Vector Revolution 180 Bedienungsanleitung

Operating Manual

_______________________________________

Relevance in print When buying the Vector Revolution 180 you decided in favour

of a model with an individual composition.

We ask for your understanding that there may be mentioned addi-

tional devices which you did not chose.

The high standard of quality and security is guaranteed by

continual development. Therefore there can appear differ-

ences between these operating instructions and your unit.

Also, errors cannot be totally excluded. Therefore we ask for

your understanding that from descriptions, indications and

illustrations there cannot be derived legal claims.

Order Information Please supply the following information:

Title of document

Code number

Date of issue

Language

Vector Systems Ltd

P O Box 78 331

Grey Lynn

AUCKLAND

NEW ZEALAND

Tel +64 9 950 4791

Fax +64 9 950 4792

Email inf[email protected]

+64 = International prefix

Contents .

_______________________________________

CHAPTERS

1 Technical data

1.1 Characteristic Data 1 - 1

1.2 Weight 1 - 1

1.3 Scope of application, operation and intended use 1 - 1

1.3.1 Scope of application 1 - 1

1.3.2 Operation 1 - 1

1.3.3 Intended use 1 - 1

1.4 Machine dimensions 1 - 2

1.5 Working dimensions 1 - 4

1.6 Connected load (Basic machine = units) 1 - 4

1.7 Ambient conditions 1 - 4

1.7.1 Electronic devices 1 - 4

1.8 Compressed air 1 - 4

2 Safety

2.1 Symbol and explanation of directions 2 - 1

2.2 Definitions 2 - 1

2.2.1 Correct use 2 - 1

2.2.2 Residual risk 2 - 1

2.2.3 Expert Personal 2 - 1

2.2.4 Proficient personnel 2 - 1

2.2.5 Qualified personnel 2 - 2

2.2.6 Protective clothing 2 - 2

2.3 Working safety directions 2 - 2

2.4 Protective devices 2 - 4

2.5 Residual risks 2 - 4

2.6 Emergency measures 2 - 5

2.6.1 General information 2 - 5

2.6.2 Fire hazard 2 - 5

2.6.3 First aid 2 - 6

3 General

3.1 Introduction 3 - 1

3.2 Application 3 - 1

3.3 Copyright ` 3 - 2

3.4 Address 3 - 2

3.5 Warranty 3 - 2

_______________________________________

Contents .

CHAPTERS

4 Transport, offloading, setting up

4.1 General instructions 4 - 1

4.2 Space requirement 4 - 1

4.3 Setting up area 4 - 1

4.4 Sensitivity 4 - 1

4.5 Ambient conditions 4 - 1

4.6 Transport routes 4 - 1

4.7 Interim storage 4 - 2

4.8 Cleaning 4 - 2

4.9 Transport from packaging to location 4 - 2

4.9.1 Transport means 4 - 2

4.9.2 Offloading 4 - 2

4.9.3 Levelling 4 - 6

5 Assembly

5.1 General instructions 5 - 1

5.2 Machine Assembly 5 - 1

5.2.1 Re-fitting of components removed for transportation 5 - 1

5.2.1.1 Fitting of X-Axis drive motor 5 - 1

5.2.1.2 Fitting of rear X Axis cable chain and support 5 - 3

5.2.1.3 Fitting and tensioning of X Axis drive belt 5 - 5

5.2.1.4 Fitting and tensioning of Y Axis drive belt 5 - 6

5.2.1.5 Fitting X Axis counter 5 - 8

5.2.1.6 Fitting X Axis +ve and X Axis –ve limit switches 5 - 9

5.2.1.7 Fitting emergency stop pullwire 5 – 10

5.2.1.8 Fitting edgeband coil support 5 - 11

5.2.2 Removing the axis transport brackets 5 – 13

5.3 Machine connections 5 – 14

5.3.1 Electrical 5 – 14

5.3.1.1 Cross section of connection cabling and input pre-fusing 5 – 14

5.3.2 Pneumatic 5 – 14

5.3.3 Testing End-Limit switches 5 – 15

5.3.4 Testing Axis counting direction (X + Y) 5 – 16

5.4 Preparations for no-load tests without workpieces 5 - 17

5.4.1 Mechanical 5 - 17

5.4.2 Electrical (provided by others) 5 – 17

5.4.2.1 Checking the direction of rotation 5 – 18

6 Design and mode of operation

6.1 General description 6 - 1

6.2 Design 6 - 1

6.3 Mode of operation 6 - 2

7 Operation panel

7.1 Control fields / control elements 7 - 1

7.2 Definition of control elements 7 - 1

_______________________________________

Contents .

CHAPTERS

8 Start up

8.1 Putting the basic machine into service 8 - 1

8.1.1 Switching on 8 - 1

8.1.2 Switching off 8 - 3

8.1.3 Emergency cut-out 8 - 4

8.1.4 Power failure 8 - 4

8.2 General Reset 8 - 4

9 Setting up basic machine

9.1 Preparation for Operation 9 – 1

9.1.1 Loading tape coil, feeding tape, setting guide height,

setting infeed top bar 9 – 1

9.1.2 End Trimming Band 9 – 5

9.1.3 Turning on the glue and setting height to match panel thickness 9 – 9

9.1.3.1 Setting glue height to match panel thickness 9 – 11

9.1.4 Setting glue start and stop adjustments 9 – 12

9.1.5 Setting Glue Pressures and Tape Presser 9 – 14

9.1.6 Setting the Nozzle Wiper 9 – 15

9.1.7 Loading a glue cartridge 9 – 16

9.1.7.1 Performing a glue-tape test 9 – 18

9.1.7.2 Manually purging glue cartridge 9 - 21

9.1.8 Selecting 360 degree setting for Butt Joint or Open Board 9 – 23

9.1.8.1 360 Degree Operation 9 – 24

9.1.8.2 Open Board Operation 9 – 27

9.2 Commencing a cycle 9 – 35

9.2.1 Setting Vacuum Cups and Lead Pods 9 – 35

9.2.2 Saving Start Positions 9 - 38

9.2.3 Single or Pendulum Operation 9 – 42

9.2.4 Start Cycle 9 – 43

9.2.4.1 Start Prevent Messages 9 – 44

9.2.5 Applying edging (without trimming or scraping) 9 – 45

9.2.6 Trimming edging (without gluing) 9 – 46

9.2.7 Setting trimmer shoes 9- 48

9.2.7.1 Setting horizontal trimmer tracer shoe 9 – 48

9.2.7.2 Setting vertical trimmer tracer shoe 9 – 50

9.2.8 Performing trimming and scraping cycle to test setup 9 - 53

9.2.8.1 Setting the glue joint scraper 9 – 54

9.3 Advanced Controls 9- 59

9.3.1 Advanced Controls: Glue 9- 60

9.3.2 Advanced Controls: Trimmer 9- 61

9.3.3 Advanced Controls: Scraper 9- 62

_______________________________________

9.3.4 Advanced Controls: Feed 9- 63

9.3.5 Advanced Controls: 360 Panel 9- 65

9.3.1 Advanced Controls: Panel Shapes 9- 66

9.4 Cycle Functions 9 – 67

9.4.1 Standard Conditions 9 - 67

9.4.2 Convex (external) Corner 9 - 67

9.4.3 Concave (internal) Corner 9 - 72

9.4.3.1 Aggregate pushed back by Bump Bar 9 - 73

9.4.3.2 Aggregate retracted by Bump Bar 9 - 74

9.4.3.3 Aggregate retracted by Bump Switch 9 – 75

9.4.4 Special Sequences 9 - 79

9.4.4.1 Setting trigger points 9 - 80

9.4.4.2 Setting up special sequences 9 - 81

9.5 Functions Page 9 - 83

9.6 Save/load settings 9 - 85

9.7 Alarms 9 - 87

10 Care and maintenance

10.1 General instructions 10 - 1

10.2 Maintenance chart 10 - 2

11 Troubleshooting and remedies

11.1 Simple fault schedule 11 – 1

11.2 List of alarms 11 – 3

11.3 Start Prevent alarms 11 - 4

12 Notes 12 - 1

Technical Data 1

________________________________________________________________________________________

_______________________________________

1-1

1.1 Characteristic Data

Machine designation: Contour Edgebander

Model Revolution 180

Manufacturer Vector Systems Ltd

P O Box 78 331

Grey Lynn

AUCKLAND, NEW ZEALAND

Serial Number ________________________

Year of Manufacture ________________________

1.2 Weight

Model Revolution 180

Weight (kg) 2500kg

1.3 Scope of application, operation and intended use.

1.3.1 Scope of application

This contour bander is for the automatic application of a wide range of banding

materials to contoured panels.

1.3.2 Operation

The workpieces are clamped to the worksurface using vacuum cups and the control

system positions the head against the panel and then follows the contour of the

panel.

1.3.3 Intended Use

The Tangent machine is used to profile the unfinished corners which result from

through-feed edgebanding. The cutter unit is mounted in a rotating suspension

system and is controlled by a copy bearing and tracer pin.

For admissible working dimensions, see section 1.5 . Any other use is deemed

incorrect. The manufacturer cannot accept liability for resultant damage. The user

shall bear the risk alone.

Technical Data 1

________________________________________________________________________________________

_______________________________________

1-2

1.4 Machine Dimensions

MODEL VECTOR Revolution 180

WIDTH 2606mm

HEIGHT 2450mm

LENGTH 4600mm

Technical Data 1

________________________________________________________________________________________

_______________________________________

1-3

Technical Data 1

________________________________________________________________________________________

_______________________________________

1-4

1.5 Working Dimensions

Pay attention to the restrictions for the working dimensions. See chapter -

Technical Data - for the related operating instructions.

Model VECTOR Revolution 180

Workpiece thickness min (mm)

max (mm)

External radius min (mm) 20

Internal radius min (mm)

1.6 Connected Load (Basic machine + units)

(For total connected load of machine, see serial plate)

Model VECTOR Revolution 180

400V 50Hz Power (kW)

Machine 0.6

Vacuum Pump 2.5

Control Voltage (V) 24VDC

1.7 Ambient Conditions

1.7.1 Electronic Devices

Operating Temperature 5°to 50°

Storage Temperature

to 50

1.8 Compressed Air

Model VECTOR Revolution 180

Compressed Air

- Operating pressure

- Limit Pressure

6 bar (6x105 Pa)

8 bar (8x105 Pa)

Connection 1/2” BSP female thread

CAUTION !
