Utilitech NT15-20A Bedienungsanleitung
1500W Ceramic Heater
MODEL #NT15-20A
ITEM #3757108
866-994-4148
UTILITECH and logo design are trademarks or
registered trademarks of LF, LLC. All rights reserved.
SM21332
9
1500W
3
4
6
7
8
Package Contents ...........................................................................................................................
Safety Information ...........................................................................................................................
Assembly Instructions ......................................................................................................................
Cleaning and Maintenance ..............................................................................................................
Warranty ..........................................................................................................................................
A
B
C
Thermostat Control
Power and Setting Control
Power indicator light
1
1
1
PART DESCRIPTION QUANTITY
A
B
C
1. Please read the instructions before use this heater.
2. To avoid burns, do not let bare skin touch the hot surface. If provided,
always use the handle to move this heater. Keep it away from
combustible materials such as furniture, pillows, bedding, papers,
clothes and curtains at least 3 feet (0.9m) from the front of the heater
and keep them away from the sides and rear.
3. High attention is necessary when heater is left unattended or used near
your children or the physical-challenging people. Don't leave the heater
alone.
4. Always unplug the heater when there is no need to use.
5. Do not operate or plug in the heater with a damaged cord, especially
when the heater malfunctioned, or was dropped or damaged in any
manner. Discard heater or return heater to authorized service facility for
examination, electrical or mechanical adjustment, or repair.
6. Do not use this heater outside. And it is not intended to use in
bathrooms, laundry areas, or similar indoor locations. Never position
the appliance where it will be splashed by water.
7. Do not cover cord with throw rugs, runners, or similar coverings when
using. And do not route cord under furniture or appliances. Arrange
cord away from traffic area where it will not be tripped over.
8. CAUTION: This appliance has a polarized plug (one blade is wider than
the other). To reduce the risk of shock, the plug is intended to fit only
one way in a polarized outlet. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician. DO
NOT attempt to defeat this safety feature. To do so could result in an
electric shock hazard.
Please read and save this important safety instructions
When using electrical appliances, basic precautions always should be
followed to protect people from fire, electric shock, and injury, including
the following:
5
SAVE THESE INSTRUCTIONS
9. This heater draws 12.5 amps in operation. To prevent overloading a
circuit, do not plug the heater into a circuit that already has other
appliances working.
10.CAUTION: It is normal for the plug to touch warmly, however, loose fit
between the AC outlet and plug may cause overheating and distortion
of the plug. Contact a qualified electrician to replace loose or worn
outlet.
11.To disconnect the heater, first to turn off the heater. Never pull the
cord directly.
12.Do not insert foreign objects into any ventilation or exhaust openings
to avoid an electric shock, fire, or any unexpected damages.
13.CAUTION: Plug heater directly into a wall outlet, do not plug the cord
with an extension cord or relocatable power tap (outlet/power strip).
14.Heater has heat, arcing and sparking parts inside. Do not use it in the
areas where gasoline, paint, or flammable liquids are used or stored.
15.Use this heater only as described ways in this manual. Any other use
is not recommended to avoid fire, electric shock, or injury to persons.
16.Even if the output of this heater may vary, its temperature still may be
intense enough to burn exposed skin. It is not recommended for
person with reduced sensitivity to heat or an inability to react to avoid
burns.
17.To prevent a potential fire, do not block air intakes or exhaust in any
manner. And do not use on cloth surfaces such as a bed, which may
cause serious accident.
Assembly
6
This heater is pre-assembled in factory.
Electrical Ratings
This product is rated 12.5 amps (1500W) at 120V, 60 Hz.
Operating Instructtons
1. Before using the heater, make sure that it is on a flat and stable surface. Damage
may occur if it is placed in an incline or decline.
2. Avoid overloading your circuit by not using other high wattage appliances in the
same outlet. At 1500 Watts, this units draws 12.5Amps.
3. Place the heater on a firm, level surface free from obstructions, and at least 3 ft.
(0.9m) away from any wall or combustible material.
Heat Mode Setting
1. To begin heating operation, tun Thermostat control clockwise to the maximum
setting.
2. Turn the power and setting control to your desired heat settings:
1~700W
2~900W
3~1500W
3. The power light will remain illuminated during operation.
1. Turn the thermostat control clockwise to the highest position to start the heater.
Allow the heater to operate and warm up the room.
2. When the desired temperature/comfort level is reached, lower the temperature
setting by turning the Thermostat Control counterclockwise until the heater stops
operating.
3. The thermostat will automatically maintain the pre-set temperature level by
turning the heat ON and OFF.
NOTE: It is normal for the heater to cycle ON and OFF as it maintains the preset
temperature. To prevent the unit from cycling, raise the temperature setting.
Fan Mode Setting
To use the unit as a cooling air circulator without heat, turn the power fan setting
control to
Thermostat Control
7
Safety Feature
1. Thermal cut-off: This heater includes a thermal cut-off that shuts the heater off if
it overheats due to abnormal conditions. If this occurs, turn the heater off, unplug
it, inspect and remove any objects on or adjacent to the heater. Allow it to cool for
a few minutes, and then plug it back in and resume normal operation.This is not a
defect!
2. Tip over switch: This heater includes a safety tip over switch, which will shut the
heater off in case it is tipped over. If at any time, the heater does tip over, please
place the heater back in the upright position. The heater will resume its normal
operation.
Reset Instrictions
If the unit shuts down please operate as follows:
1. Turn the unit off
2. Unplug unit wait 10 minutes
3. Plug in and turn on
If Your Heater Fails To Operate
1. Be sure it is plugged in and that the electrical outlet is working.
2. Check for any obstruction. If you find an obstruction turn the heater OFF.Unplug
the heater and wait at least ten minutes for it to cool. Carefully remove the
obstruction. Plug the heater back in and restart it as described under
OPERATION.
3. If the unit is operating the same as mentioned above, remove the plug from the
socket and have appliance serviced by authorized electrician only.
We recommend that the heater be cleaned at least once a month and before
off-season storage.
1. Turn the heater OFF and unplug it. Allow it to cool.
2. Use a dry cloth to clean the external surfaces of the heater.
DO NOT USE WATER, WAX, POLISH OR ANY CHEMICAL SOLUTION.
1. Clean your heater using the above-mentioned steps, then pack the heater in its
original container and store in a cool dry place.
2. This heater does not disassemble.
3. The motor is factory lubricated for life, and will require no further lubrication.
CLEANING AND MAINTENANCE
WARRANTY
8
ONE YEAR LIMITED WARRANTY. The manufacturer warrants this product to
be free from manufacturing defects in material and workmanship. This one-year
warranty does not cover transit damages.
This warranty does not apply to the finish on any portion of the product. Serving
performed by unauthorized persons shall render the warranty invalid. For
warranty service, contact Customer Service at 866-994-4148, 8 a.m.- 8 p.m.,
EST, Monday – Sunday.Some states do not allow the limitation or exclusion of
certain damages. Therefore, these limitations and exclusions may not apply to
you. This warranty gives the consumer specific legal rights. You may have other
rights that vary from state to state.
Printed in China
MODELO #NT15-20A
ARTÍCULO #3757108
SM21332
UTILITECH™ y el diseño del logotipo son marcas
comerciales o marcas registradas de LF, LLC.
Todos los derechos reservados.
¿Preguntas, problemas, piezas faltantes? Antes de volver a la tienda, llame a
nuestro Departamento de Servicio al Cliente al 866-994-4148 de lunes a domingo
de 8 a.m. a 8 p.m., hora estándar del Este. También puede comunicarse con
nosotros a través de partsplus@lowes.com o visitar www.lowespartsplus.com.
Fecha de compra
Número de serie
9
Calentador de cerámica
de 1500 vatios
Contenido del paquete .....................................................................................................................11
Información de seguridad .................................................................................................................12
Instrucciones de ensamblaje ............................................................................................................14
Limpieza y mantenimiento ................................................................................................................15
Garantía ...........................................................................................................................................16
ÍNDICE
ESPECIFICACIONES DEL PRODUCTO
ESPECIFICACIONES
Rango de voltaje
Frecuencia nominal
Potencia nominal
Garantía 1 año
1500 W
60 Hz
120 V
10
