Vantron UCTB-27 Bedienungsanleitung

UCTB-27

Rockchip ARM Cortex™-A17 RK3288 with Quad ARM Cortex A17

(64bit @ 1.6GHz high performance processor;

Hardware Manual

Rev 2.1

2021/12/27

Chengdu Vantron Technology, Ltd.

User

’

s Manual

UCTB-27 User’s Manual

-2- www.vantrontech.com.cn

Revision record

Rev. Date Change Description Editor

1.0 2019-12-12 Initial Version

2.0 2020-03-11 Update structural drawings

2.1 2021-12-27 Update detail description

UCTB-27 User’s Manual

-3- www.vantrontech.com.cn

Table of Contents

FOREWORD ........................................................................................................................................ 4

1.1

OPYRIGHT

OTICE

................................................................................................................................ 4

1.2

OTES

..................................................................................................................................................... 4

1.3

TATEMENT

............................................................................................................................................. 4

1.4

ISCLAIMER

............................................................................................................................................ 5

1.5

IMITATION OF

IABILITY

WARRANTY

........................................................................................... 5

1.6

AFETY

NSTRUCTIONS

............................................................................................................................ 5

1.7

RECAUTIONS

.......................................................................................................................................... 5

1.8

AFETY

NSTRUCTIONS FOR

OWER

ABLES AND

CCESSORIES

............................................................. 5

O ER IEW ......................................................................................................................................... 7

2.1

NTRODUCTION

........................................................................................................................................ 7

2.2

EATURES

................................................................................................................................................ 8

2.3

RDER INFORMATION

.............................................................................................................................. 8

HARDWARE INSTRUCTIONS ....................................................................................................... 10

3.1

PPEARANCE

......................................................................................................................................... 10

3.1.1

Appearance ................................................................................................................................... 10

3.2

NTERFACE

ESCRIPTION

...................................................................................................................... 10

3.3

TRUCTURE

........................................................................................................................................... 11

HARDWARE DESCRIPTION.......................................................................................................... 12

4.1

ONNECTORS

ESCRIPTION

.................................................................................................................. 12

4.1.1

Power button ................................................................................................................................. 12

4.1.2

AC Jack ......................................................................................................................................... 13

4.1.3

Recovery button ............................................................................................................................ 13

4.1.4

Debug interface ............................................................................................................................. 13

4.1.5

Micro USB .................................................................................................................................... 13

4.1.6

Ethernet ......................................................................................................................................... 13

4.1.7

USB 2.0 ........................................................................................................................................ 13

4.1.8

Video ............................................................................................................................................ 14

TIPS ..................................................................................................................................................... 15

UCTB-27 User’s Manual

-4- www.vantrontech.com.cn

1 Foreword

1.1 Copyright Notice

While all information contained herein have been carefully checked to assure its accuracy

in technical details and printing, Vantron assumes no responsibility resulting from any error

or features of this manual, or from improper uses of this manual or the software. Please

contact our technical department for relevant operation solutions if there is any problem that

cannot be solved according to this manual.

Vantron reserves all rights of this manual, including the right to change the content, form,

product features, and specifications contained herein at any time without prior notice. The

latest version of this manual is at www.vantrontech.com.cn. Please contact Vantron for

further information:

Vantron Technology（Vantron）

E-mail:

sales@vantrontech.com

The trademarks and registered trademarks in this manual are properties of their respective

owners. No part of this manual may be copied, reproduced, translated or sold. No changes or

other purposes are permitted without the prior written consent of Vantron.

Vantron reserves the right of all publicly-released copies of this manual.

1.2 Notes

Applicable notes are listed in the following table:

Sign Notice

Type Description

Notice Important information and regulations

Caution Caution for latent damage to system or

harm to personnel

1.3 Statement

It is recommended to read and comply with this manual before operating board, which

provides important guidance and helps decreasing the danger of injury, electric shock, fire,

or any damage to the device.

UCTB-27 User’s Manual

-5- www.vantrontech.com.cn

1.4 Disclaimer

Vantron assumes no legal liability of accidents resulting from failure of conforming to the

safety instructions.

1.5 Limitation of Liability/Non-warranty

For direct or indirect damage to this device or other devices of Vantron caused by failure

of conforming to this manual or the safety instructions on device label, Vantron assumes

neither warranty nor legal liability even if the device is still under warranty.

1.6 Safety Instructions

 Keep and comply with all operation instructions, warnings, and information.

 Pay attention to warnings on this device.

 Read the following precautions so as to decrease the danger of injury, electric

shock, fire, or any damage to the device.

1.7 Precautions

 Pay attention to the product labels/safety instructions printed on silk screens.

 Do not try repairing this product unless declared in this manual.

 Keep away from heat source, such as heater, heat dissipater, or engine casing.

 Do not insert other items into the slot (if any of this device.

 Keep the ventilation slot ventilated for cooling.

 System fault may arise if other items are inserted into this device.

 Installation: ensure correct installation according to instructions from the

manufacturer with recommended installation tools.

 Ensure ventilation and smoothness according to relevant ventilation standard.

1.8 Safety Instructions for Power Cables and Accessories

Proper power source only

Start only with power source that satisfies voltage label and the voltage necessary

according to this manual. Please contact technical support personnel of Vantron for any

uncertainty about the requirements of necessary power source.

Warning：Avertissement：

□ This battery cannot mix with deposal or twice- recycled batteries in use. Otherwise, for its

abnormal charge and discharge, it will cause over-heated, distort, smoke or burning.

□ Cette batterie ne peut pas se mélanger avec des batteries deposal ou deux fois recyclées en

UCTB-27 User’s Manual

-6- www.vantrontech.com.cn

cours d’utilisation. Sinon, pour sa charge et sa décharge anormales, il provoquera une

surchauffe, une déformation, de la fumée ou une brûlure.

□ Keep the battery out of children’s reach and prevent them biting or swallowing the battery.

□ Gardez la batterie hors de la portée des enfants et empêchez-les de mordre ou d’avaler la

batterie.

□ Risk of fire or explosion if the battery is replaced by an incorrect type

□ Risque d'incendie ou d'explosion si le type de batterie est incorrect

Use tested power source

This product still contains a button lithium battery as a real-time clock after its external

power source is removed and therefore should not be short-circuited during transportation or

placed under high temperature.

Place cables properly:

Do not place cables at any place with extrusion danger.

Cleaning Instructions

 Please power off before cleaning the device.

 Do not use spray detergent.

 Clean with a damp cloth.

 Do not try cleaning exposed electronic components unless with a dust collector.

 Support for special fault: Power off and contact technical support personnel of Vantron

in case of the following faults:

 The device is damaged.

 The temperature is excessively high.

 Fault is still not solved after the operation according to the manual.

UCTB-27 User’s Manual

-7- www.vantrontech.com.cn

2 Over View

2.1 Introduction

Thank you for choosing Vantron. It is our commitment to provide our valued customers

with the embedded devices equipped with the state-of-the-art technology and the best

product services.

Tablet enables the interaction between operators/users and applications, connects

industrial control products such as wireless, transducer, battery inside, storage, etc. Tablet

adopts a display for displaying and input units such as touch screen, keyboard, audio, kind

of sensors etc. for writing working parameters or inputting operation commands. As a digital

device for realizing information interaction between human and machine, Tablet is

composed of hardware and software. Based on its ample function interfaces and powerful

user operational interface, it is very suitable for control units such as medical device,

intelligent transportation, industrial field, etc.

Vantron’s Embedded Computer products are based on the most advanced ARM and

Rockchip processors and have low-power consumption and high integration. The products

are designed for applications such as industrials, medicals, and transportations etc.

UCTB-27 User’s Manual

-8- www.vantrontech.com.cn

2.2 Features

2.3 Order information

Specifications

CPU

Processor

RK3288W, CPU:

Quad-core Cortex-A17, up to 1. GHz

GPU:

Mali-T7 4, up to 500MHz

Memory

RAM

2GB DDR3-18 ( Optional 4GB )

Flash

32GB eMMC 5.1 ( Optional 8GB or 1 GB )

Storage

1xMicro SD ( Internal ) ( Optional )

EEPROM

1Kb

Video

Video Decoder

Real-time video decoder

，

MPEG-2, MPEG-4, H.2 4, VP8

H.2 4:

21 0p @24fps (

3840x21 0 )

MPEG-4: 1080p@ 0fps ( 1920x1080 )

MPEG-2: 1080p@ 0fps (1920x1080 )

VP8: 1080p@ 0fps ( 1920x1080 )

Video Encoder

Support video encoder for H.2 4

Image size is to FHD ( 1920x1080 )

Maximum frame rate is up to1920x1080@30fps

Display

LCD

27" TFT LCD

Resolution

1920x1080

Contrast Ratio

3000:1

LCM Luminance

300 cd/m

( Typ. )

Support Color

1 .7M colors

View Angle

U/D 178° / R/L 178°

LED Life Time

30000 hours ( Typ. )

Touch Screen

Cap-touch, support for 10 touch.

Camera

Front Camrea

5M Pixels Auto Focus Camera at front upper left area.

Sensor

accelerometer

3-axis accelerometer

Interfaces

TF card

1 x TF card Slot ( Memory capacity to be determined ) ( Internal )

Debug

1 x 3.5mm Headphone jack ( Internal )

HDMI

1 x HDMI 2.0 ( Internal )

USB

2 x USB HOST ( TYPE A ), standard USB 2.0 ( Internal )

1 x Micro USB, standard USB 2.0; supports OTG ( Internal )

Button

1 x Recovery button ( Internal )

Wireless

WIFI&BT

WIFI: IEEE 802.11 a/b/g/n/ac; BT: 5.0

External Antenna ( Optional )

Mini-PCIe slot for 4G Module or GPRS Module ( Optional )

Audio

Speaker

2 x 3W speaker, Drill hole on frame a lower side. ( Internal )

MIC

1 x MIC at bottom

RTC

Supported

Software

Android .0.1

Applications

Provide SDK

Power

AC Input

110V/220V (50/ 0Hz)

Mechanical

Dimensions

74 x 413.15 x 0.3mm

Weight

TBD

nvironment

Condition

Temperature

Operation: 0 ~ 50

℃

, Storage -20 ~ 0

℃

Humidity

Operation: 20% ~ 80%, Storage: 10% ~ 90%

Accessories

12" AC cable

UCTB-27 User’s Manual

-9- www.vantrontech.com.cn

Note: please contact Vantorn for other order information.

Order Part Example

UCTB-27

(

CPA-G44-UWT4

RK3288W ARM

Quad

-core, Cortex-A17 1.6GHz

WIFI 802.11 a/b/g/n/ac, BT 5.0.

UCTB-27 User’s Manual

-10- www.vantrontech.com.cn

3 Hardware Instructions

3.1 Appearance

3.1.1 Appearance

Figure 3-1 : Front view

Figure 3-2 : Back view

3.2 Interface Description

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Vantron Industrie-PC Handbücher

Vantron

Vantron IBOX6425E Bedienungsanleitung

Beliebte Industrie-PC Handbücher anderer Marken

Chipsee

Chipsee PPC-A72-101 Bedienungsanleitung

Advantech

Advantech UNO-2184G Bedienungsanleitung

MSI

MSI MS-9A76 Bedienungsanleitung

Stackrack

Stackrack THOR200 Bedienungsanleitung

Moxa Technologies

Moxa Technologies DA-682C Series Bedienungsanleitung

Nodka

Nodka eBOX-3000-ETC Bedienungsanleitung

Siemens

Siemens SIMATIC IPC627E Bedienungsanleitung

MSI

MSI MS-9A89 Bedienungsanleitung

Artila

Artila Matrix-516 Bedienungsanleitung

Siemens

Siemens SIMATIC Rack PC 840 V2 Bedienungsanleitung

Advantech

Advantech IPPC-6152A Bedienungsanleitung

Beckhoff

Beckhoff CX9020 Bedienungsanleitung

Dell

Dell Embedded Box PC 5000 Bedienungsanleitung

IBASE Technology

IBASE Technology ASB200-918 Series Bedienungsanleitung

Lenovo

Lenovo ThinkCentre M90q Betriebsanleitung

IXXAT

IXXAT Econ 100 Bedienungsanleitung

Kontron

Kontron KBox A-151-TGL Bedienungsanleitung

AXIOMTEK

AXIOMTEK ICO500-518 Series Bedienungsanleitung
