V-ZUG Combair SG Series Montageanleitung

V-ZUG Ltd

Oven • Hob

Combair SG

Tips on settings

Symbols used

Operating mode

Cooking space temperature

˚C

Preheating until the cooking space temperature is reached

mins. Duration in minutes

hrs. Duration in hours

Level

Accessories

Operating modes

Press the

button Operating mode

Press the

button Operating mode

1× Top/bottom heat 5× Hot air humid

2× Top/Bottom heat humid 6× PizzaPlus

3× Bottom heat 7× Grill

4× Hot air 8× Grill-forced convection

Optimal use

The cooking space temperatures and levels given in recipe books are in part unlikely to be optimal for this appliance. The

following tables show how to get the best use out of the appliance.

Ensure that the «sloped» side 1of the original baking tray is to the back of the cooking space.

Bread and plaited bread

˚C

mins.

Bread 210-220 5 mins. 35-45 2

190-200 5 mins. 35-45 1+3

Bread roll 210-230 5 mins. 25-35 2

200-220 5 mins. 25-30 1+3

Plaited bread 180-190 5 mins. 35-45 2

180-200 5 mins. 30-45 1+3

Cakes, torte

˚C

mins.

Ring cake (chocolate, carrot, nut, etc.) 160-170 yes 50-70 2

Torte (chocolate, carrot, nut, etc.) 170-180 yes 40-50 2

Linzertorte 170-180 yes 35-45 2

Whisked sponge cake 160-170 yes 30-40 2

Roulade/Swiss roll 180-200 yes 7-10 2

180-190 yes 8-12 1+3

Short crust pastry case, baked blind 190-200 yes 20-25 2

Fruit tart with short crust pastry 170-180 yes 40-50 2

170-180 yes 45-55 2

Raisin bread, yeast ring, hazelnut plait 170-190 yes 30-40 2

Luzerner Lebkuchen (gingerbread) 170-180 yes 45-55 2

Tray-baked cake 180-190 yes 20-30 2

Apple strudel 180-200 yes 30-40 2

Cake topped with meringue 130-150 yes 25-35 3

Japonaise base (thin nut meringue base) 150-170 yes 15-20 2

130-150 yes 15-20 1+3

Savouries and biscuits

˚C

mins.

Aperitif nibbles 180-200 yes 15-30 2

180-190 yes 15-25 1+3

Puff pastries with a filling (ham or nut croissant, etc.) 180-200 yes 20-30 2

170-190 yes 20-30 1+3

Small yeast pastries 170-190 yes 15-25 2

Eclairs, profiteroles 160-180 yes 20-30 2

Macaroons 180-200 yes 8-12 2

Brunsli (chocolate almond spice cookies), Zimtsterne

(cinnamon star cookies)

170-190 yes 8-12 2

170-190 yes 5-10 1+3

Mailänderli (butter biscuits), Spitzbuben (jam biscuits) 170-180 yes 10-15 2

160-180 yes 10-15 1+3

Basler Leckerli (honey almond spice cookies) 190-210 yes 15-20 2

Chräbeli (aniseed biscuits) 130-140 yes 20-30 2

130-140 yes 25-35 1+3

Meringues (allow to dry overnight after baking) 80-90 no 80-100 2

Bruschetta, garlic bread 210-230 yes 5-10 3

Ham and pineapple toastie 200-220 yes 15-20 2

250 5 mins. 5-7 3

Flans and pizzas

˚C

mins.

Fruit flan 200-210 yes 40-45 2

170-190 yes 45-50 2

180-190 yes 45-50 1+3

Savoury flan (cheese, vegetable, onion) 180-190 yes 35-45 2

200-210 yes 35-45 2

180-190 yes 35-45 1+3

Fresh pizza

(for frozen pizza, follow the manufacturer's instructions)

210-220 yes 15-20 2

210-220 yes 20-25 2

200-220 yes 20-25 1+3

With frozen or fresh fruit that is very juicy add the glaze after the first 15-20 minutes.

Baked dishes and gratins

˚C

mins.

Baked dish (sweet) 190-200 yes 30-45 2

Gratin (vegetable, fish, potato) 190-200 yes 30-50 2

Lasagne, moussaka 200-210 yes 30-45 2

Gratinated vegetables 230-250 yes 5-10 2

230 5 mins. 5-10 3

Meat

˚C

mins.

Shoulder of veal, roasted 200-220 yes 70-90 2

Roast beef 200-220 yes 25-35 2

1and

Shoulder of beef, braised 170-190 yes 70-100 2

Shoulder of pork, braised 180-190 yes 80-110 2

Shoulder of pork, roasted 210-230 yes 100-120 2

1and

Leg of lamb 200-210 yes 90-110

Meat loaf 200-220 yes 50-70 2

Fleischkäse (specialty meat loaf) 170-190 yes 45-65 2

Fillet in pastry 180-190 yes 30-40 2

Chops * 250 5 mins. 15-20 4

3and

Sausages * 250 5 mins. 10-15

* Turn halfway through the cooking time.

Poultry

˚C

mins.

Whole chicken * 210-230 yes 70-80 2

1and

180-190 no 60-80

Chicken, 4 halves * 220-230 5 mins. 50-60

Chicken leg * 250 5 mins. 20-30 3

* Turn halfway through the cooking time.

Low temperature cooking

˚C

hrs.

Fillet of beef 80-90 no 2½-3½ 2

Roast beef 80-90 no 2½-3½ 2

Middle loin of pork 90-100 no 3-4 2

Cooking using a Römertopf (clay cooking pot)

˚C

mins.

Chicken 200-220 no 60-70 2

Roasting 200-220 no 80-90 2

Braising steak 200-220 no 50-70 2

Desiccating and drying

˚C

hrs.

Apple slices or rings 70 no 7-8 2

1+3

1+2+3

Sliced mushrooms 50-60 no 5-8

Herbs 40-50 no 3-5

Apricots 60-70 no 14-16

Overdrying poses a fire hazard! Monitor the desiccating and drying process.

Only use undamaged, ripe fruit, fresh mushrooms and herbs.

Clean and chop the fruit, mushrooms or herbs into small pieces.

Line the original baking tray or wire shelf with baking paper, spread the food on it and then put in the cooking space at

the appropriate level.

Wedge a wooden spoon between the operating panel and the appliance door, leaving an approximately 2 cm gap

open.

Turn the food at regular intervals

– to ensure even drying.

A maximum of 3 levels in the cooking space can be used at any one time.

Preserving food

Bottling in the home involves preserving food in bottling jars. Only use undamaged jars with glass lids, suitable rubber

seals and correctly functioning sealing clips. Do not use jars with screw or bayonet tops as the pressure that builds up

during preserving cannot be reduced.

Put a maximum of 5 jars that hold no more than 1 litre each in the cooking space at any one time.

Always use same-size jars.

Original baking tray Put the wire shelf at level 1.

Fill the jars evenly with the food to be preserved, which is at the ambient temperature,

and add liquid (and any sugar, salt or vinegar) as required.

Close the jars according to the manufacturer's instructions.

Place the jars on the Original baking tray as shown in the illustration. The jars should not

touch one another.

Select the 150 °C operating mode and start.

Heat until bubbles start to rise quickly to the surface of the liquid in the jars.

–Preserving food that is at the ambient temperature takes about 60 to 90 minutes.

Keep the appliance door closed during the preserving process.

Set the cooking space temperature and operating mode to «0» and leave the jars standing in the cooking space for

40 minutes.

Leave the appliance door open in the at-rest position.

Leave the jars in the cooking space to cool down completely.

Remove the jars. Check that the jars are sealed tight.
