How do I...

Page III. Page IV.

Turn phone on/off

These operations need to be performed in standby mode. When

the left soft key function is Menu, the phone is in standby mode.

To return to standby mode, press .

Make a call

Answer a call

Press and hold .

Key in the phone number and press .

Press (Answer) or .

Turn Vibration

on/off

Press and hold until the (green)

indicator appears/disappears.

WARNING: Prior to placing or receiving calls, the WiFi phone must be

connected to a Wireless Access Point and registered with the service

network. See Section 3, "Connecting to a Wireless Network" for detailed

instructions.

How do I...

Phonebook

options:

Add a contact

Delete a contact

Under the Phonebook menu:

Select Add Entry; follow screen prompts.

Select Delete; follow screen prompts.

Edit a contact

phonebook

Assign a speed

dial key

Select Search; scroll to name; press

(Detail); press to reach the intended

item; press (Option); select Edit;

follow screen prompts.

Contact name must already be in the

phonebook. Select Speed Dial; select the

desired key (2-9); scroll to the desired

name and press (Ok); scroll to the

desired number and press (Ok).

Select Search; key in the first letter(s) of

the name; press to scroll.

End or reject

a call

Clear a keypad

entry

Use speed dial

Adjust listening

volume

Access menu

options

Press (Clear) .

While on a call, press .

Press (Menu) to access the main

menu. Press to reach the desired

submenu/option, and then press (Ok).

If there is a number in front of the

intended option, you can access the

option by directly pressing the

corresponding number key.

Press (Hangup) or , or close the

flip cover.

Press and hold the speed dial key to

display the phone number, and then

press .

1. Overview

Page 1 Page 2

The UTStarcom F3000 Handheld is a wireless Voice over IP

(VoIP) telephone that, when coupled with VoIP phone service,

combines the benefits of Internet telephone service, with

mobility. This guide covers how to configure and use your F3000

to make VoIP phone calls via the service network. You can make

and receive calls as long as you are within range of a wireless

access point. See the F3000 User Manual for more information

on all features.

Note: Before using your F3000 handheld, you should have high-speed

Internet access, a wireless router, and a voice account set up.

When the battery power is low and needs recharging, the battery

indicator will flash continuously, and the phone will sound a

low battery alarm, reminding you that the battery is running low

and the phone will be switched off automatically. To charge the

battery, follow the steps below:

1. Connect the charger to an AC wall outlet (100 - 240V).

2. Connect the lead from the charger to the charging socket of

the phone. The battery indicator bar starts to scroll ( a

a a ). If the phone is off, the text "Charging..."

is also displayed on the LCD screen.

3. When the battery indicator bar stops scrolling, charging is

complete. The text "Fully Charged!" is also displayed on the

LCD screen, if the phone is off.

Note: The phone takes about 3-4 hours to charge and the exact time may

vary depending on the circumstances.

2. Charge the Battery

DigitalInnovation

Internet

3. Connecting to a Wireless Network

Page 3 Page 4

Your F3000 WiFi phone has been preconfigured to provide VoIP

phone service via any available open wireless Access Point (AP)

connected to the Internet. If you want to use a specific AP or

your AP is protected by encrypted access, refer to Section 3.2.

When you turn on the F3000, it searches for available APs,

selects the AP with the best signal and attempts to connect

to it. You will see the message "Connecting to APname"

while the phone is attempting to connect.

Note: If there are new configuration and software updates available,

when the F3000 has successfully connected to an AP, it will need to

be provisioned. Please refer to Section 4.

Note: If the WiFi phone cannot connect to an AP, it will keep

searching and wear down your battery. Verify open AP availability. If

not found, turn off the phone until you are within range of an Access

Point.

Once connected (and provisioned

when necessary), you will see the

message "Registering via APname".

When the right soft key function

displaying Names in standby mode,

you are ready to make and receive

calls.

Before connecting to a protected or specific AP, you must

define it to the F3000. You can define a maximum of four

APs. Typically you would define frequently used APs such

as that of your home router. Defined APs can be open

(available for use by anyone) or protected (available for use

by authorized users only).

Protected APs require use of an encryption code for

access. The F3000 supports WEP and WPA-PSK

encryption codes. If your home wireless router was installed

with a WEP or WPA-PSK (Pre-Shared Key), use it when

defining the SSID to your F3000. If you are defining a

corporate AP, obtain the WEP or WPA-PSK from the AP

administrator.

Once APs are saved, the F3000 first tries to connect to one

of the defined APs and if none are available, it looks for an

open AP to use for your call.

You will see the message "Connecting to APname" while

the phone is attempting to connect.

Note: If there are new configuration and software updates available,

when the F3000 has successfully connected to an AP, it will need to

be provisioned. Please refer to Section 4.

3.1 Connecting to Open Access Points

3.2 Connecting to Protected or Specific Access

Points

3. Connecting to a Wireless Network

Page 5 Page 6

3. Connecting to a Wireless Network

Note: You must be within range of the AP when using Net Search to

define it to the F3000.

The Net Search feature locates APs and allows you to save

the SSIDs. Follow these Net Search steps:

3.3.1 Using Net Search

1. There are two ways to initiate Net Search:

- Press (Search) while the F3000 is automatically

scanning for an AP (when the phone is first turned on).

- Use the menus to initiate Net Search: Press

(Menu); press to scroll to WiFi and press

(Ok); press to select Net Search.

2. Available SSIDs are displayed. Press to highlight

the desired SSID and press (Save). Press to

reach the desired AP profile and press (Save) to

save the SSID.

3. Press to select the Security Mode option. select

from Open AP, WEP KEY and WPA-PSK according to

the AP's authentication mode.

4. If WEP KEY or WPA-PSK is selected, the phone will

dierectly access the WEP Key Info or WPA-PSK Info

option.

Follow the prompts to set the option:

- WEP Key Info: Select 64bit or 128bit to specify the

encryption method that was used to create the WEP;

enter the WEP key and press (Ok). To set the

WEP key authentication method and index, select

Auth. Method and WEP Key Index.

- WPA-PSK Info: Enter the WPA-PSK key and press

(Ok).

Once connected (and provisioned when necessary), you

will see the message "Registering via APname". When the

right soft key function displaying Names in standby mode,

you are ready to make and receive calls.

Note: If the WiFi phone cannot connect to

an AP, it will keep searching and wear

down your battery. Verify open AP

availability. If not found, turn off the phone

until you are within range of an Access

Point.

APs can be defined and saved automatically using the Net

Search feature if APs have broadcast turned on. If the

desired AP has broadcast turned off. The AP can be

entered directly through a series of keystrokes on your

handset.

3.3 Finding and Saving the Access Point

3. Connecting to a Wireless Network

Page 7 Page 8

For alpha entry, rapidly press a key to toggle through the

letters assigned to that key. For example, enters a, b,

c, A, B, and C. Rapidly press to toggle through the

entries. Therefore, to enter B, rapidly press five times.

Pause between key presses to enter the next character in

the string. For example, to enter the string "ab", press

once, pause then rapidly press twice.

If you want to change something previously entered, press

(Clear) to delete the character to the left of the cursor;

press and hold (Clear) to delete all characters. Press

to move the cursor.

An indicator ( or ) appears at

the upper right corner of the screen.

indicates Alpha entry;

indicates numeric entry.

Press to switch between

and .

For numeric entry, press the desired

key once.

3. Connecting to a Wireless Network

Page 8

You can enter alpha and numeric values, such as a WEP

Key, using the F3000 phone keys.

If the desired AP has broadcast turned off, you can save the

AP by entering SSID information directly.

1. Press (Menu); press to scroll to WiFi and

press (Ok); press to select WiFi Config; press

to select AP Profile.

2. Press to reach the desired AP profile and press

(Ok). Press to select the SSID option.

3. Enter the desired AP's SSID and press (Ok).

4. Follow steps 3-4 specified in Section 3.3.1.

3.4 Tips for Alphanumeric Entry

3.3.2 Entering SSIDs Directly

4. Auto-Provisioning of F3000 WiFi

Phone

If there are new configuration and software updates available,

once the phone has connected to the Internet successfully via

the Access Point, the F3000 will need to be provisioned with the

latest configuration and software. This process is automatic and

will take several minutes to complete. During this time, several

status messages such as downloading, decompressing will be

displayed on the phone's display. Once complete, the phone will

reboot.

After auto-provisioning, the phone will use the same process as

previously described for connecting to Access Points.

Page 9 Page 10

5. Troubleshooting5. Troubleshooting

These are the most common problems and solutions that come

up when starting to use the F3000 WiFi phone. If you are having

trouble placing a phone call, go through this checklist until your

problem is solved:

I cannot make a phone call:

- Is the phone connected to an AP and registered with the

service network?

If so, you will see the right soft key function displaying

Names in standby mode. Key in the phone number to call

and press .

If the phone hasn't connected to an AP, refer to Section 3.1

("Connecting to Open Access Points") and Section 3.2

("Connecting to Protected or Specific Access Points") for

advice.

If the phone has connected to an AP, but hasn't registered

with the service Network, the following message will appear

"No Service Try Another AP". This may indicate connection

to an AP for which there is no Internet, or possibly an AP that

has filtering. Try connecting to another AP.

- Is there sufficient signal strength? Check the Signal Bars in

the top left corner of the display. Move closer to AP for better

signal strength.

The phone cannot be switched on:

- Press and make sure you hold it down for more than 2

seconds.

- If it still doesn't switch on, check your battery. If necessary,

charge the battery.

How do I know what my IP address and Mac Address is?

Access the Network Information option: Press (Menu);

press to scroll to WiFi and press (Ok); press to

select Network Parameter. Press to select Network

Information.

Net Search didn't find my AP:

Make sure SSID broadcasting is enabled on your AP.

HELPFUL HINT: Your WiFi phone's Local Log function provides the

phone's status information, which may help analyze the problem.

Press (Menu); press to scroll to Misc and press (Ok).

Press to select Local Log. The phone's status information will be

displayed.

Strong Weak

Doc. Code: 8810026900.0512

Andere Handbücher für F3000

Inhaltsverzeichnis

Andere UTStarcom Schnurloses Telefon Handbücher

UTStarcom

UTStarcom F3000 Bedienungsanleitung

Beliebte Schnurloses Telefon Handbücher anderer Marken

3Com

3Com NBX Bedienungsanleitung

Panasonic

Panasonic KX-TGK210HK Bedienungsanleitung

Panasonic

Panasonic KX-TCA181EX Bedienungsanleitung

BT FREESTYLE 3200 Bedienungsanleitung

AT&T

AT&T CL84102 Bedienungsanleitung

BREZZICNI

BREZZICNI CL-3622 Bedienungsanleitung

Panasonic

Panasonic KX-TG1831NZ Bedienungsanleitung

Panasonic

Panasonic KX-TG7301E Bedienungsanleitung

Furuno

Furuno FM-4721 Bedienungsanleitung

Sanyo

Sanyo CLT-J70 Bedienungsanleitung

Amplicomms

Amplicomms BigTel 201 Bedienungsanleitung

GE 26992 Bedienungsanleitung

AT&T

AT&T E1812B Bedienungsanleitung

Sanyo

Sanyo CLT-670 Bedienungsanleitung

GE 15432970 Bedienungsanleitung

Curtis

Curtis TC595 Bedienungsanleitung

Gigaset

Gigaset Gigaset 3000 Micro Bedienungsanleitung

Poly

Poly VVX D230 Einrichtungshandbuch
