VAT 653 Series Montageanleitung
Installation, Operating &
Maintenance Instructions
1071762EA Edition 15.01.2021
Series 653
With separated Controller
Sample picture
Series
653
2/16
Edition 15.01.2021 1071762EA
Imprint
Manufacturer
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Website:
Phone:
Fax:
Email:
www.vatvalve.com
+41 81 771 61 61
+41 81 771 48 30
CH@vatvalve.com
Publisher
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Editor
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Print
VAT Vakuumventile AG, CH
-
9469 Haag,
Switzerland
Copyright
©
VAT Vakuumventile AG
2021
No part of these instructions may be reproduced in any way (photocopies,
microfilms or any other reproduction processes) nor may it be manipulated with
electronic systems, duplicated or distributed without written permission from VAT.
Offenders are liable to pay damages.
The original VATfirmware and updated state of the artversions of the VATfirmware
are intended for use with VAT products. The VAT firmware contains a limited, time
unlimited user license. The VAT firmware may not be used for purposes other than
those intended nor is it permitted to make copies of the VAT firmware. In particular,
it is strictly forbidden to give copies of the VAT firmware to other people.
The use of trade names, brand names, trademarks, etc. in these Instructions does
not entitle third parties to consider these names to be unprotected and to use them
freely. This is in accordance with the meaning of the laws and acts covering brand
names and trademarks
.
Series 653
1071762EA Edition 15.01.2021 3/
16
Contents
1
Description of product........................................................................4
1.1
Identification of product ...................................................................................................4
1.2
Use of product.................................................................................................................4
1.3
Used abbreviations..........................................................................................................4
1.4
Related documents..........................................................................................................4
1.5
Important information.......................................................................................................4
1.6
Technical data.................................................................................................................4
2
Safety ...................................................................................................5
2.1
Compulsory reading material...........................................................................................5
2.2
Danger levels ..................................................................................................................5
2.3
Personnel qualifications...................................................................................................6
3
Installation...........................................................................................6
3.1
Electrical connection........................................................................................................6
3.2
Installation into the system..............................................................................................7
4
Repairs.................................................................................................8
5
Dismounting and Storage...................................................................9
5.1
Dismounting ....................................................................................................................9
5.2
Storage..........................................................................................................................10
6
Packaging and Transport.................................................................11
6.1
Packaging......................................................................................................................11
6.2
Transport.......................................................................................................................12
7
Disposal.............................................................................................13
8
Spare parts ........................................................................................14
9
Appendix............................................................................................15
DESCRIPTION OF PRODUCT Series
653
4/16
Edition 15.01.2021 1071762EA
1 Description of product
1.1 Identification of product
Fabrication No.:
000
.
.-
.
.
.
.-
.
.
.
./
.
.
.
.
A
-
.
.
.
.
.
.
Fabrication number
Order number
1.2 Use of product
tbdb4
Use product for clean and dry vacuum applications only. Other applications are only allowed with the
written permission of VAT.
1.3 Used abbreviations
tbdb94
1.4 Related documents
•
Product Data Sheet
•
Dimensional Drawing
•
IOMI Heating device (if valve with heater)
1.5 Important information
This symbol points to a very important statement that requires particular attention.
Example
:
Refer to chapter: «Technical data» for detailed information.
1.6 Technical data
Maximum cable length 4.5m
Series 653
ERROR! REFERENCE SOU
RCE NOT FOUND.
1071762EA Edition 15.01.2021 5/
16
2 Safety
2.1 Compulsory reading material
Read this chapter prior to performing any work with or on the product. It contains important information
that is significant for your own personal safety. This chapter must have been read and understood by
all persons who perform any kind of work with or on the product during any stage of its serviceable
life.
NOTICE
Lack of knowledge
Failing to read this manual may result in property damage.
Firstly, read manual.
These Installation, Operating & Maintenance Instructions are an integral part of a
comprehensive documentation belonging to a complete technical system. They must
be stored together with the other documentation and accessible for anybody who is
authorized to work with the system at any time.
2.2 Danger levels
DANGER
High risk
Indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING
Medium risk
Indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION
Low risk
Indicates a hazardous situation which, if not avoided, may result in minor or moderate
injury.
NOTICE
Command
Indicates a hazardous situation which, if not avoided, may result in property damage.
ERROR! REFERENCE SOU
RCE NOT FOUND.
Series
653
6/16
Edition 15.01.2021 1071762EA
2.3 Personnel qualifications
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
3 Installation
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
3.1 Electrical connection
NOTICE
Wrong connection
Wrong connection may result in damage of controller or power supply.
Connect all cables exactly as shown in the following descriptions and schematics.
NOTICE
Burned connector pins (spark)
Connector pins or electronic parts could damage, if plugged and unplugged under
power.
Do not plug or unplug connectors under power.
Series 653
ERROR! REFERENCE SOU
RCE NOT FOUND.
1071762EA Edition 15.01.2021 7/
16
3.2 Installation into the system
Disconnect 24VDC power from the controller and wait for 60 seconds
Description
Required tool
1. Connect link cable (male
connector) to controller adapter
connector X1 and fasten it.
X1
Philips screw driver
size 1
2. Connect link cable (female
connector) to valve adapter
connector X2 and fasten it.
X2
Philips screw driver
size 1
3. Install the valve in accordance
with valve IOMI
Valve IOMI
If you need any further information, please contact one of our service centers. You can find the addresses on our
website: http://www.vat.ch
REPAIRS Series
653
8/16
Edition 15.01.2021 1071762EA
4 Repairs
Repairs may only be carried out by the VAT service staff. In exceptional cases, the customer is
allowed to carry out the repairs, but only with the prior consent of VAT.
Please contact one of our service centers. You will find the addresses on our website
www.vatvalve.com.
Series 653 DISMOUNTING AND STORAGE
1071762EA Edition 15.01.2021 9/
16
5 Dismounting and Storage
WARNING
Unqualified personnel
Inappropriate handling may cause serious injury or property damage.
Only qualified personnel are allowed to carry out the described work.
5.1 Dismounting
NOTICE
Contamination
Gate and other parts of the valve must be protected from contamination.
Always wear clean room gloves when handling the valve.
NOTICE
Valve in open position
Valve body may become damaged if valve gate is in open position.
Move valve gate to the closed position before dismounting the valve.
1. Close the valve
2. For dismounting the valve please follow the instructions of chapter: «Installation», however in
reverse order.
DISMOUNTING AND STORAGE Series
653
10/16
Edition 15.01.2021 1071762EA
5.2 Storage
NOTICE
Wrong storage
Inappropriate temperatures and humidity may cause damage to the product.
Valve must be stored at:
– relative humidity between 10% and 70%
– temperature between +10 °C and +50 °C
– non-condensing environment
NOTICE
Inappropriate packaging
Product may get damaged if inappropriate packaging material is used.
Always use the original packaging material and handle product with care.
1. Clean / decontaminate valve.
2. Cover all valve openings with a protective foil.
3. Pack valve appropriately, by using the original packaging material.
