UTStarcom Gz One Type S Bedienungsanleitung

User Guide

Guíadel Usuario

OMC211VW VER 1.1

Manual_Cover_15mm 2007.2.13 6:45 PM 페이지1

Contents

G’zOne TYPE-S

Phone Overview ............5

Menus Overview..........12

Getting Started with Your

Phone...........................15

The Battery.....................15

Charging the Battery ......17

Battery Charge Level ......19

Turning the Phone On

and Off ...........................19

Making Calls...................20

Redialing Calls................20

Receiving Calls ...............20

Screen Icons ..................21

Quick Access to

Convenient Features...23

Vibrate Mode ..................23

Lock Mode......................23

Mute Function ................23

Volume Quick Adjustment

........................................24

Call Waiting ....................24

Caller ID ..........................25

Voice Command.............25

Speed Dialing .................25

Entering and Editing

Information ..................27

Text Input .......................27

Text Input Modes ...........27

Contacts in Your Phone’s

Memory........................31

The Basics of Storing

Contacts Entries .............31

Options to Customize Your

Contacts .........................32

Editing Contacts Entries.36

Deleting ..........................39

Phone Numbers With

Pauses............................41

Searching Your Phone’s

Memory ..........................43

Making a Call From Your

Phone’s Memory ............44

Menu Access..................48

GET IT NOW ................49

1. Tunes & Tones............50

2.4 Alarm Clock..............99

2.5 World Clock ...........100

2.6 Notepad.................100

2.7 Countdown Timer...100

2.8 Stop Watch ............101

3. Bluetooth Menu ........102

3.1 Add New Device.....103

4. Sounds Settings .......108

4.1 Master Volume .......109

4.2 Call Sounds............109

4.3 Alert Sounds...........110

4.4 Keypad Volume......111

4.5 Earpiece Volume ....111

4.6 Service Alerts .........112

4.7 Power On/Off .........113

4.8 Alarm Sounds.........113

4.9 Folder On / Off .......114

5. Display Settings........114

5.1 Banner ...................115

5.2 Backlight ................116

5.3 Contrast .................117

5.4 Wallpaper...............117

5.5 Display Themes......118

5.6 Dial Fonts ...............118

5.7 Clock Format..........118

5.8 Power Saver...........119

6. Phone Settings .........120

6.1 Standalone Mode...121

6.2 Set Shortcut Keys ..122

6.3 Language ...............122

6.4 Security..................123

6.5 System Select ........128

6.6 NAM Selection .......129

7. Call Settings .............130

7.1 Answer Options......130

7.2 Auto Retry ..............131

7.3 TTY Mode ..............132

7.4 One Touch Dial.......132

7.5 Voice Privacy..........133

7.6 Call Restrictions......133

7.7 Data Settings..........134

7.8 DTMF Tones...........134

7.9 Ringer ID ................135

7.0 Picture ID ...............135

Contents

G’zOne TYPE-S

1.1 Get New Ringtones ..51

1.2 My Ringtones ...........51

1.3 My Sounds...............52

2. Picture & Video ...........53

2.1 Get New Pictures .....54

2.2 My Pictures ..............54

2.3 My Videos ................55

2.4 Take Picture .............57

2.5 Record Video ...........58

2.6 PIX Place..................59

3. Games ........................59

4. News & Info ................59

5. Tools on the Go..........63

6. Extras..........................63

MESSAGING................64

1. New Message.............65

2. Inbox...........................71

3. Sent ............................74

4. Drafts ..........................76

5. Voicemail ....................77

6. Mobile IM....................78

7. E-mail .........................78

8. Chat ............................78

Message Settings...........79

Message Settings Sub-

Menu Descriptions..........80

Message Erase ...............82

CONTACTS..................83

1. New Contact...............83

2. Contact List ................84

3. Groups........................85

4. Speed Dials ................86

RECENT CALLS...........87

1. Missed ........................88

2. Received.....................88

3. Dialed..........................89

4. All................................90

5. View Timers ................91

SETTINGS & TOOLS....92

1. My Account ................92

2. Tools...........................93

2.1 Voice Commands.....94

2.2 Calculator.................97

2.3 Calendar...................97

G’zOne TYPE-S

Phone Overview

G’zOne TYPE-S

8. Memory ....................136

8.1 Memory Usage.......136

8.2 My Pictures ............136

8.3 My Videos ..............137

8.4 My Sounds.............137

9. Phone Info ................138

9.1 My Number ............138

9.2 SW Version ............138

9.3 Icon Glossary .........139

Inbox Items................140

Safety.........................141

TIA Safety Information..141

Tips on Efficient Operation

....................................141

Driving..........................141

Electronic Devices ........142

Pacemakers .................142

Hearing Aids.................143

Other Medical Devices..143

Hospitals and Health Care

Facilities .......................144

Vehicles........................144

Posted Facilities ...........144

Aircraft..........................144

Blasting Areas ..............145

Potentially Explosive

Atmospheres................145

Safety Information for FCC

RF Exposure.................146

Body-Worn Operation ..146

SAR information ...........147

FDA information............149

Accessibility..................174

12 MONTH LIMITED

WARRANTY ...............179

G’zOne TYPE-S

2. Flip

3. LCD Screen

4. Left Soft Key

5. Headset Port

6. Camera /

Video Key

7. SEND Key

9. Vibrate

Mode Key

8. Clear Key

1. Earpiece

11. Center Select Key

10. Navigation Key

12. Right Soft Key

13. Speaker / FLASH Key

14. Speaker Key

16. END / PWR Key

17. Alphanumeric Keypad

15. Volume Keys

19. Lock Mode Key

20. Microphone

28. Charging Port

18. Voice Command Key

(when flip is open)

5. Headset Port

15. Volume Keys

14. Speaker Key

18. Countdown Timer,

Stop Watch

(when flip is closed)

1. Earpiece

2. Flip Open the case to answer an incoming call and

close to end the call.

3. LCD Screen Displays messages and indicator icons.

4. Left Soft Key Use to display the Message menu

or access the function listed above the key.

5. Headset Port

6. Camera / Video Key Use for quick access to

Camera / Video function.

7. SEND Key Use to place or answer calls. In

standby mode, press to access your call history list.

8. Clear Key Press to delete a single space or

character. Press and hold to delete entire words.

Press this key once in a menu to go back one level.

9. Vibrate Mode Key Press and hold to turn

Vibrate mode on/off.

10. Navigation Key Press Navigation Key left

for Picture & Video, Navigation Key down for

Calender, Navigation Key up for Mobile Web,

and Navigation Key right for GET IT NOW.

11. Press Center Select Key to select a function.

Phone Overview

G’zOne TYPE-S

23. Outside Display

22. Flash 21. Camera Lens

25. Speaker

24. Charging

terminals

26. Screw type

battery lock

27. Battery

28. Charging Port

19. Lock Mode Key Use to set the lock function

(from standby mode press and hold for about 2

seconds).

20. Microphone 21. Camera Lens

22. Flash 23. Outside Display

24. Charging terminals 25. Speaker

26. Screw type battery lock 27. Battery

28. Charging Port

Phone Overview

G’zOne TYPE-S

12. Right Soft Key Use to display Contact List or to

access the function listed above the key.

13. Speaker / FLASH Key Press to turn

Speakerphone on/off. Press and hold to turn the

flash on/off when the phone is in idle mode.

14. Speaker Key Press to turn Speakerphone on/off.

15. Volume Keys You can set or reset Volume Up /

Down / Stopwatch / Countdown Timer functions. You

can set to Sound Off while incoming alert if Folder is

set to Close

16. END / PWR Key Use to turn the power on/off

and to end a call. Also use to return to the main

menu display screen.

17. Alphanumeric Keypad Use to enter numbers and

characters and select menu items.

18. Voice Command Key Use this key as Voice

Command/Voice Recorder function if Folder is set as

open. In case the flip is closed, press and hold this

key to change its mode in the loop of the normal

watch, the countdown timer, and the stop watch.

G’zOne TYPE-S

NOTE

In order to maintain your phone's resistance it is

recommended that you rinse any parts which may appear

blocked with pure water.

NOTE

Clean Charging Terminals with dry cloths or cotton buds

occasionally. Dust may cause some electrical connection

problems. Do not change the shapes of ports by rubbing,

wiping or poking too much.

Phone Overview

G’zOne TYPE-S

Water Resistant

The G'zOne TYPE-S is water resistant. The device provides the

most reliable performance for your outdoor life, in such

conditions as driving rain or high humidity.

For additional information, see 12 MONTH LIMITED

WARRANTY section (from page 179).

NOTE

To keep water resistant;

• Fasten down the headset and charging port cover.

• Install the battery and screw the battery lock on tightly.

Shock Resistant

The rugged construction of the G'zOne TYPE-S allows for

shock and vibration resistance. The G'zOne TYPE-S can

perform in those environments where a phone needs to sustain

these conditions.

Dust Resistance

To give you additional peace of mind the G'zOne TYPE-S is

also dust resistant. The device was tested using silica flour at a

temperature of 95F and bears up to the MIL-STD-810F (Dust)

standard.

G’zOne TYPE-S

Charging Terminals (internal) Charging Terminals (external)

SETTINGS &

TOOLS

1. My Account

2. Tools

1. Voice Commands

2. Calculator

3. Calendar

4. Alarm Clock

5. World Clock

6. Notepad

7. Countdown Timer

8. Stop Watch

3. Bluetooth Menu

1. Add New Device

4. Sounds Settings

1. Master Volume

2. Call Sounds

2.1. Call Ringtone

2.2. Call Vibrate

3. Alert Sounds

3.1. Text Message

3.2. Picture-Video

Message

3.3. Voicemail

Message

4. Keypad Volume

5. Earpiece Volume

6. Service Alerts

6.1. ERI

6.2. Minute Beep

6.3. Call Connect

7. Power On/Off

7.1. Power On

7.2. Power Off

8. Alarm Sounds

8.1. Tone

8.2. Vibrate

9. Folder On/Off

5. Display Settings

1. Banner

1.1. Personal Banner

1.2. ERI Banner

2. Backlight

2.1. Display

2.2. Keypad

3. Contrast

4. Wallpaper

4.1. My Pictures

4.2. My Videos

Menus Overview

G’zOne TYPE-S

GET IT NOW

1. Tunes & Tones

1. Get New Ringtones

2. My Ringtones

3. My Sounds

2. Picture & Video

1. Get New Pictures

2. My Pictures

3. My Videos

4. Take Picture

5. Record Video

6. PIX Place

3. Games

4. News & Info

5. Tools on the Go

6. Extras

MESSAGING

1. New Message

2. Inbox

3. Sent

4. Drafts

5. Voicemail

6. Mobile IM

7. E-mail

8. Chat

CONTACTS

1. New Contact

2. Contact List

3. Groups

4. Speed Dials

RECENT CALLS

1. Missed

2. Received

3. Dialed

4. All

5. View Timers

G’zOne TYPE-S

The Battery

Warning!

Use only approved batteries for your phone.

NOTE

It is important to fully charge the battery before initial use of

the phone.

The phone comes with a rechargeable battery. Keep the

battery charged while not in use in order to maximize talk

and standby time. The battery charge level appears at

the top of the LCD screen.

Warning!

Failure to follow the below directions for installing/removing

the battery could result in product failure.

Installing the Battery

1. Insert the battery into the opening on the back of the

handset using the guide.

Getting Started with Your Phone

G’zOne TYPE-S

5. Display Themes

6. Dial Fonts

7. Clock Format

7.1. Main Clock

7.2. Front Clock

8. Power Saver

6. Phone Settings

1. Standalone Mode

2. Set Shortcut Keys

2.1. Left Key

2.2. Up Key

2.3. Right Key

2.4. Down Key

2.5. Reset All

3. Language

4. Security

4.1. Common Code

4.2. Lock Mode

4.3. Restrict Calls

4.4. Edit Code

4.5. Emergency #s

4.6. Erase Contacts

4.7. Reset Default

5. System Select

6. NAM Selection

7. Call Settings

1. Answer Options

2. Auto Retry

3. TTY Mode

4. One Touch Dial

5. Voice Privacy

6. Call Restrictions

7. Data Settings

8. DTMF Tones

9. Ringer ID

0 . Picture ID

8. Memory

1.Memory Usage

2. My Pictures

3. My Videos

4. My Sounds

9. Phone Info

1. My Number

2. SW Version

3. Icon Glossary

G’zOne TYPE-S

Guide

Charging the Battery

To use the charger provided with your phone:

Warning!

Use only the charger provided with the phone. Using any

charger other than the one included with the Verizon Wireless

G’zOne TYPE-S may damage your phone or battery.

1. Connect the AC Charger to the Handset Charging

Cradle.

2. Plug the AC Charger power plug into an electrical

outlet.

3. Insert the handset into the Handset Charging Cradle.

Getting Started with Your Phone

G’zOne TYPE-S

2. Insert the Device Lock Tool into the slot of the battery

lock and turn in the direction of the arrow shown

below.

Removing the Battery

1. Insert the Device Lock Tool into the slot of the battery

lock and turn in the direction of the arrow shown

below.

2. Remove the battery by pulling up on the tab.

G’zOne TYPE-S

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere UTStarcom Handy Handbücher

UTStarcom

UTStarcom Shuttle CDM8964VM Bedienungsanleitung

UTStarcom

UTStarcom cdm7025US Bedienungsanleitung

UTStarcom

UTStarcom PLS-7075 Bedienungsanleitung

UTStarcom

UTStarcom Verizon CDM9200VW Bedienungsanleitung

UTStarcom

UTStarcom CDM-8625 Bedienungsanleitung

UTStarcom

UTStarcom CDM7176M Bedienungsanleitung

UTStarcom

UTStarcom PLS6800 Bedienungsanleitung

UTStarcom

UTStarcom F1000 Series Bedienungsanleitung

UTStarcom

UTStarcom UTS700X Bedienungsanleitung

UTStarcom

UTStarcom UT611 Bedienungsanleitung

UTStarcom

UTStarcom CDM-8625 Bedienungsanleitung

UTStarcom

UTStarcom GSM738 Bedienungsanleitung

UTStarcom

UTStarcom 860 Konfigurationshandbuch

UTStarcom

UTStarcom 860 Bedienungsanleitung

UTStarcom

UTStarcom GPRS1229 Bedienungsanleitung

UTStarcom

UTStarcom GPRS758 Bedienungsanleitung

UTStarcom

UTStarcom CDM-8935 Bedienungsanleitung

UTStarcom

UTStarcom UTS-C3000 Bedienungsanleitung

UTStarcom

UTStarcom Handset Bedienungsanleitung

UTStarcom

UTStarcom F1000 Series Bedienungsanleitung

UTStarcom

UTStarcom PPC-6700 Bedienungsanleitung

UTStarcom

UTStarcom UT GF251 Bedienungsanleitung

UTStarcom

UTStarcom CDM-4500 Bedienungsanleitung

UTStarcom

UTStarcom CDM-7000 Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
