USER MANUAL
L238IPS
23.8” FHD 1920x1080 IPS LED Monitor
PACKAGE INCLUDES
HDMI
2pcs M4x30 AC/DC POWER ADAPTER
12V/2.5A 30W
2pcs M4x12
POWER CORD
OPTIONAL MOUNTING PLATE & SCREWS
US
EU
-OR-
Im Lieferumfang Enthalten
Le paquet contient
El paquete incluye
La confezione contiene
A csomag tartalma
MOUNT OPTION (Wall Mount Sold Separately)
+
x2
x2
GETTING STARTED
DC DP HDMI VGA AUDIO IN
PORTS
CONTROL PANEL
DP
Power HDMI VGA
Audio
Out
Audio
In
E : Return
M: Enter the main menu ; Enter
: Up / Down, Right / Left
: Turn on or o the machine
MAIN MENU
Color
Audio
OSD
System
Information
Brightness: To adjust the luminance of the video
Contrast: To adjust the foreground white level of screen image
Black Boost: To adjust black levels to display darker areas such as shadows to be more visible
Blue Light: To adjust Blue Light levels OFF/25%/50%/75%/100%. Blue Light Disabled if DCR is ON
DCR: Dynamic Contrast Ratio
Note: Adjusting H. Position, V. Position, Focus, & Clock is grayed out if connected via HDMI or DisplayPort.
Auto Cong: Automatic conguration of the below parameters ONLY if connected via VGA Analog signal
H. Position: To move image Horizontally
V. Position: To move image Vertically
Focus: To adjust the phase position of the analog signal
Clock: To adjust the clock of analog signal
COLOR
Gamma: To adjust Gamma 1.8/2.2/2.4
Color: To adjust color temperature: Warm/Normal/Cool/Blue Light/User
RGB Values can be individually adjusted
AUDIO
Volume: To adjust internal speakers
OSD
Language: To select desired language
OSD Time Out: To adjust time limit of OSD
Transparency: To adjust OSD visibility in foreground
