaurants, convenience
stores, cafeterias and other specialty retail establishments. It is highly configurable, has easy
access to connectors, and includes a large selection of interface ports for connectivity to
printers, cash drawers, scanners, keyboards, and other peripherals.
2170 POS System Components
You will find the following components inside the 21 0 POS System box:
• 21 0 POS
• Safety Sheet
• A/C power cord
• Two (2) RJ-45 to DB-9 serial port adapter dongles
Note: Options that were purchased from UTC RETAIL such as a keyboard, customer
display and printer may be shipped in separate bo es.
Depending on the configuration you have purchased, the following optional items may also be
installed onto the 21 0 POS:
• Magnetic Stripe Reader (MSR) unit
• Rear Customer Display (RCD) unit
• 8.4” Rear LCD Display
Peripheral Support
• The 21 0 POS System accepts a standard PC keyboard with a USB interface. UTC
RETAIL P/N 10 18020 contains both a USB keyboard and USB mouse.
• The 21 0 POS System was designed to coordinate with the UTC RETAIL PD1200 Pole
Display option.
• The 21 0 POS System supports many different printers, such as the Epson H6000 or
TM-T88.
© 2013 UTC RETAIL. 5 11921015A Rev A
All rights reserved.
2170 POS System Specifications
2170
Processor Intel
®
Atom™ D2550 (1.86 GHz)
System Memory 2GB DD 3-1066 (up to 4 GB)
Hard Drive 320GB (min), 60GB (min) SSD optional
Front Side Bus 800 MHz
Graphics Intel
®
Integrated
SVGA Yes
S-232 4
USB Interface Ports 4
Network Port 10 / 100 / 1000 ealtek LAN
Customer Displays (optional)
1. 2-line x 20 character PD1200 VFD – free standing
2. 2-line x 20 character VFD – integrated
3. 8.4” LCD
MS (optional) ID Tech 3 Track
Keyboard options Standard PC with USB interface
Cash Drawer Optional
Dimensions (W x D x H) 12.75” x 11.75” x 4.25”
Operating Systems Windows POS eady 2009, POS eady 7, Windows 7
Professional
I/O Panel
Connector Panel View
The photo above is of the panel below the touchscreen LCD. The labeled I/O ports are self-
explanatory to an experience PC user. To the left of the locking power port (to your right as you
face the 21 0) is the system power on/off switch (circled in red above) which was deliberately
chosen for its small size to prevent accidental power downs. The USB ports are standard USB
2.0, the COM ports are explained below. The cash drawer port accepts a RJ12 jack; your POS
application can access this port directly. This cash drawer port has a power setting of 19VDC.
The LAN jack is for standard RJ45 network cables, DC IN is the port for the supplied AC
adapter and VGA is a standard 15-pin SVGA port.
11921015 Rev A 6 © 2013 UTC RETAIL.
All rights reserved.
COM Ports
There are 4 COM ports on the 21 0; they are standard RS-232.The COM3 and COM4 ports
have been configured to supply +5VDC power to pin 9 of their DB9 connector. COM3 and
COM4 may supply up to 0.5A of current; do not exceed this limit.
Note: COM3 and COM4 may also be configured for pin 9 to be RI (ring indicator) or to
supply +12V 0.5A. This configuration must be performed at the UTC RETAIL facility.
The table below summarizes the RS232 DB9 pin definitions:
PIN NO.
1
2
3
4
5
6
7
8
9
Signal CD RX TX DTR GND DSR RTS CTS
RI or 5V/12V
output
(as
explained
above)
Use the supplied RJ48 – DB9 adapter cables to connect to the COM ports. Additional cables
are available as P/N 11801015. See the drawing below for the adapter’s pinout.
Figure 1, Serial Port Adapter Pinout
© 2013 UTC RETAIL. 7 11921015A Rev A
All rights reserved.
Cash Drawer Interface
The 21 0 POS I/O panel as a single cash drawer port which is capable of driving a 24VDC cash
drawer. The interface is compatible with the APG Cash Drawer (http://www.cashdrawer.com/ )
CD-005A specification, seen below.
Figure 2, ash Drawer Interface
Supported Peripheral Options Details
USB Serial
Printer Options
H6000IV
TM-T88V
Keyboard Options
Standard PC keyboard
Pole Display Options
PD1200 with external power
adapter
Power Re uirements
The 21 0 POS System has one AC power cord. Connect the power cord to the AC adapter
installed into the system’s base. A dedicated, clean power source is recommended. UTC
RETAIL offers a variety of UPS options. Contact your sales agent.
Voltage: 120 VAC ± 10%
Current: 5 Amps maximum, with all peripherals connected
11921015 Rev A 8 © 2013 UTC RETAIL.
All rights reserved.
Figure 4, HDD seen under the
opened door
Connect Power Cable
Place the 21 0 POS face down on a clean, soft surface, ensuring you do not scratch the front
bezel or the touchscreen.
Plug the supplied AC cord into the power adapter mounted into the base. See photo below.
Stand the system on its feet and snake the power cable through the cutout in the rear of the
base.
Figure 3, A Power ord Attachment
Expansion Options
None, the system does not accept any internal expansion cards.
Hard Drive Removal
The 21 0 POS System is equipped with one easily accessible hard drives.
To remove a hard drive, follow these steps:
1. Shut off all power to the system, unplug the
power cord from the AC outlet.
2. Remove the single screws on the rear panel
and lift off the hard drive access cover.
3. Disconnect the HDD cabling.
4. Replace hard drive.
5. Reconnect the cabling and install the door.
© 2013 UTC RETAIL. 9 11921015A Rev A
All rights reserved.
System Installation Guide
Please refer to the 21 0 POS System Installation Guide, which may be downloaded from the
UTC RETAIL’s website at www.utcretail.com.
Note: Consideration should be taken to ensure that none of the unit vents are blocked. Blocking
the vents may cause damage to the unit. The 21 0 POS has no internal cooling fans and relies
on ambient air to provide system cooling.
Please call UTC RETAIL’s Technical Support at 800.349.0546 if you have any problems not
addressed in this manual or have questions about sections of this documentation.
