Vauxhall VIVARO Bedienungsanleitung

VIVARO

©Copyright by Vauxhall Motors Ltd., England.

Reproduction or translation, in whole or in parts, is not

permitted without prior written consent from Vauxhall Motors

Ltd.

All rights as understood under the copyright laws are explicitly

reserved by Vauxhall Motors Ltd.

All information, illustrations and specifications contained in this

manual are based on the latest production information

available at the time of publication.

The right is reserved to make changes at any time without

notice.

Edition: July 2006.

TS 1545-A-07

VIVARO

Operation, Safety and Maintenance

Owner’s Manual

TS1545-A-07.qxd 28/06/2006 14:37 Page 1

VAUXHALL Vivaro

Operation, Safety, Maintenance

-2

Data specific to your vehicle

Please enter your vehicle’s data here to ke ep it ea sily accessible.

This information is available under the section "Technical data " as well as on the identification plate.

Fuel

Designation

Engine oil

Grade

Viscosity

Tyre inflation pressure

Ty re si ze wi th full load

Summer tyres Front Rear

Winter tyres Front Rear

Weights

Permissible gross vehicle weight

– ECkerbweight

=Loading

-1

Your Vivaro

Developed to the latest findings of

automobile research, it offers technical

sophistication and exceptional comfort.

Your vehicle represents an intelligent

synthesis of advanced technology,

outstanding safety, environmental

compatibility and economy.

It now lies with you to drive your vehicle

safely and to see it performs perfectly.

This Owner's Manual provides you with all

the necessary information to that end.

Make sure your passeng ers are aware of

the possible risk of accident a nd injury

which may result from improper use of the

vehicle.

You must always comply with the laws of

the country in which you are travelling.

These could differ from the information in

this Owner’s Manual.

The Owner's Manualshould always be kep t

in the vehicle: ready to hand in the glove

compartment.

Make use of the Owner's Manual:

zIts "In Brief" section will give you an initial

overview.

zThe table of contents at the start of the

Owner’sManual and in each individual

chapter will help you find your way.

zIts index will help you find what you

want.

zIt will familiarise you w ith the

sophisticated technology.

zIt will increase your pleasure in your

vehicle.

zIt will help you to handle your vehicle

expertly.

The Owner’s Ma nual is designed to be

clearly laid-out and easily und erstood.

This symbol signifies:

6Continue reading on next page.

3The asterisk signifies equipment not

fitted to all vehicles (model variants,

engine options, m odels specific to one

country, optional equipment, Genuine

Vauxhall Parts and Accessories).

Yellow arrows in the illustrations serve as

points of reference or indicate some action

to be p erformed.

Black arrows in the illustrations ind icate a

reaction or a second action to be

performed.

Thank you for choosing a Vauxhall. We

wish you many hours of pleasurable

driving .

Your Vauxhall Team

9Warning

9War ning is used to mark tex t

regarding possible risks of accid ent or

injury. Failure to follow the instructions

could lead to injury or loss of life.

Inform vehic le passengers accord ingly.

Contents In b rief ... ......... ......... ......... ......... ......... ........ . 2

Instrum ents .... ......... .................. ............... 20

Keys, doors, b onnet ... ......... ......... ......... .. 37

Seats, interior......................................... .. 47

Safety system s........ ......... ......... ......... ...... 56

Lighting . ......... ......... ......... ......... ......... ...... 75

Windows ................................... .... ..... .... .. 79

Heating, ventila tion ... ......... ......... ......... .. 81

Tecshift.. ..... .... ..... .... .... ..... .... ................... 89

Driving hints.................................. ..... .... .. 95

Save fuel, protec t the env ironment ....... 97

Fuel consum ption, fuel, re fuelling .... ...... 99

Catalytic converter,

exhaust em issions ......................... ... 102

Drive control system s................... ........ 106

Dropside b od y............ ......... ......... ......... 109

Brakes.... ..... .... ..... .... .... ..... .... ..... ............. 113

Wheels, tyres.......................................... 117

Roof rack, caravan and trailer towing 122

Self-help ..... .... ..... .... .............................. 125

If y ou ha ve a problem ................ .......... 142

Service plan, m aintenance .......... ......... 144

Vehicle care ... ..... .... .... ..... .... ..... .... ..... .... 157

Technical data ............................. ..... ... 161

Index............................ ..... .... ..... .... ..... .... 174

Commitment to customer

satisfaction:

Our aim: to keep y ou ha ppy w ith y our

vehicle. All Vauxhall Authorised Repairers

offer first class service at competitive

prices. Experienced, factory-trained

technicians work according to fa ctory

instructions. Your Authorised Repairer can

supply you with GENUINE VAUXHALL-

APPROVED PARTS, which have undergone

stringent quality and precision checks, and

of course useful and attractive

VAUXHALL-APPROVED ACCESSORIES.

Our name is your guarantee!

For detailsof the

Vaux hall Authorised Repa irer Network

please ring this number; 01582 - 427200

In b ri e f2

In brief

Key numbers, Code numbers

Remove key number from key.

The k ey num ber is given in the vehicle

papers and in the Car Pass 3.

Immobilizer, radio 3: the code numbers are

given in the Car Pass and Radio Pass

respectively.

Donot keep the CarPass and Radio Pass in

the v ehicle.

6Further information - see pages 37, 38.

Unlocking the vehicle:

Direct remote control unit 3

towards vehicle,

press button c,

pull do or handle

The doors are unlocked.

To unlock mechanically: insert key andturn

in driver’s door lock and pull door handle.

To lock doors from inside, press central

locking button 3located on the lower

dashboard.

6Door locks - see page 37,

electronic immobilizer - see page 38,

remote control - see page 39,

central locking system - see page 41,

anti-theft locking system - see page 43,

Vauxhall alarmsystem- seepage 43.

Seat adjustment 3:

Pull handle, slide seat,

release handle,

allow seat to audibly latch into

position

Neveradjustthe driver’s seatwhilstdriving.

It could move in an uncontrolled manner

when the handle has been pulled.

9Warnin g

Imp ortant: Do not sit nearer than 10

inche s (25cm ) from the steering whe el, to

permit safe airbag deployment.

In brief 3

A djusting the sea t b ack :

Pull release lever

Move seat back to suit seating position, it

will lock in position when the lever is

released.

Adjusting the lumbar support 3:

Turn handwheel

Adjust lumbar support to suit p ersonal

re qu i reme n t s.

Do not lean on seat backrest whilst

adjusting it.

Adjusting arm rest support 3:

Adjust arm rest support to suit personal

requirements.

zRaise armrest in increments to desired

he ight.

zTo reposition, fully raise armrest before

low ering.

In b ri e f4

Adjusting seat height 3:

Pull lever at side

Lift lever and remove weight from seat to

raise it or p ress d own on seat with body

weight to low er it.

Neveradjust the driver’s seat whilst driving.

It could move in an uncontrolled manner

when the lever has been pulled.

6Seat position – see page 47.

Adjusting head restraint height:

hold firmly and adjust height,

then release

6Head restraint position – see page 47,

further information, removal – see page 48.

6Further information - see page 47.

9Warnin g

Disregard of these instructions may lead

to injuries or endanger life. Vehicle

passe ng ers should be inform ed

accordingly.

In brief 5

Steering wheel adjustment:

A djust po sition

Adjust the steering wheel only when the

vehicle is stationary.

Move the unlocking lever upwards, adjust

t h e w he el to th e de si re d p o s iti on , th e n

release the lever.

Push the lever firmly downwards to ensure

that the w heel is locked in position.

6Airbag systems - see page 61.

Fitting seat belt:

Draw seat belt smoothly from

inertia reel, guide over shoulder

and engage in buckle

The belt must not be twisted at any point.

The lap belt must lie snugly against the

body. The backrest must not be tilted back

too far (recommended tilting angle

approx. 25°).

To release belt, press red button on belt

buckle.

6Seat belts – see p ages 57 to 59,

airbag systems 3– see page 61,

seat position – see pag e 47.
