Vestfrost CFS 344 Bedienungsanleitung

CFS 344

GB Instructions for use

DE Bedienungsanleitung

FR Mode d’emploi

IT Manuale d’uso

NL Gebruiksaanwijzing

Get to know your freezer

Control panel.

Top light.

Name plate.

Drawer.

Door.

Kick plate.

Adjustable feet.

In case this appliance contains hydrocar-

bon freezer please refer to guidelines listed

below.

As the appliance contains a ammable

freezer, it is essential to ensure that the

freezer pipes are not damaged.

Standard EN378 species that the room

in which you install your appliance must

have a volume of 1m³ per 8 g of hydrocar-

bon freezer used in the appliances. This is

to avoid the formation of ammable gas/

air mixtures in the room where the appli-

ance is located in the event of a leak in the

freezer circuit. The quantity of the freezer

used in your appliance is indicated on the

rating plate.

WARNING: Keep ventilation openings in

the appliance’s cabinet or in

the built-in structure clear of

obstruction

WARNING: Do not use other mechanical

devices or other means to ac-

celerate the defrosting process

than those recommended by

the manufacturer

WARNING: Do not damage the refrigerant

system

WARNING: Do not use electrical appli-

ances inside the refrigerated

storage compartment, unless

they are of a type recommend-

ed by the manufacturer

WARNING: Do not expose the appliance

to rain

WARNING: This appliance is not intended

for use by young children or

inrm persons unless they have

been adequately supervised by

a responsible person to ensure

that they can use the appliance

safely. Young children should

be supervised to ensure that

they do not play with the appli-

ance

●Always keep the keys in a separate place

and out of reach of children

●Before servicing or cleaning the appli-

ance, unplug the appliance from the

mains or disconnect the electrical power

supply

●If the supply cord is damaged, it must be

replaced by the manufacturer, its service

agent, or similarly qualied persons in

order to avoid a hazard

●Relevant for Australia: Supply cord

tted with a plug complies with AS/NZS

3112.

●Frost formation on the interior evaporator

wall and upper parts is a natural phenom-

enon. Therefore, the appliance should

be defrosted during normal cleaning or

maintenance.

●Please note that changes to the appli-

ance construction will cancel all warranty

and product liability

Warning

Contents

Get to know ............................................2

Warning ..................................................3

Before starting the appliance..................4

Maintenance...........................................4

Installation ..............................................5

Technical data.........................................5

Control panel ..........................................6

How to freeze .........................................6

Defrosting the freezer.............................7

Has the appliance stopped working?......8

General advice .......................................8

Change of light bulb................................8

Lock........................................................8

Change of hinge side..............................9

Warranty, spare parts ...........................10

Disposal................................................ 11

Maintenance

The kick panel can be removed to faciliate a

vacuum-cleaning of the oor.

Only use an unscented detergent when

cleaning the cabinet inside.

You may remove the top panel and wash it

when cleaning the cabinet inside.

Switch off the appliance and pull out the

plug when cleaning the cabinet.

To make the cooling system work at its

optimum it is necessary from time to time

to clean the wire condensator and the com-

pressor at the back of the cabinet by means

of a brush or a vacuum cleaner. Remember

to clean the drain.

Check that the cabinet is undamaged.

Please report any damage immediately to

your dealer. Wash the cabinet and inner

lining with a mild unscented detergent and

wipe it dry. Do not use abrasive scouring

powder, steel wool or similar.

If the appliance has digital thermometer

please see page C and D

Before starting the

appliance

immediately observe that the power has

been cut off. Construction and details in the

accessories are subject to alteration without

previous notice.

Technical data

Installation

See drawings - page A and B. Install the

cabinet in a dry place and so that it is not

exposed to direct sunlight or any other heat

source.

Place the cabinet in a level position. This is

easily achieved by adjusting the adjustable

feet at the front edge of the base.

The cabinet may not rest against a wall on

its hinged side. When placing the cabinet

on carpet or on wooden oor you should

adjust it once more after some time as the

cabinet might settle in soft foundations.

If you want to build the appliance into a

cupboard you must consider 3 factors:

1. There must be space above the appli-

ance in order to make the cooling system

work satisfactorily.

2. When the door is opened the appliance

takes up more room than the width of

the cabinet and therefore the door must

either be placed outside the cupboard or

there must be a space of at least 1,5 cm

at the hinge side.

3. The distance to the wall at the hinge side

must be of a sufcient size.

Furthermore it is possible to build together

two appliance. If one of these is a wine

cabinet please observe a min. distance of

25mm between the cabinet in order to keep

cooling performance intact.

It is safest to place the earthed wall socket

abo ve the appliance and at least 1.7 / 2.0

m above the oor. Any local installation

rules for appliances of this kind must be

observed.

During a storm the electricity supply might

be cut off. You should be aware of this

when installing the appliance in weekend

cottages or elsewhere where you would not

This device complies with relevant EU

directives including Low Voltage Directive

2006/95 EEC. and Electromagnetic Com-

patibility Directive 2004/108/EC

The rating plate provides various techni-

cal information as well as type and serial

number.

How to freeze.

To keep food at its best, items must be fro-

zen to –18 °C as quickly as possible.

Activating the Super Freeze function reduc-

es freezer temperature to –25 °C. If items

weighing 3 kg or more are to be frozen, the

Super Freeze button should be activated

about 24 hours in advance.

To freeze smaller quantities, it is sufcient

to activate Super Freeze just a couple of

hours in advance, or even at the same time

as items are placed in the freezer. There

is no need to use Super Freeze when pre-

frozen items are placed in the freezer or

when small, single items are involved.

Control panel

1. Yellow pilot lamp lights when freezing

switch is activate.

2. Thermometer (not in all appliance).

3. Lighting

4. Thermostat knop.

5. Super freezing switch.

6. Door switch, lighting.

..-10.....-20.....-30..

Super Freeze

If more than 3 kg of fresh items are to be

frozen, proceed as follows:

1. Press the Super Freeze button (the

yellow lamp lights up). The freezer then

operates at maximum capacity (the com-

pressor runs continuously).

2. Activate Super Freeze 24 hours before

placing fresh items in the freezer.

3. After placing fresh items in the freezer,

leave Super Freeze on for a further 24

hours.

4. Then press the Super Freeze button

again (the yellow lamp goes off).

The goods and the humidity of the air will

gradually cause frost and ice to form in the

freezer unit. A thin layer of frost or ice does

not affect the functioning of the freezer,

but the thicker the coating, the higher the

energy consumption. A little loose frost can

be scraped off with a plastic or wooden

scraper. (Never use a knife or other sharp

tool, as this may damage the evaporator

unit). When the frost and ice is about 4-5

mm thick, the freezer must be defrosted. Do

this as follows:

1. Switch off the unit by turning the thermo-

stat knob to zero.

2. Pull out the spout at the bottom of the

freezer and put a bowl under it.

3. Take the food out. Keep it in the fridge or

packed in newspaper to keep it as cold

as possible.

4. Place a bowl of hot (not boiling) water in

the freezer.

5. When the ice has melted, clean the

freezer with water and a little detergent.

Wipe dry with a soft cloth.

6. Set the thermostat button again. Push in

the freezing button if there is a lot of food

to be put in the unit.

7. Put the food in again when the tempera-

ture has reached -18°C - you can see

this on the freezer thermometer (it takes

about an hour).

8. Switch off the freezing button.

For defrosting pull out the drain

water extension over a bowl.

Defrosting the freezer

Save energy

●Cool hot food and beverages before plac-

ing them in the freezer.

●Thaw frozen items in a refrigerator.

●Keep the lid closed as much as possible.

●Check regularly that the lid closes tightly.

●Position the freezer in a cool (min. 5 °C

well-ventilated room.

●Place frozen items in a refrigerator while

defrosting the freezer.

●Defrost the freezer before the layer of ice

becomes excessively thick.

Before calling a repairman, check that

the plug is properly plugged into the wall

socket.

●The fuse is intact.

●The power has not been cut off.

●All controls are correctly set.

●Switch off the cabinet for 15 minutes (for

instance at the thermostat). Switch back

on and after 5 minutes check whether

frost has formed on the evaporator.

●Do not open the cabinet unnecessary.

Has the appliance

stopped working?

The appliance is equipped with a high qual-

ity skin condenser.

Therefore, a slight heating of the side walls

is quite normal.

Lighting

This appliance is equipped with a device

which causes the light to switch off if the

door is left open for abnormally long time.

When the door has been closed for a

couple of minutes, the light switch returns to

normal operation.

General advice

Remove the mains plug from the socket.

The light bulb is changed like a normal light

bulb.

Bulb designation: 12W E14.

Please note:

The light bulb have a rating of max. 12W.

Change of light bulb Mounting of lock

(Optional extra.)

Change of hinge side

1) Dismount the top hinge. The hinge is to

be used later as top hinge at the

opposite side. Lift off the door.

5) Move the handle.

2) Remove the kick plate. The bottom hinge

is dismounted at the 3 screws. The hinge is

turned 180° and mounted on the opposite

side.

4) Adjusting the bottom door: Loosen the

3 screws in the bottom hinge and push

the bottom hinge to the required side.

Tighten the screws and mount the kick

plate.

The kick plate.

3) Ajustment of the top door:

loosen the screws in the hinge

above the door, loosen the hinge

above the door and turn

the hinge to the wanted

side. Tighten the screws.

Warranty, spare parts and service

Warranty disclaimer

Faults and damage caused directly or

indirectly by incorrect operation, misuse,

insufcient maintenance, incorrect building,

installation or mains connection. Fire, ac-

cident, lightening, voltage variation or other

electrical interference, including defective

fuses or faults in mains installations.

Repairs performed by others than approved

service centres and any other faults and

damage that the manufacturer can sub-

stantiate are caused by reasons other than

manufacturing or material faults are not

covered by the warranty.

Please note that changes to the construc-

tion of the appliance or changes to the

component equipment of the appliance will

invalidate warranty and product liability, and

the appliance cannot be used lawfully. The

approval stated on rating plate will also be

invalidated.

Transport damage discovered by the buyer

is primarily a matter to be settled between

the buyer and the distributor, i.e. the dis-

tributor must ensure that such complaints

are resolved to the buyer’s satisfaction.

Before calling for technical assistance,

please check whether you are able to rectify

the fault yourself. If your request for assist-

ance is unwarranted, e.g. if the appliance

has failed as a result of a blown fuse or

incorrect operation, you will be charged

the costs incurred by your call for technical

assistance.

Spare parts

When ordering spare parts, please state

the type, serial and product numbers of

your appliance. This information is given on

the rating plate. The rating plate contains

various technical information, including type

and serial numbers.

Product number.

Andere Handbücher für CFS 344

Inhaltsverzeichnis

Sprachen:

Andere Vestfrost Gefrierschrank Handbücher

Vestfrost

Vestfrost VF 1084 TT Bedienungsanleitung

Vestfrost

Vestfrost VW20NFE00 Bedienungsanleitung

Vestfrost

Vestfrost CMFN 144 W Bedienungsanleitung

Vestfrost

Vestfrost SZ***C Series Bedienungsanleitung

Vestfrost

Vestfrost VLS 026 RF SDD Bedienungsanleitung

Vestfrost

Vestfrost CMF 103 X Bedienungsanleitung

Vestfrost

Vestfrost VR-BS16501M0 Bedienungsanleitung

Vestfrost

Vestfrost VTS254 Bedienungsanleitung

Vestfrost

Vestfrost ULTF-C74i Bedienungsanleitung

Vestfrost

Vestfrost WV84KFTT Bedienungsanleitung

Vestfrost

Vestfrost ULTF-37 Bedienungsanleitung

Vestfrost

Vestfrost VWT717FFE00B Bedienungsanleitung

Vestfrost

Vestfrost CFS 344 Bedienungsanleitung

Vestfrost

Vestfrost VF 11186 NoFrost Bedienungsanleitung

Vestfrost

Vestfrost VLS 076 RF SDD Bedienungsanleitung

Vestfrost

Vestfrost VD 865 FNX Bedienungsanleitung

Vestfrost

Vestfrost VR-BF27912H1S Bedienungsanleitung

Vestfrost

Vestfrost ULTF 40 Bedienungsanleitung

Vestfrost

Vestfrost WV146F Bedienungsanleitung

Vestfrost

Vestfrost VD200CFM Bedienungsanleitung

Vestfrost

Vestfrost WV186F Bedienungsanleitung

Vestfrost

Vestfrost ULTF-37i Bedienungsanleitung

Vestfrost

Vestfrost ULTF-C74i Bedienungsanleitung

Vestfrost

Vestfrost ULTF40 Bedienungsanleitung

Beliebte Gefrierschrank Handbücher anderer Marken

Siemens

Siemens GU..D SERIES Bedienungsanleitung

Omcan

Omcan FR-CN-0155 Bedienungsanleitung

Beko

Beko FNE290E24W Bedienungsanleitung

Electrolux

Electrolux ARCTIS G 8 60 50-6I Bedienungsanleitung

Electrolux

Electrolux EUF2042AOX Bedienungsanleitung

Dometic

Dometic CoolFreeze CFX95DZ Bedienungsanleitung

Electrolux

Electrolux EUF7000W1 Bedienungsanleitung

Polar Electro

Polar Electro CT330 Bedienungsanleitung

MPM

MPM MPM-145-SK Series Bedienungsanleitung

SAF

SAF PRESTOTIG 200AC/DC Kurzanleitung

Zanussi

Zanussi ZFT11407WA Bedienungsanleitung

AEG

AEG A63190GT Bedienungsanleitung

AEG

AEG A81000TNW0 Bedienungsanleitung

Matsui

Matsui MUC50S15E Bedienungsanleitung

NEFF

NEFF G4344X8 Bedienungsanleitung

Frigidaire

Frigidaire FV 1246 H Bedienungsanleitung

Frigidaire

Frigidaire FFC13K1AW Bedienungsanleitung

Electrolux

Electrolux EU 2400C Bedienungsanleitung
