Verykool T7442 Bedienungsanleitung
1
1.Introduction
1.1 Verykool T7442
Details Description
CPU +GPU ARM Cortex A7 1.3GHz Dual core Processor
Memory 512MB RAM
Storage 8GB Built-in storage (Approx. 4GB of built in storage is used by OS and
application files)
Micro SD Slot with up to 32GB expandable
Operating
System Android™ 4.4 KitKat.
Connectivity GSM Dual SIM (Normal + Micro) Quad-band 850/900/1800/1900
MHz; WCDMA 850/2100; HSPA+ 21 Mbps downlink and 5.76
Mbps uplink, Wi-Fi 802.11 b\g\n, Bluetooth(4.0), GPS/A-GPS,
USB OTG.
G-Sensor Rotate screen
Camera 13.0 MP Rear camera with Flash
5.MP Front camera for video calling
Display 17.78 cm (7Inch)display with HD Screen Resolution 1024*600
Full Capacitive Multi Touch
Video
Formats Support 3GP,AVI,MP4,M4V,MKV, WMV,MOV, FLV (With 3rd
party application)
Viewer Support JPG,PNG,BMP,GIF
2
Audio
Formats Support AAC,AMR, FLAC, MP2, MP3, OGG
FM Radio Yes
Audio Port Speaker /3.5mm Earphone Jack / Internal Mic. and Earpiece
Hardware
Keys Power and Volume controller
Soft Keys Return , Home, & Menu
Battery/
Power 2500mAh Polymer battery
Power 5V—1A
Dimension 191.89mm x 108.02mm x 9.65mm
Weight 274gm
3
1.2 Know Your Device
4
5
2.Getting Started
Installing the SIM card and Memory card
You need to remove a portion of the back cover before you can install the
SIM card and Micro SD card. Also, make sure to always turn off the power
before installing or replacing the SIM card and Micro SD card.
To install the SIM card: The SIM card contains your phone number,
service details, and phonebook/ message memory. Your device supports
both 2G& 3G SIM cards.
To install the memory card: To have additional storage for your images,
videos, music, and files, you can purchase a memory card and install it into
your device.
6
3.Read your notifications
7
4.Using phone features
a. Turning the phone function on or off: To enable or disable Airplane
Mode:
I. TouchSettingsMore…Airplane mode
II. Touch ‘airplane Mode’ to enable or disable
b. Making a call: On Home screen, touch Phone to enter the dial screen
I. Call log tab: select an entry listed in the log to call the number.
II. Contacts tab: Contacts with phone numbers are listed. Select a contact
and then select the phone number to dial.
c. Internet: You device’s networking capabilities allow you to access
internet using browser, Through Wi-Fi, GPRS and EDGE.
d. E-mail: Using the Email, you can send or receive emails from other email
accounts.
e. Messaging: Select whether you want to create SMS after entering create
new function. Enter text message, press option key to get the following
options. There are different options available for SMS like Sending options,
Input method and more.
f. Gallery: Using gallery you can see picture and video.
8
g. Music: Use the Music player to play music files. The songs saved in your
Memory Card can be played using the Music Player of the device.
h. Camera: Use the rear and front camera to capture the picture and record
the video.
i. Calendar: Use Calendar to create and manage events, meetings, and
Appointments.
j. Video Player: Using this you can play your videos from gallery.
k. FM radio: This device presents radio function. Using this you can play as
well as record Your favorite song from FM.
l. File manager: The phone provides a certain space for users to manage
files and supports the memory card. You can use file manager to
conveniently manage various directories and files on the memory card.
Choose file manager and press options to perform operations like ‘Open’,
‘New folder’, ‘Rename’, ‘Delete’ ,'Copy', 'Move' and more.
9
5.Settings
Wireless & Networks
SIM Management: You can select to activate or deactivate the SIM card
you want to open .Set the default SIM to use voice call, video call, and
messaging and data connection on/off switch.
Wi-Fi: Wi-Fi on/off: Select Wi-Fi checkbox from settings if you prefer to use
Wi-Fi for your data connection.
Wi-Fi settings: Open the Wi-Fi settings screen; select it from the network
list. Provide your username or password if required.
Bluetooth: Bluetooth on/off: Use Bluetooth check box from settings to turn
Bluetooth services on or off.
Bluetooth settings: With Bluetooth services on, you can open the
Bluetooth settings screen to: Rename phone, advance settings.
Data Usage: It provides a graphical representation of data usage for a
specified Data usage cycle through Mobile internet or Wi-Fi
More settings
Airplane Mode:Using this you can on/off Airplane mode.
10
Default SMS app:The system settings allow users to select a "default SMS
app." Once selected, only the default SMS app is able to write to the SMS
Provider and only the default SMS app receives the SMS. The default SMS
app is responsible for writing details to the SMS Provider when it receives or
sends a new message.
Tethering & portable hotspot: The device is used as a wireless modem for
a PC, when it’s connected to PC using a USB cable.
VPN: VPN stands for virtual private mode. Using this feature .You can
connect to your private network through a public network.
Mobile Network: Select data roaming capability.
USB internet: using this function sharing windows PC internet via USB
cable.
Device
Audio Profiles: There are four types of user profiles available, they are
general, silent meeting and outdoor. Select one user profile and enter the
following options:
Vibrate: select to have your phone vibrate for incoming calls.
Volume: select to open volume control.
Voice call ring tone: select a ring tone to use for incoming call.
DefaultNotification sound: Select a ring tone to use for a notification.
