VECTECH 201D Desoldering Tool
Instruction Manual
Thank you for purchasing our products. Please keep
the instruction manual properly for future reference.
Contents
1. Safety Instructions................................................................................1
2. Overview................................................................................................2
3. Product Characteristics.......................................................................2
4. Product Specifications.........................................................................3
5. Functional Descriptions.......................................................................4
5.1. Dimensions................................................................................ 4
5.2. Part Descriptions.......................................................................5
5.3. Key Descriptions.......................................................................6
5.4. Function Descriptions of the Main Interface.........................7
6. Connection............................................................................................ 8
7. Temperature Settings.......................................................................... 8
8. Menu Settings.......................................................................................9
8.1. Channel Temperature Settings...............................................9
8.2. Address Settings.....................................................................10
8.3. Sound Switch Settings...........................................................10
8.4. Password Settings..................................................................10
8.5. Suction Count Settings.......................................................... 11
8.6. Language Settings..................................................................11
8.7. Sleeping Time Settings..........................................................12
8.8. Turn Off Settings.....................................................................12
8.9. Temperature Calibration........................................................ 13
9. Operation.............................................................................................14
10. Cleaning and Maintenance............................................................ 14
10.1. Maintenance of the Desoldering Nozzle.......................... 14
10.2. Checking and Cleaning of the Desoldering Nozzle........15
10.3. Steps of Installing the External Filter................................ 16
10.4. Steps of Installing the External Filter................................ 17
11. Replacing the Heater.......................................................................17
11.1. Steps of Removing the Heater........................................... 17
11.2. Steps of Replacing the Heater...........................................17
12. Troubleshooting............................................................................... 18
13. Selection of Desoldering Nozzles.................................................19
1
1.Safety Instructions
CAUTION
During the installation and use of this product, all electrical safety
regulations of the country and regions must be strictly observed.
The power supply must be disconnected when disassembling the
product. Do not operate with power on.
If the product does not work properly, please contact the supplier or
our company, and do not disassemble or change the product in any
way. We are not responsible for any problems caused by unauthorized
maintenance or modification.
WARNING
Don't install the product in a place where the surface is easy to shake
or be impacted, as it may damage the product.
Don't place the product in places where it may be exposed to rain or
moisture.
The product should be used away from places where there is
magnetic interference.
Don't use in flammable and explosive environments.
After using the desoldering station, the nozzle temperature will be
quite high, which is easy to burn operators and may cause dangerous
accidents.
Don't knock workbench with the desoldering gun to remove residual
flux, which may seriously damage the desoldering gun.
After the desoldering gun is used, a layer of melting tin should be
plated to prolong its life before placing it into the holder.
Please unplug the power cord when the product is not used for a long
time.
2
2.Overview
This desoldering tool uses high-frequency eddy current heating, which
makes the nozzle heat up quickly to melt the solder in the pad of the PC
B through-hole devices. The vacuum pump is started by the switch of
the desoldering gun switch to generate vacuum to suck the liquid tin
into the tin storage tube to achieve the purpose of quickly disassemblin
g the through-hole components. At the same time, it can also be used
for tin removal on the surface of the pad to improve maintenance
efficiency.
3.Product Characteristics
LCD display, touch button for comfortable operation.
Novel appearance design.
Powerful built-in vacuum pump.
Precise digital temperature calibration.
Function of counting tin absorbing times.
Support the function of preventing blockage.
3
4.Product Specifications
Product model
201D
Power consumption
200W
Voltage
AC 220V
Temperature range
300℃～500℃
Temperature stability
±2℃（No load）
Dimensions（L*W*H）
189.5*189.0*135mm
Weight
About 3.2 Kg
4
5.Functional Descriptions
5.1.Dimensions
Unit：mm
5
5.2.Part Descriptions
NO.
Part Descriptions
1
LCD Display
2
Touch Buttons
3
External Filter
4
Desoldering Gun
5
Desoldering Gun Holder
6
5.3.Key Descriptions
Key
Function Descriptions
+/-
Temperature up/down
1. Short press, temperature goes up or down by
1℃.
2. Long press, temperature goes up or down
quickly.
POWER
1. Power on: Press and hold the "POWER" button
to turn on
2. Power off: Press and hold the "POWER" button
to turn off
2/3
Press "2" and "3" keys at the same time to enter
the menu setting interface
1/+/-
1. Press "1" or "+" or "-" to switch the menu in the
menu setting interface.
2. Press "1" to switch parameter options, press "+"
or "-" to change the parameter value in the
parameter setting interface.
1/3
Press "1" and "3" keys at the same time to enter
the temperature calibration interface.
7
5.4.Function Descriptions of the Main Interface
Symbols
Descriptions
Symbols
Descriptions
CH0
Temporary channel
CH1～CH3
Channel 1 to Channel
3 optional
Password lock
No password lock
1. Red indicates the
heating state;
2. Black indicates the
no heating state;
3. Alternating red and
black indicates
constant temperature.
℃
Celsius
Buzzer on
Buzzer off
